IQ Switch
®
ProxSense
™
Series
IQS525-TP43L Trackpad Module
The IQS525-TP43L trackpad module integrates an IQS525 controller designed for optimized
performance. The module requires a simple I
2
C interface to a host microcontroller.
IQS525-TP43L Module Features:
•
•
•
•
•
•
•
•
•
•
•
•
Supplied as qualified PCB module – optimized layout
600 DPI, up to 330Hz report rate
Overlay – typical 2mm acrylic
Up to 5 finger touch
ZIF type connector – interface to FPC cable
Low Power: 8
µA
active standby
I
2
C interface
The module supports 5 snap dome buttons
DS100 or CT210 for data streaming required
2mm flat acrylic overlay
FPC cable
AZP216 interface board
Development Tools
Applications
•
•
•
Remote control: Navigation keys or trackpad
Wireless keyboard & media centre controllers
Laptop, tablet docking station
Resources Available for Download
•
•
•
•
•
•
•
Quick Start Guide
User Guide
Settings File
Graphical User Interface (GUI)
GUI Guide
Application note on how to design a trackpad
Gerber Files for the module
