Barrier Strips
Tri-Barriers
D
ESCRIPTION
/A
PPLICATION
The Tri-Barrier product is an original
Thomas & Betts design and we set
new terminal block standards with its
introduction. In recent years, some of
our competition has copied this
design.
It’s easy to see why we’re copied.
Our Tri-Barrier blocks help contain
stray or frayed wire ends. This
prevents electrical shorts — not only
between positions on the same
block, but also between other
components immediately adjacent to
the block. With today’s high-density
PCB designs, this has become an
increasingly important feature.
TRI-BARRIER STRIPS
A
PPLICATIONS
• Industrial controls and automation
• Machine tools
• HVAC/R
• Power supplies
• Security/Irrigation
• Transformers
D
ESIGN
A
DVANTAGES
• Back barriers to safeguard field
wiring
• Fast wiring – backed-out wire-
ready screws
• Interupted thread prevents screws
from falling out
• Standoffs allow flux and solvents to
drain during cleaning
• Molded-to-length or cut-to-length
versions available
• Slotted or phil-slot screws available
CONNECTOR INDEX
0.250”
0.250”
0.325”
0.325”
0.375”
0.375”
0.375”
0.375”
Pitch, Series #3....................................................56-59
Pitch, Series RSB2..............................................60, 61
Pitch, Series #4....................................................62-65
Pitch, Series RSB3 ..............................................66-69
Pitch, Series #6....................................................70-73
Pitch, Series RSB6 ..............................................74-77
Pitch, Series BC6, Panel Mount ..........................78-79
Pitch, Series MB6, Double Level ........................80, 81
0.4375” Pitch, Series #8 ..................................................82, 83
•
®
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
55
Barrier Strips
Tri-Barriers
0.375" PITCH
SERIES #6
TRI-BARRIER
P
HYSICAL
P
ROPERTIES
H
OUSING
M
ATERIAL
:
Polyamide
F
LAMMABILITY
:
UL94V-0
C
OLOR
:
Black
T
ERMINAL
T
ERMINALS
:
Bright acid tin over copper alloy
S
CREWS
:
#6-32 steel, zinc plating with clear
chromate coating. Wire clamping screws stan-
dard. Binding head screw with undercut optional.
6PCV-03 & 6PCV-06
M
ECHANICAL
P
ITCH
(T
ERMINAL
S
PACING
):
0.375"
R
ECOMMENDED
PCB H
OLE
D
IA
.:
1.8mm (.073")
E
LECTRICAL
P
ROPERTIES
M
AXIMUM
C
URRENT
:
25A
O
PERATING
V
OLTAGE
:
300V
W
IRE
R
ANGE
:
12-22 AWG
6,8
(.27)
9,5
(.375)
E
NVIRONMENTAL
P
ROPERTIES
O
PERATING
T
EMPERATURE
R
ANGE
:
105°C max.
6,8
(.27)
9,5
(.375)
(For Dual Pin Configuration) 10,9
.433
1,8 Dia.
4,6
(.073)
(.18)
(For Dual Pin Configuration) 10,9
.433
1,8 Dia.
4,6
(.073)
(.18)
7,9
(.31)
RIGHT ANGLE
VERTICAL
3,8
PRINTED CIRCUIT BOARD LAYOUT
Dia.
(.150)
5,6
(.22)
4,1
(.16)
Cut Out
3,8
Dia.
(.150)
7,9
(.31)
4,0
(.156)
6,3
(.25)
5,6
(.22)
6,3
(.25)
8,4
6,3
(.33)
(.25)
4,0
(.156)
Cut Out
4,1
(.16)
6,3
(.25)
2,4
(.094)
7,9
(.31)
Cut Out
Cut Out
5,6
(.22)
4,8
(.19)
8,4
(.33)
2,4
(.094)
3,8
Dia.
(.15)
7,9
(.31)
4,8
(.19)
3,8
Dia.
(.15)
5,6
(.22)
RIGHT ANGLE
VERTICAL
MOUNTING PANEL LAYOUT
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
70
Barrier Strips
Tri-Barriers
0.375" PITCH
SERIES #6
TRI-BARRIER
O
RDERING
I
NFORMATION
A
6 PCV-04-004
A
C
B
C
D
Screw Size Spacing
6
= #6-32 on .375" Centers
No. of Circuits
(Not positions)
02
through
30
B
Terminal Style
DBL
= Double Printed Circuit Pin
D
Modifiers
PCR
= Printed Circuit, Right Angle
Use table below.
PCV
= Printed Circuit Pin, Vertical
Note:
If modifier is -000
STR
= Solder Turret, Right Angle
it may be omitted. (6PCV-06)
STV
= Solder Turret, Vertical
TBV
= Non Feed Thru (bottom covers required for all powered
positions)
WWR
= Solderless Wire Wrap, Right Angle
WWV
= Solderless Wire Wrap, Vertical
Combo Head
Slotted Head
Phil-slot Head Slotted Head
Modifier
Model
DBL
PCV
Slotted Head
000
001
000
001
004
005
PCR
000
001
004
005
STV
WWV
000
004
000
004
Modifier
Phil-slot Head
006
007
006
007
008
009
006
007
008
009
006
008
006
008
Screw Style
Wire Clamp
Binding Head
Wire Clamp
Binding Head
Wire Clamp
Binding Head
Wire Clamp
Binding Head
Wire Clamp
Binding Head
Wire Clamp
Wire Clamp
Wire Clamp
Wire Clamp
Mounting Construction
No Mounting
No Mounting
No Mounting
No Mounting
STR
WWR
TBV
000
006
Wire Clamp
®
LR30811
E54800
Thomas & Betts Electronics/OEM Division Tel: 901-252-7766 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in inches.
71
