Speci cation Summary
Capacitance Range
0.001µF to 20.0µF
Capacitance Tolerance
Standard tolerance is ±10%. Tolerances of ±5%,±2% and ±1%
are available.
Operating Temperature Range
-55°C to +125°C
Enclosure/ Construction
Extended metallized polycarbonate
lm (non-inductive).
Quality Control
Capacitors are tested 100% for:
o Capacitance
o Tolerance
o Dissipation Factor
o Dielectric withstanding voltage
o Insulation Resistance
o Equivalent Series Resistance (ESR)
Process and inspection data are maintained on le and available
on special request.
Environmental
Parameter
Vibration
Immersion
Shock
Humidity
Thermal Shock
Life
Method
204
104
213
106
107
108
Condition
D
B
I
-
A
F
Voltage Rating
DC working voltage ratings at +125°C, 50VDC, 100VDC, and
200VDC.
Reference MIL-STD-202
Characteristics
Insulation Resistance
Temperature(°C)
25
Megaohmsx
50,000
Microfarads
85
5,000
125
500
Capacitance Change
Temperature(°C)
-55
PercentageChange
-2.5
(typical)
25
0
85
±1.0
125
±2.0
Insulation Resistance
CapacitanceChange
Dissipation Factor
When measured at 1kHz, the dissipation factor shall not exceed
0.3% from +25°C to +125°C.
Dielectric Strength
Capacitors withstand a DC potential of 200% rated
voltage for two (2) minutes without damage or
breakdown. Test voltage must be applied and
discharged through a resistance of 1 OHM per volt.
minimum, and at 25°C.
Rev. 2
ADDITIONAL
INFORMATION
Polycarbonate lm capacitors are the superior choice for a wide range of electronic applications. That's
why they've gained such broad acceptance and the rst choice of circuit designers for decades. Now
we're being told, that no longer is anyone going to produce the right grade of polycarbonate lm. And
once existing inventories are gone, well, these polycarbonate capacitors will be a thing of the past. NOT
TRUE! We produce our own polycarbonate lm in house. We always have, and we plan to continue to be
a source. So, now you don't have to make that change, or be forced to settle for a substitute capacitor
that doesn't o er the combined advantages of performance, reliability, compact size and cost!
Type MC12 is a versatile metallized polycarbonate capacitor o ered in a wrap and ll tubular
con guration with axial leads, designed for the following typical applications:commercial-industrial
including analog and timing circuits, high frequency, and lter networks.
HOW TO ORDER
TYPE
Metallized Polycarbonate Dielectric
MC12
B
106
K
STYLE
DC Voltage Rating: B=50VDC, D=100VDC, F=200VDC, J=400VDC
Expressed in Picofarades, the rst two digits are signi cant gures. The
third is the number of zeros.
/ VOLTAGE
CAPACITANCE
TOLERANCE
IN PICO FARADS
K=±10% Also available: J=±5%, G=±2%, F=±1%
Marking and Date Code
All capacitors are marked with company initials "EC", corporate logo or EC trademark—in addition to type MC12, capacitance,
tolerance, rated DC working voltage and date code. The rst two digits of the date code represent the year, the second two digits the
week, i.e., 0952 is the 52nd week of 2009, 0902 is the second week of 2009.
Quality Assurance
Major emphasis is placed on quality assurance. EC is an ISO 9001-2000 and AS9100:2004 Certi ed Company. Raw material
inspection and the use of SPC manufacturing procedures assure the highest quality standards. Procedures are fully described in the
EC Quality Control Manual. Electronic Concepts will continue to advance the state-of-the-art by utilizing leading edge technology,
compact capacitor designs and establishing reliability procedures.
