CA0224M96 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> CA0224M96

CA0224M96: DescriptionQUAD OP-AMP, 9000uV OFFSET-MAX, 1MHz BAND WIDTH, PDSO14; CategoryAnalog mixed-signal IC Amplifier circuit; File Size805KB，6 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CA0224M96 Overview

QUAD OP-AMP, 9000uV OFFSET-MAX, 1MHz BAND WIDTH, PDSO14

CA0224M96 Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	SOIC
Contacts	14
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.5 µA
Nominal Common Mode Rejection Ratio	70 dB
Maximum input offset voltage	9000 µV
JESD-30 code	R-PDSO-G14
Number of functions	4
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	COMMERCIAL
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal location	DUAL
Nominal Uniform Gain Bandwidth	1000 kHz
