Z5SMC8.7 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> Z5SMC8.7

Z5SMC8.7: DescriptionZener Diode, 8.7V V(Z), 5%, 5W, Silicon, Unidirectional, DO-214AB, PLASTIC, SMC, 2 PIN; CategoryDiscrete semiconductor diode; File Size51KB，2 Pages; ManufacturerSEMIKRON; Websitehttp://www.semikron.com

Download Datasheet Parametric Compare View All

Z5SMC8.7 Overview

Zener Diode, 8.7V V(Z), 5%, 5W, Silicon, Unidirectional, DO-214AB, PLASTIC, SMC, 2 PIN

Z5SMC8.7 Parametric

Parameter Name	Attribute value
Maker	SEMIKRON
Parts packaging code	DO-214AB
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-214AB
JESD-30 code	R-PDSO-C2
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-50 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
polarity	UNIDIRECTIONAL
Maximum power dissipation	5 W
Certification status	Not Qualified
Nominal reference voltage	8.7 V
surface mount	YES
technology	ZENER
Terminal form	C BEND
Terminal location	DUAL
Maximum voltage tolerance	5%
Working test current	150 mA

Z5SMC8.7 Preview

Z5 SMC 1 ... Z5 SMC 200 (5W)

Absolute Maximum Ratings

Symbol Conditions

Values

Units

Surface mount diode

Zener silicon diodes

Z5 SMC 1 ... Z5 SMC 200

Maximum Power

Dissipation: 5 W

Nominal Z-voltage: 8,7 to 200 V

Features

Mechanical Data

18-04-2007 MAM

Z5 SMC 1 ... Z5 SMC 200 (5W)

Surface mount diode

Zener silicon diodes

Z5 SMC 1 ... Z5 SMC 200

Maximum Power

Dissipation: 5 W

Nominal Z-voltage: 8,7 to 200 V

Features

Mechanical Data

18-04-2007 MAM

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

Z5SMC8.7 Related Products

	Z5SMC8.7	Z5SMC170	Z5SMC190
Description	Zener Diode, 8.7V V(Z), 5%, 5W, Silicon, Unidirectional, DO-214AB, PLASTIC, SMC, 2 PIN	Zener Diode, 170V V(Z), 5%, 5W, Silicon, Unidirectional, DO-214AB, PLASTIC, SMC, 2 PIN	Zener Diode, 190V V(Z), 5%, 5W, Silicon, Unidirectional, DO-214AB, PLASTIC, SMC, 2 PIN
Maker	SEMIKRON	SEMIKRON	SEMIKRON
Parts packaging code	DO-214AB	DO-214AB	DO-214AB
package instruction	R-PDSO-C2	R-PDSO-C2	R-PDSO-C2
Contacts	2	2	2
Reach Compliance Code	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99
Configuration	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON
Diode type	ZENER DIODE	ZENER DIODE	ZENER DIODE
JEDEC-95 code	DO-214AB	DO-214AB	DO-214AB
JESD-30 code	R-PDSO-C2	R-PDSO-C2	R-PDSO-C2
Number of components	1	1	1
Number of terminals	2	2	2
Maximum operating temperature	150 °C	150 °C	150 °C
Minimum operating temperature	-50 °C	-50 °C	-50 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
polarity	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL
Maximum power dissipation	5 W	5 W	5 W
Certification status	Not Qualified	Not Qualified	Not Qualified
Nominal reference voltage	8.7 V	170 V	190 V
surface mount	YES	YES	YES
technology	ZENER	ZENER	ZENER
Terminal form	C BEND	C BEND	C BEND
Terminal location	DUAL	DUAL	DUAL
Maximum voltage tolerance	5%	5%	5%
Working test current	150 mA	8 mA	5 mA
