5962-8966901EA

Description
Quad SPST JFET Analog Switch
CategoryAnalog mixed-signal IC    The signal circuit
File Size257KB,12 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

5962-8966901EA Overview

Quad SPST JFET Analog Switch

5962-8966901EA Parametric

Parameter NameAttribute value
Brand NameAnalog Devices Inc
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeDIP
package instructionGLASS SEALED, CERDIP-16
Contacts16
Manufacturer packaging codeQ-16
Reach Compliance Code_compli
ECCN codeEAR99
Analog Integrated Circuits - Other TypesSPST
JESD-30 codeR-GDIP-T16
JESD-609 codee0
length19.05 mm
Nominal Negative Supply Voltage (Vsup)-15 V
normal positionNO/NC
Number of channels1
Number of functions4
Number of terminals16
Nominal off-state isolation58 dB
On-state resistance matching specifications8 Ω
Maximum on-state resistance (Ron)80 Ω
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
outputSEPARATE OUTPUT
Package body materialCERAMIC, GLASS-SEALED
encapsulated codeDIP
Encapsulate equivalent codeDIP16,.3
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
power supply+-15 V
Certification statusQualified
Filter levelMIL-STD-883
Maximum seat height5.08 mm
Nominal supply voltage (Vsup)15 V
surface mountNO
Maximum disconnect time400 ns
Maximum connection time500 ns
switchBREAK-BEFORE-MAKE
technologyBIPOLAR
Temperature levelMILITARY
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width7.62 mm
Base Number Matches1
a
FEATURES
Two Normally Open and Two Normally Closed SPST
Switches with Disable
Switches Can Be Easily Configured as a Dual SPDT or
a DPDT
Highly Resistant to Static Discharge Destruction
Higher Resistance to Radiation than Analog Switches
Designed with MOS Devices
Guaranteed R
ON
Matching: 10% max
Guaranteed Switching Speeds
T
ON
= 500 ns max
T
OFF
= 400 ns max
Guaranteed Break-Before-Make Switching
Low “ON” Resistance: 80 max
Low R
ON
Variation from Analog Input Voltage: 5%
Low Total Harmonic Distortion: 0.01%
Low Leakage Currents at High Temperature
T
A
= +125 C: 100 nA max
T
A
= +85 C: 30 nA max
Digital Inputs TTL/CMOS Compatible and Independent
of V+
Improved Specifications and Pin Compatible to
LF-11333/13333
Dual or Single Power Supply Operation
Available in Die Form
1
Quad SPST JFET
Analog Switch
SW06
FUNCTIONAL BLOCK DIAGRAM
V+
12
3
IN 1
S1
2
6
IN 2
8
LEVEL
SHIFT
7
11
IN 3
9
10
14
IN 4
16
15
4
DIS
13
GND
V–
5
D1
S2
D2
S3
D3
S4
D4
GENERAL DESCRIPTION
The SW06 is a four channel single-pole, single-throw analog
switch that employs both bipolar and ion-implanted FET
devices. The SW06 FET switches use bipolar digital logic inputs
which are more resistant to static electricity than CMOS devices.
Ruggedness and reliability are inherent in the SW06 design and
construction technology.
Increased reliability is complemented by excellent electrical
specifications. Potential error sources are reduced by minimizing
“ON” resistance and controlling leakage currents at high tem-
peratures. The switching FET exhibits minimal R
ON
variation
over a 20 V analog signal range and with power supply voltage
changes. Operation from a single positive power supply voltage
is possible. With V+ = 36 V, V– = 0 V, the analog signal range
will extend from ground to +32 V.
PNP logic inputs are TTL and CMOS compatible to allow the
SW06 to upgrade existing designs. The logic “0” and logic “1”
input currents are at microampere levels reducing loading on
CMOS and TTL logic.
REV. A
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 617/329-4700
Fax: 617/326-8703
