NTHS
Vishay Dale
NTC Thermistors, SMD Chip
FEATURES
•
Extended resistance values available in
standard sizes
•
Wraparound Ni barrier terminations with
100 % Sn (or Sn90Pb10)
•
Allows design flexibility for use with hybrid circuitry
•
Available in bulk or tape and reel packaging
•
High-density monolithic construction with glass overcoat
•
Compliant to RoHS directive 2002/95/EC
•
Halogen-free according to IEC 61249-2-21 definition
QUICK REFERENCE DATA
PARAMETER
Resistance value at 25
°C
Tolerance on
R
25
- value
VALUE
1.0 kΩ to 350 kΩ
± 1 %, ± 2 %, ± 3 %,
± 5 %, ± 10 %
3181K to 4247K
±3%
- 40 °C to + 125 °C (150 °C)
APPLICATIONS
•
Temperature sensing, protection and compensation in
automotive, industrial, telecom and consumer applications.
Examples are:
- Battery chargers
- Power suppliers
- Office equipment
- LCD compensation
B
25/75
value
Tolerance on B
25/85
- value
Operating temperature range
at zero power (intermittent)
- In-car entertainment
NTHS PRODUCT DATA AND
R
25
RESISTANCE RANGE AVAILABILITY
CURVE
3
6
2
10
11
5
1
17
4
B
25/75
(K)
3181
3254
3477
3500
3700
3890
3964
4064
4247
TCR
(%/K)
- 3.70
- 3.60
- 3.83
- 3.90
- 4.00
- 4.30
- 4.40
- 4.54
- 4.68
NTHS0402
(kΩ)
-
-
10 to 12
18 to 25
30 to 34
47 to 50
68 to 100
250
350
80
2.0
NTHS0603
(kΩ)
1 to 2
2.5 to 4.7
6.8 to 12
12 to 20
22 to 32
38 to 57
50 to 100
150 to 220
250 to 350
125
3.0
NTHS0805
(kΩ)
1 to 1.5
2 to 3.3
4.7 to 10
6 to 12
15 to 30
35 to 50
33 to 78
100 to 200
200 to 300
210
3.5
NTHS1206
(kΩ)
1 to 2
2.7 to 3.5
6 to 10
10 to 20
20 to 33
30 to 44
38 to 100
100 to 220
200 to 330
280
4.0
R
25
± TOL.
AVAILABILITY
5, 10
5, 10
3, 5, 10
3, 5, 10
3, 5, 10
3, 5, 10
1, 2, 3, 5, 10
3, 5, 10
3, 5, 10
Maximum dissipation at 25 °C in mW
Dissipation factor in mW/K
Note
• Typical resistance vs. temperature conversion data can be found at
www.vishay.com/doc?33011
Document Number: 33008
Revision: 29-Apr-10
For technical questions, contact:
thermistor1@vishay.com
www.vishay.com
39
NTHS
Vishay Dale
NTC Thermistors, SMD Chip
GLOBAL PART NUMBER INFORMATION
Global Part Numbering: NTHS1206N02N1002JE (preferred part number format)
N
T
H
S
1
2
0
6
N
0
2
N
1
0
0
2
J
E
GLOBAL
MODEL
NTHS0402
NTHS0603
NTHS0805
NTHS1206
CONDUCTOR
TYPE
Nickel barrier
CURVE
01
02
03
04
05
06
10
11
17
CHARACTERISTIC
N
RESISTANCE
VALUE
1002
= 10K
TOLERANCE
CODE
F
=±1%
G
=±2%
H
=±3%
J
=±5%
K
= ± 10 %
PACKAGING
F
= Lead (Pb)-free,
bulk
E
= Lead (Pb)-free,
T/R (2K, full)
U
= Lead (Pb)-free,
T/R (5K, full)
P
= Tin/lead,
bulk
R
= Tin/lead,
T/R (2K, full)
G
= Tin/lead,
T/R (5K, full)
DIMENSIONS
in inches (millimeters)
BW
L
W
PART NUMBER
NTHS0402
L
0.040 ± 0.004
(1.016 ± 0.102)
0.063 ± 0.008
(1.6 ± 0.20)
0.079 ± 0.008
(2.00 ± 0.20)
0.126 ± 0.008
(3.20 ± 0.20)
W
0.022 ± 0.006
(0.5 ± 0.051)
0.031 ± 0.008
(0.80 ± 0.20)
0.049 ± 0.008
(1.25 ± 0.20)
0.063 ± 0.008
(1.60 ± 0.20)
BW
0.010 ± 0.004
(0.25 ± 0.102)
0.010 ± 0.006
(0.25 ± 0.15)
0.012 ± 0.006
(0.30 ± 0.15)
0.018 ± 0.008
(0.46 ± 0.20)
NTHS0603
NTHS0805
NTHS1206
Note
• Thickness of the part is depending on size and resistance value. Please consult the factory for more information on individual types at
thermistor1@vishay.com
www.vishay.com
40
For technical questions, contact:
thermistor1@vishay.com
Document Number: 33008
Revision: 29-Apr-10
