Commercial
CCR-53
Failsafe
Miniature DC-26.5GHz SPDT Switch
The CCR-53 Switch is a broadband, SPDT, electromechanical, coaxial switch designed to
switch a microwave signal from a common input to either of two outputs. The characteristic
impedance is 50 Ohms. The switches are small with connector spacing compatible with SMA
connectors.
The CCR-53 series switch is offered with either a failsafe or latching actuator. This design is
compatible with the two most common mounting hole patterns. The CCR-53 series switch is
interchangeable with a variety of
switches.
Break before make
Voltage (VDC) 20
O
C
Current (mA)
Switching Time:
Connectors:
Weight:
20 msec max
SMA (f)
1.65 oz. max
12
15
28
Specifications
RF Contacts:
Actuator
200 160 90
Temperature Range:
-40
O
C to +65
O
C (Operating)
Shock:
Vibration:
Humidity:
Typical Contact Life:
RF Power Handling
MIL-STD-202 Method 213, Condition D (500G Non Operating)
MIL-STD-202 Method 214, Condition D (10G RMS Non Operating)
Moisture Seal Available
5 Million Cycles
Insertion Loss Repeatability (1 Million Cycles):
DC to 6 GHz: 0.05 dB
DC to 20 GHz: 0.1 dB
3000
Typical Performance
Return Loss
rs
800
400
Sta
Power CW (Watts)
nda
rd S
MA
200
Co
nne
cto
15
80
40
25
10
0.1
0.01
1.0
4.0
Frequency GHz
10
18
26.5
Frequency GHz
26.5
0.0
0.4
Specifications
VSWR (max)
Insertion Loss (min)
Isolation (max)
DC-6 GHz 6-12 GHz 12-18 GHz 18-26.5GHz
IL dB
60
70
80
90
1.25:1
0.20 dB
70.0 dB
1.40:1
0.40 dB
60.0 dB
1.50:1
0.50 dB
60.0 dB
1.80:1
0.70 dB
50.0 dB
0.01
Frequency GHz
26.5
Specifications subject to change without notice.
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2007
Isolation dB
Miniature DC-26.5GHz SPDT Switch
Failsafe
Commercial
CCR-53
Indicators
TTL
Analog
H = 1.30 MAX. STD MODEL
H = 1.80 MAX. TTL MODEL
H = 1.30 MAX. STD MODEL
H = 1.80 MAX. TTL MODEL
Standard Width Body
Optional Narrow Width Body
Part Numbering System for CCR-53 (Failsafe)
CCR-53 S 1 O - N
Series
Connectors
Actuator Voltage
Connector
S: SMA Female #
Actuator Voltage
1: 28Vdc Failsafe #
2: 15Vdc Failsafe #
3: 12Vdc Failsafe #
Actuator Type
O: No Indicator Contacts #
C: Indicator Contacts #
Options
T: TTL Drivers with Diodes
N: Narrow Body #
R: Positive + Common
#: Stock item subject to prior sale
Options
Actuator Type
For other options contact Factory
Specifications subject to change without notice.
www.teledynecoax.com
email: coax@teledyne.com
Tel: (800) 351-7368
10/2007
