This document was generated on 10/04/2013
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
15-80-0449
Active
C-Grid® Products
2.54mm Pitch C-Grid® Header, Through Hole without Peg, Dual Row, Vertical,
Shrouded, High Temperature, 44 Circuits, 0.38µm Gold, (Au) Selective Plating, Tin (Sn)
PC Tail Plating, 3.81mm Inside Shroud to End Circuit Spacing
Documents:
3D Model
Drawing (PDF)
Product Specification PS-70567 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
Agency Certification
CSA
UL
LR19980
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
General
Product Family
Series
Application
Overview
Product Name
UPC
PCB Headers
70567
Signal, Wire-to-Board
C-Grid® Products
C-Grid®
800753975453
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
No
44
44
Black
25
No
94V-0
No
No
None
Yes
Brass, Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
7.491/g
2
Vertical
3.30mm
No
Yes
2.36mm
Tube
2.54mm
2.54mm
0.381µm
1.905µm
No
No
Open Ends
No
Yes
Search Parts in this Series
70567Series
Mates With
70013 Interim Clip
Temperature Range - Operating
Termination Interface: Style
-55°C to +105°C
Through Hole
Electrical
Current - Maximum per Contact
Voltage - Maximum
2.5A
250V DC
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
5
SMC & Wave Capable (TH only)
1
245
Material Info
Old Part Number
A-70567-0292
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-70567
SDA-70567-****
