Thin-Film Low Pass Filter
LP0805 Type Harmonic
GENERAL DESCRIPTION
The ITF (Integrated Thin-Film) SMD Filter is based on thin-film
multilayer technology. The technology provides a miniature
part with excellent high frequency performance and rugged
construction for reliable automatic assembly.
The ITF Filter is offered in a variety of frequency bands com-
patible with various types of high frequency wireless systems.
DIMENSIONS:
millimeters (inches)
L
W
T
A
B
2.03±0.1
(0.080±0.004)
1.55±0.1
(0.061±0.004)
1.02±0.1
(0.040±0.004)
0.56±0.25
(0.022±0.010)
0.35±0.15
(0.014±0.006)
FEATURES
•
•
•
•
•
•
•
•
Small Size: 0805
Frequency Range: 800MHz - 3.5GHz
Characteristic Impedance: 50Ω
Operating / Storage Temp.: -40°C to +85°C
Power Rating: 3W Continuous
Low Profile
Rugged Construction
Taped and Reeled
PAD LAYOUT
See CP0805 pad layout on page 64.
FINAL QUALITY INSPECTION
Finished parts are 100% tested for electrical parameters and
visual/mechanical characteristics. Each production lot is
evaluated on a sample basis for:
• Static Humidity: 85°C, 85% RH, 160 hours
• Endurance: 125°C, I
R
4 hours
APPLICATIONS
•
•
•
•
•
Mobile Communications
Satellite TV Receivers
GPS
Vehicle Location Systems
Wireless LAN’s
TERMINATION
Nickel/Solder coating (Sn, Pb) compatible with automatic
soldering technologies: reflow, wave soldering, vapor phase
and manual.
4
HOW TO ORDER
LP
Style
Low Pass
0805A
Size
0805
0902
Frequency
MHz
AW
Termination
AW= Nickel/Solder (SnPb)
**AS
= Nickel/ Lead Free
Solder (Sn100)
**RoHS compliant
TR
Packaging Code
TR = Tape and Reel
Not RoHS Compliant
TERMINALS AND LAYOUT (Top View)
Orientation in Tape
TYPE A
TYPE D
TYPE E
LEAD-FREE COMPATIBLE
COMPONENT
For RoHS compliant products,
please select correct termination style.
TYPE F (Sn100)
IN
GND
IN
GND
IN
GND
IN
GND
OUT
GND OUT
GND OUT
GND
A
MARKING
CODE
OUT
GND
110
Thin-Film Low Pass Filter
LP0805 Type Harmonic
ELECTRICAL CHARACTERISTICS
Application
E-GSM
GSM
AMPS
PCN
PCS
PHP
DECT
3G
Wireless LAN
WLL
Part
Number
LP0805A0897AS
LP0805A0942AS
LP0805A0902AS
LP0805A0947AS
LP0805A1119AS
LP0805A0836AS
LP0805A0881AS
LP0805A1747AS
LP0805A1842AS
LP0805A1880AS
LP0805A1960AS
LP0805A1907AS
LP0805A1890AS
LP0805A2150AS
LP0805A2442AS
LP0805A3500AS
Frequency
Band (MHz)
880 - 915
925 - 960
890 - 915
935 - 960
1101 - 1137
824 - 849
869 - 894
1710 - 1785
1805 - 1880
1850 - 1910
1930 - 1990
1895 - 1920
1880 - 1900
1905 - 2180
2400 - 2484
3400 ~ 3600
I. Loss
max
VSWR
max
Attenuation
(dB) Typical
Layout Type
(SnPb)
A
A
A
A
A
A
A
D
D
D
D
D
D
D
D
E
Layout Type F
Marking Code
E
F
E
F
H
A
C
I
J
K
M
L
K
N
S
X
0.4dB
(0.3dB typ)
1.7
30 @ 2XFo
20 @ 3xFo
Typical Electrical Performance
LP0805A0836ASTR
0
-10
-20
dB
dB
-30
-40
-50
-60
-70
0
0.5
1
1.5
2
2.5
3
3.5
4
2Fo
3Fo
Fo
0
-10
-20
dB
-30
-40
-50
-60
-70
0
0.5
1
1.5
2
2.5
3
3.5
4
2Fo
3Fo
Fo
LP0805A0881ASTR
0
-10
-20
-30
-40
-50
-60
-70
0
0.5
1
Fo
LP0805A0902ASTR
3Fo
2Fo
4
2.5
3
3.5
4
1.5
2
Frequency (GHz)
Frequency (GHz)
Frequency (GHz)
LP0805A0967ASTR
0
-10
-20
dB
dB
-30
-40
-50
-60
-70
0
0.5
1
1.5
2
2.5
3
3.5
4
2Fo
3Fo
Fo
0
-10
-20
Fo
LP0805A1747ASTR
0
Fo
-10
-20
dB
3Fo
-30
LP0805A1842ASTR
-30
-40
-50
2Fo
-60
-70
0
1
2
3
4
5
3Fo
-40
-50
-60
2Fo
6
7
8
9
10
-70
0
1
2
3
4
5
6
7
8
9
10
Frequency (GHz)
Frequency (GHz)
Frequency (GHz)
LP0805A1950ASTR
0
Fo
-10
-20
dB
dB
-30
-40
-50
-60
-70
0
1
2
3
2Fo
3Fo
-10
-20
0
Fo
LP0805A2442ASTR
0
-10
-20
3Fo
dB
-30
-40
-50
2Fo
-60
6
7
8
9
10
-70
0
1
2
3
4
Fo
LP0805A3500ASTR
-30
-40
-50
-60
3Fo
2Fo
4
5
6
7
8
9
10
-70
0
1
2
3
4
5
5
6
7
8
9
10
11
12
13
Frequency (GHz)
Frequency (GHz)
Frequency (GHz)
LP0805A1119ASTR
0
-10
-20
dB
2Fo
dB
-30
-40
-50
-60
-70
0
0.5
1
1.5
2
2.5
3
3.5
4
3Fo
Fo
0
-10
-20
-30
-40
-50
-60
-70
0
1
2
Fo
LP0805A2150ASTR
3Fo
2Fo
3
4
5
6
7
8
9
10
Frequency (GHz)
Frequency (GHz)
111
Thin-Film Low Pass Filter
LP0805 Test Jig
ITF TEST JIG FOR LOW PASS FILTER 0805
GENERAL DESCRIPTION
These jigs are designed for testing the LPF0805 Low Pass
Filters using a Vector Network Analyzer.
They consist of a dielectric substrate, having 50W microstrips
as conducting lines and a bottom ground plane located at a
distance of 0.254 mm from the microstrips.
The substrate used is RF-35-0100-C1B107 (or similar).
The connectors are SMA type (female), ‘Johnson
Components Inc.’ Product P/N: 142-0701-841(or similar).
Both a measurement jig and a calibration jig are provided.
The calibration jig is designed for a full 2-port calibration, and
consists of an open line, short line and through line. LOAD
calibration can be done by a 50W SMA termination.
MEASUREMENT PROCEDURE
Follow the VNA’s instruction manual and use the
calibration
jig
to perform a full 2-Port calibration in the required band-
widths.
Solder the filter to the
measurement jig
as follows:
Input
²
Connector 1 (Jig)
GND (Filter)
²
GND (Jig)
(Filter)
Output
²
Connector 2 (Jig)
GND (Filter)
²
GND (Jig)
(Filter)
Set the VNA to the relevant frequency band. Connect the
VNA using a 10dB attenuator on the jig terminal connected
to port 2 (using an RF cable).
Measurement
Calibration Jig
Connector 1
Short line to
GND
Open
line
4
Connector 2
Connector
Johnson
P/N 142-0701-841
Load
Through
Load
Through
112
