SJ78L09
Elektronische Bauelemente
3-Terminal
Positive Voltage Regulator
RoHS Compliant Product
A suffix of “-C” specifies halogen and lead-free
FEATURES
Maximum output current I
O
: 0.1A
Output voltage V
O
: 9V
Continuous total dissipation P
D
: 0.625W (T
A
=25°
C)
TO-92
TYPICAL APPLICATION
1
OUT
2
GND
3
IN
Note: Bypass capacitors are recommended for optimum stability and
transient response and should be located as close as possible to the
regulators.
REF.
A
B
C
D
E
Millimeter
Min.
Max.
4.40
4.70
4.30
4.70
12.70
-
3.30
3.81
0.36
0.56
REF.
F
G
H
J
K
Millimeter
Min.
Max.
0.30
0.51
1.27 TYP.
1.10
1.40
2.42
2.66
0.36
0.76
ABSOLUTE MAXIMUM RATINGS
(Operating temperature range applies unless otherwise specified)
Parameter
Input Voltage
Operating Junction and Storage Temperature Range
Symbol
V
I
T
OPR,
T
STG
Value
30
0~150, -55~150
Unit
V
°
C
ELECTRICAL CHARACTERISTICS
(At specified virtual junction temperature, V
I
=16V, I
O
=40mA, C
I
=0.33µF, C
O
=0.1µF unless otherwise specified)
Parameter
Symbol
Min.
8.64
Output Voltage
V
O
8.55
8.55
Load Regulation
Line Regulation
Quiescent Current
Quiescent Current Change
Output Noise Voltage
Ripple Rejection
Drop Out Voltage
△V
O
△V
O
I
Q
△I
Q
△I
Q
V
N
RR
V
D
-
-
-
-
-
-
-
-
-
-
Typ.
9
9
9
19
11
45
40
4.1
-
-
58
45
1.7
Max.
9.36
9.45
9.45
90
40
175
125
6
1.5
0.1
-
-
-
Unit.
V
V
V
mV
mV
mV
mV
mA
mA
mA
µV
dB
C
T
J
=25 °
C
Test Condition
12V
≦
V
I
≦24V,
I
O
=1mA~40mA,
T
J
=0~125 °
C
I
O
=1mA~70mA, T
J
=0~125 °
C
I
O
=1mA~100mA, T
J
=25 °
C
I
O
=1mA~40mA, T
J
=25 °
C
12V
≦
V
I
≦24V,
T
J
=25 °
C
13V
≦
V
I
≦24V,
T
J
=25 °
C
T
J
=25 °
C
13V
≦
V
I
≦24V,
T
J
=0~125 °
C
1mA
≦
V
I
≦
40mA, T
J
=0~125 °
C
10Hz
≦
f
≦
100KHz, T
J
=25 °
C
15V
≦
V
I
≦25V,
f=120Hz,
T
J
=0~125 °
C
T
J
=25 °
C
21-Mar-2013 Rev. A
Page 1 of 2
