RB150 - RB158
PRV : 50 - 800 Volts
Io : 1.5 Amperes
WOM
FEATURES :
B
A
RB15
WOM
3.5± 0.3
5.1± 0.55
B
φ
8.1± 0.2
φ
8 .9± 0.2
*
*
*
*
*
*
*
High surge current capability
High reliability
Low reverse current
Low forward voltage drop
High case dielectric strength of 2000 V
DC
Ideal for printed circuit board
Pb / RoHS Free
A
32.3 MIN
MECHANICAL DATA :
* Case : Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Terminals : Plated lead solderable per
MIL-STD-202, Method 208 guaranteed
* Polarity : Polarity symbols marked on case
* Mounting position : Any
* Weight : 3.4 grams
φ
0 .8± 0.1
4.3
±0
.5
Dimensions in millimeters
MAXIMUM
ambient temperature unless
ELECTRICAL
C
RATINGS AND
otherwise specified
Rating at 25
°
.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
RATING
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current Tc=50°C
Peak Forward Surge Current, Single half sine wave
Superimposed on rated load (JEDEC Method)
Maximum Forward Voltage per Diode at I
F
= 1 A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
Note :
CHARACTERISTICS
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
I
R(H)
R
θ
JL
T
J
T
STG
RB150
50
35
50
RB151
100
70
100
RB152
200
140
200
RB154
400
280
400
RB156
600
420
600
4.3
±
0.5
29.5± 0.5
RB158
800
560
800
UNIT
V
V
V
A
A
V
µA
µA
°C/W
°C
°C
1.5
40
0.95
10
100
15
- 40 to + 140
- 40 to + 140
Ta = 25
°C
Ta = 100
°C
1 ) Thermal resistance from Junction to lead mounted on P.C. Board with 0.47" X 0.47" ( 12mm X 12mm ) Cu pads.
http://www.luguang.cn
mail:lge@luguang.cn
RB150 - RB158
PRV : 50 - 800 Volts
Io : 1.5 Amperes
FIG.1 - DERATING CURVE FOR OUTPUT
RECTIFIED CURRENT
2.0
FIG.2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
40
AVERAGE FORWARD OUTPUT
CURRENT, AMPERES
PEAK FORWARD SURGE
CURRENT, AMPERES
100
120
140
35
30
25
20
15
10
5
0
1.5
1.0
0.5
P.C. Board Mounted with
0.47" X 0.47" ( 12mm X 12mm )
Cu. pads.
0
20
40
60
80
0
1
2
4
6
10
20
40
60
100
CASE TEMPERATURE, (
°
C)
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL FORWARD CHARACTERISTICS
10
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
REVERSE CURRENT, MICROAMPERES
10
PER DIODE
FORWARD CURRENT, AMPERES
T
J
= 100
°C
1.0
1.0
T
J
= 25
°C
0.1
0.1
T
J
= 25
°C
0.01
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
0.01
0
20
40
60
80
100
120
140
FORWARD VOLTAGE, VOLTS
PERCENT OF RATED REVERSE
VOLTAGE, (%)
