RH73W2A1G0KTN: DescriptionRESISTOR, METAL GLAZE/THICK FILM, 0.125W, 10%, 500ppm, 1000000000ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

RH73W2A1G0KTN Overview

RESISTOR, METAL GLAZE/THICK FILM, 0.125W, 10%, 500ppm, 1000000000ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT

RH73W2A1G0KTN Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	CHIP, ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
structure	Rectangular
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.4 mm
Package length	2 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	1.2 mm
method of packing	TR
Rated power dissipation(P)	0.125 W
resistance	1000000000 Ω
Resistor type	FIXED RESISTOR
size code	0805
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	500 ppm/°C
Terminal surface	Silver (Ag)
Terminal shape	WRAPAROUND
Tolerance	10%
Operating Voltage	100 V

Preview

Download Datasheet

View All

C orporate Hom e

|

Electronic Components

|

Se gm e nts

|

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

>

Products

>

By Type

>

Resistors

>

Product Feature Selector

> Product Details

RH73W2A1G0KTN Product Details

Live Product Chat

Fixed Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

RH73W2A1G0KTN

(1625861-7)

T E I nternal N umber: 1 6 2 5 8 6 1 - 7

Product Highlights:

l

Resistor Type = High Value/High Voltage Resistors

l

Resistance Selection = G ?

l

Resistance = 1G ?

l

Power Rating = .125 W

l

Tolerance = 10 %

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

l

None Available

Catalog Pages/Data Sheets:

l

SMD High Value Resistors - Type RH73 Series - Tyco E...

(PDF, English)

Product Specifications:

l

None Available

Application Specifications:

l

None Available

Instruction Sheets:

l

None Available

CAD Files:

l

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

l

Resistor Type = High Value/High Voltage Resistors

l

Resistance (?)

= 1G

l

Element

= Thick Film

l

Termination Type = Solder

Electrical Characteristics:

l

Resistance Selection (?)

= G

l

Power Rating (W)

= 0.125

l

Tolerance (%)

= 10

l

Package Type

= Taped and Reeled

Body Related Features:

l

Series

= RH73

l

Mount Style

= Surface Mount

l

Packaging Style

= 0805

l

Package, C omponent Size

= 2.1 x 1.3

Industry Standards:

l

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

l

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

l

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

l

Temperature C oefficient (ppm/?C )

= ?500

Operation/Application:

l

Application

= High Voltage

Other:

l

Brand = C GS

Additional Information:

l

Product Line Information

RH73W2A1G0KTN Related Products

	RH73W2A1G0KTN	1625861-7
Description	RESISTOR, METAL GLAZE/THICK FILM, 0.125W, 10%, 500ppm, 1000000000ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT	RESISTOR, METAL GLAZE/THICK FILM, 0.125W, 10%, 500ppm, 1000000000ohm, SURFACE MOUNT, 0805, CHIP, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
package instruction	CHIP, ROHS COMPLIANT	CHIP, ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Installation features	SURFACE MOUNT	SURFACE MOUNT
Number of terminals	2	2
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
method of packing	TR	TR
Rated power dissipation(P)	0.125 W	0.125 W
resistance	1000000000 Ω	1000000000 Ω
Resistor type	FIXED RESISTOR	FIXED RESISTOR
size code	0805	0805
surface mount	YES	YES
technology	METAL GLAZE/THICK FILM	METAL GLAZE/THICK FILM
Temperature Coefficient	500 ppm/°C	500 ppm/°C
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	10%	10%
