AC509
Typical Values
5 TO 500 MHz
TO-8 CASCADABLE AMPLIFIER
AC509
13.3 dB
+21.5 dBm
+34.0 dBm
4.2 dB
Medium Gain
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Output Power
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Third Order I.P.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Noise Figure
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High Performance Thin Film
Standard Size TO-8 Package
AC509
TO-8 Package for Amplifiers
SPECIFICATIONS
*
Parameter
Frequency (Min.)
Small Signal Gain (Min.)
Gain Flatness (Max.)
Noise Figure (Max.)
SWR (Max.)
Input/Output
Typical
3-600 MHz
13.3† dB
< ±0.25 dB
4.2 dB
< 1.5:1
Guaranteed
0 to 50 °C
-55 to +85 °C
5-500 MHz
12.5† dB
±0.5 dB
5.0 dB
1.7:1^
5-500 MHz
12.0† dB
±0.7 dB
5.5 dB
1.9:1^
Power Output (Min.)
@ 1dB comp.
Reverse Isolation
DC Current (Max.)
+21.5 dBm
18.0 dB
88.0 mA
+20.5 dBm
—
92.0 mA
+20.0 dBm
—
96.0 mA
AS509
* Measured in a 50-ohm system at +15 Vdc unless otherwise specified.
† 1.0 dB lower below 10 MHz. ^ 2.0:1 below 10 MHz.
SMTO-8 Package for Amplifiers
INTERMODULATION PERFORMANCE
Typical @ 25 °C
+12 volts
+48 dBm
+42 dBm
+31 dBm
+15 volts
+51 dBm
+45 dBm
+34 dBm
Second Order Harmonic Intercept Point
. . . . .
Second Order Two Tone Intercept Point
. . . . . .
Third Order Two Tone Intercept Point
. . . . . . . .
ABSOLUTE MAXIMUM RATINGS
Storage Temperature
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -62 to +125 °C
Maximum Case Temperature
. . . . . . . . . . . . . . . . . . . . . . . .
+125 °C
Maximum DC Voltage
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+19 Volts
Maximum Continuous RF Input Power
. . . . . . . . . . . . . . . .
+13 dBm
Maximum Short Term Input Power
(1 Minute Max.) . . . . . . . 100 Milliwatts
Maximum Peak Power
(3 µsec Max.) . . . . . . . . . . . . . . . . . .
0.5 Watt
Burn-in Temperature
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+105 °C
1
(θjc) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermal Resistance
+21 °C/Watt
Junction Temperature Rise Above Case
(Tjc) . . . . . . . . . . .
+40.5 °C
1. Thermal resistance is based on total power dissipaton.
DIMENSIONS ARE IN INCHES [MILLIMETERS]
