BAT54WX
Features
•
•
•
Extremely-Fast Switching Speed
Low Forward Voltage Drop
Case Material: Molded Plastic.
Classification Rating 94V-0
UL Flammability
200mWatt, 30Volt
Schottky Diodes
MARKING:JV
Maxim um Ratings
Symbol
V
RRM
V
RWM
V
R
I
F
R
θ
JA
P
D
T
J
T
STG
I
FRM
I
FSM
Rating
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Forward Current
Thermal Resistance Junction to Ambient
Power dissipation
Junction Temperature
Storage Temperature
Repetitive peak forward current
Peak forward current 9t=1us)
Rating
30
200
635
200
-65 to +150
-65 to +150
300
600
Unit
V
mA
℃/W
mW
℃
℃
mA
mA
SOD-523
A
B
C
E
G
D
F
H
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
V
(BR)
I
R
Parameter
Reverse Breakdown Voltage
Reverse Voltage Leakage
Current
Min
30V
Max
2μA
0.24V
0.50V
0.80V
0.32V
0.40V
10pF
5ns
Test Conditions
I
R
=10μA
V
R
=25V
I
F
=0.1mA
I
F
=30mA
I
F
=100mA
I
F
=1.0mA
I
F
=10mA
V
R
=1V, f=1MHZ
I
rr
=10mA,I
R
=10mA~1
mA
INCHES
DIM
A
B
C
D
E
F
G
H
MIN
.059
.043
.030
.001
.010
.003
.020
.020
MAX
.067
.051
.033
.003
.014
.003
.028
.031
MIN
1.50
1.10
0.75
0.01
0.25
0.08
0.50
0.51
DIMENSIONS
MM
MAX
1.70
1.30
0.85
0.07
0.35
0.15
0.70
0.78
NOTE
V
F
Forward Voltage
C
T
t
rr
Total Capacitance
Reverse Recovery Time
Revision: 2
www.mccsemi.com
1 of 3
2006/05/13
BAT54WX
