SR302 thru SR320
Taiwan Semiconductor
CREAT BY ART
FEATURES
- Low forward voltage drop
- Low power loss, high efficiency
- Guardring for overvoltage protection
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
Schottky Barrier Rectifier
MECHANICAL DATA
Case:
DO-201AD
Molding compound, UL flammability classification rating 94V-0
Base P/N with suffix "G" on packing code - halogen-free
Base P/N with prefix "H" on packing code - AEC-Q101 qualified
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test,
with prefix "H" on packing code meet JESD 201 class 2 whisker test
Weight:
1.1g (approximately)
DO-201AD
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@3A
Maximum reverse current @ rated VR
T
J
=25
℃
T
J
=100℃
T
J
=125
℃
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
0.55
0.5
I
R
dV/dt
R
θJC
R
θJA
T
J
T
STG
- 55 to +125
10
-
5
-
10000
15
50
- 55 to +150
- 55 to +150
0.70
SR
302
20
14
20
SR
303
30
21
30
SR
304
40
28
40
SR
305
50
35
50
SR
306
60
42
60
3
80
0.85
0.1
-
2
V/μs
O
SR
309
90
63
90
SR
310
100
70
100
SR
315
150
105
150
SR
320
200
140
200
UNIT
V
V
V
A
A
0.95
V
mA
Voltage rate of change (Rated V
R
)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
C/W
O
O
C
C
Document Number: D1308007
Version: I13
SR302 thru SR320
Taiwan Semiconductor
CREAT BY ART
ORDERING INFORMATION
PART NO.
AEC-Q101
QUALIFIED
A0
SR3xx
(Note 1)
Prefix "H"
R0
B0
X0
Note 1: "xx" defines voltage from 20V (SR302) to 200V (SR320)
Suffix "G"
PACKING CODE GREEN COMPOUND
CODE
DO-201AD
DO-201AD
DO-201AD
DO-201AD
500 / Ammo box
1,250 / 13" Paper reel
500 / Bulk packing
Forming
PACKAGE
PACKING
EXAMPLE
PREFERRED P/N
SR306 A0
SR306 A0G
SR306HA0
PART NO.
SR306
SR306
SR306
H
AEC-Q101
QUALIFIED
PACKING CODE
A0
A0
A0
G
Green compound
AEC-Q101 qualified
GREEN COMPOUND
CODE
DESCRIPTION
RATINGS AND CHARACTERISTICS CURVES
(TA=25℃ unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD CURRENT (A)
4
PEAK FORWARD SURGE CURRENT
(A)
SR305-SR320
3
80
FIG. 2 MAXIMUM FORWARD SURGE CURRENT
60
8.3ms Single Half Wave
JEDEC Method
2
SR302-SR304
40
1
20
0
0
25
50
75
100
125
150
LEAD TEMPERATURE (
o
C)
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
FIG. 3 TYPICAL FORWARD CHARACTERISTICS
100
INSTANTANEOUS FORWARD CURRENT (A)
INSTANTANEOUS REVERSE CURRENT (mA)
10
FIG. 4 TYPICAL REVERSE CHARACTERISTICS
SR305-SR306
10
SR302-SR304
1
T
J
=125℃
0.1
T
J
=75℃
T
J
=25℃
1
SR315-SR320
0.01
SR309-SR310
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
FORWARD VOLTAGE (V)
0.001
0
20
40
60
80
100
SR302-SR304
SR305-SR320
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Document Number: D1308007
Version: I13
SR302 thru SR320
Taiwan Semiconductor
CREAT BY ART
FIG. 5 TYPICAL JUNCTION CAPACITANCE
1000
SR302-SR304
FIG. 6 TYPICAL TRANSIENT THERMAL IMPEDANCE
100
TRANSIENT THERMAL IMPEDANCE
(℃/W)
JUNCTION CAPACITANCE (pF)
100
10
10
f=1.0MHz
Vslg=50mVp-p
SR315-
SR320
SR305-SR306
1
1
0.1
1
10
100
REVERSE VOLTAGE (V)
0.1
0.01
0.1
1
t-PULSE DURATION (sec)
10
100
PACKAGE OUTLINE DIMENSIONS
Unit (mm)
Min
5.00
1.20
25.40
8.50
25.40
Max
5.60
1.30
-
9.50
-
Unit (inch)
Min
0.197
0.048
1.000
0.335
1.000
Max
0.220
0.052
-
0.375
-
DIM.
A
B
C
D
E
MARKING DIAGRAM
P/N =
G=
F=
Specific Device Code
Green Compound
Factory Code
YWW = Date Code
Document Number: D1308007
Version: I13
SR302 thru SR320
Taiwan Semiconductor
CREAT BY ART
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied,to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or seling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Document Number: D1308007
Version: I13
