UNISONIC TECHNOLOGIES CO., LTD
82CXX
VOLTAGE DETECTORS
3
CMOS IC
DESCRIPTION
The UTC
82CXX
series are good performance 3-terminals
voltage detectors and manufactured by CMOS technologies
with highly accurate, low power consumption. The detection
voltage is extremely accurate with minimal temperature drift.
2
1
1
SOT-23
TO-92
FEATURES
*High-accuracy detection voltage : ± 2%
*Detect voltage range : 0.9V to 6.2V in 0.1V increments
*Detect voltage temperature characteristics: TYP.±100ppm/°С.
*Wide operating voltage range : 0.7V to 10.0V
*Low current consumption : TYP 0.7μA(at V
IN
=1.5V)
1
SOT-89
Lead-free:
82CXXL
Halogen-free: 82CXXG
ORDERING INFORMATION
Normal
82Cxx-AB3-D-R
82Cxx-AB3-E-R
82Cxx-AE3-5-R
82Cxx-T92-D-B
82Cxx-T92-D-K
82Cxx-T92-E-B
82Cxx-T92-E-K
Ordering Number
Lead Free
82CxxL-AB3-D-R
82CxxL-AB3-E-R
82CxxL-AE3-5-R
82CxxL-T92-D-B
82CxxL-T92-D-K
82CxxL-T92-E-B
82CxxL-T92-E-K
Halogen-Free
82CxxG-AB3-D-R
82CxxG-AB3-E-R
82CxxG-AE3-5-R
82CxxG-T92-D-B
82CxxG-T92-D-K
82CxxG-T92-E-B
82CxxG-T92-E-K
Package
SOT-89
SOT-89
SOT-23
TO-92
TO-92
TO-92
TO-92
Pin Assignment
1
2
3
I
G
O
O
I
G
G
O
I
I
G
O
I
G
O
O
I
G
O
I
G
Packing
Tape Reel
Tape Reel
Tape Reel
Tape Box
Bulk
Tape Box
Bulk
Note: 1. Pin assignment: I:V
IN
O:V
OUT
G:V
SS
2.xx: Output Voltage, refer to Marking Information
www.unisonic.com.tw
Copyright © 2008 Unisonic Technologies Co., Ltd
1 of 20
QW-R119-010,E
82CXX
MARKING INFORMATION
PACKAGE
VOLTAGE CODE
35:3.5V
09:0.9V
36:3.6V
10:1.0V
37:3.7V
11:1.1V
38:3.8V
12:1.2V
39:3.9V
13:1.3V
40:4.0V
14:1.4V
41:4.1V
15:1.5V
42:4.2V
16:1.6V
43:4.3V
17:1.7V
44:4.4V
18:1.8V
45:4.5V
19:1.9V
46:4.6V
20:2.0V
47:4.7V
21:2.1V
48:4.8V
22:2.2V
49:4.9V
23:2.3V
50:5.0V
24:2.4V
51:5.1V
25:2.5V
52:5.2V
26:2.6V
53:5.3V
27:2.7V
54:5.4V
28:2.8V
55:5.5V
29:2.9V
56:5.6V
30:3.0V
57:5.7V
31:3.1V
58:5.8V
32:3.2V
59:5.9V
33:3.3V
60:6.0V
34:3.4V
62:6.2V
MARKING
CMOS IC
Pin Code
Date Code
C:CMOS
SOT-89
82CXXX
1
2
3
L: Lead Free
L: Halogen Free
Voltage Code
TO-92
SOT-23
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 20
QW-R119-010,E
82CXX
MARKING CODE FOR SOT-23
PART
NUMBER
82C09
82C10
82C11
82C12
82C13
82C14
82C15
82C16
82C17
82C18
82C19
82C20
82C21
82C22
82C23
82C24
82C25
82C26
82C27
82C28
82C29
82C30
82C31
82C32
82C33
82C34
82C35
DETECT VOLATGE
VOLTAGE
0.9V
1.0V
1.1V
1.2V
1.3V
1.4V
1.5V
1.6V
1.7V
1.8V
1.9V
2.0V
2.1V
2.2V
2.3V
2.4V
2.5V
2.6V
2.7V
2.8V
2.9V
3.0V
3.1V
3.2V
3.3V
3.4V
3.5V
CODE
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
MARKING
CODE
L09
L10
L11
L12
L13
L14
L15
L16
L17
L18
L19
L20
L21
L22
L23
L24
L25
L26
L27
L28
L29
L30
L31
L32
L33
L34
L35
PART
NUMBER
82C36
82C37
82C38
82C39
82C40
82C41
82C42
82C43
82C44
82C45
82C46
82C47
82C48
82C49
82C50
82C51
82C52
82C53
82C54
82C55
82C56
82C57
82C58
82C59
82C60
82C62
DETECT VOLATGE
VOLTAGE
3.6V
3.7V
3.8V
3.9V
4.0V
4.1V
4.2V
4.3V
4.4V
4.5V
4.6V
4.7V
4.8V
4.9V
5.0V
5.1V
5.2V
5.3V
5.4V
5.5V
5.6V
5.7V
5.8V
5.9V
6.0V
6.2V
CODE
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
62
CMOS IC
MARKING
CODE
L36
L37
L38
L39
L40
L41
L42
L43
L44
L45
L46
L47
L48
L49
L50
L51
L52
L53
L54
L55
L56
L57
L58
L59
L60
L62
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 20
QW-R119-010,E
82CXX
BLOCK DIAGRAM
CMOS IC
V
IN
+
-
V
REF
V
OUT
Vss
TYPICAL APPLICATION CIRCUITS
V
IN
V
IN
Vss
V
OUT
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 20
QW-R119-010,E
82CXX
ABSOLUTE MAXIMUM RATINGS
(Ta=25°С, unless otherwise specified.)
PARAMETER
SYMBOL
V
IN
I
OUT
V
OUT
CMOS IC
RATINGS
UNIT
Input Voltage
12
V
Output Current
50
mA
Output Voltage
Vss-0.3 ~ VIN+0.3
V
SOT-23
150
Power Dissipation
P
D
mW
SOT-89
500
TO-92
300
Operating Temperature
T
OPR
-40 ~ +85
°С
Storage Temperature
T
STG
-40 ~ +150
°С
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS
(Ta=25°С, unless otherwise specified.)
PARAMETER
Detect Voltage(Note 2)
Hysteresis Range
SYMBOL
V
DF
V
HYS
CIRCUIT
1
1
TEST CONDITONS
MIN
V
DF
×0.98
TYP
V
DF
0.7
0.8
0.9
1.0
1.1
MAX
V
DF
×1.02
V
DF
×0.08
V
DF
×0.02 V
DF
×0.05
UNIT
V
V
Supply Current
I
SS
2
Operating Voltage
Output Current
(V
DF
≦
1.5V)
V
IN
I
OUT
1
3
4
V
IN
=1.5V
V
IN
=2.0V
V
IN
=3.0V
V
IN
=4.0V
V
IN
=5.0V
V
DF(T)
=0.9V ~ 1.5V
V
DF(T)
=1.6V ~ 6.2V
N-ch, V
DS
=0.5V
V
IN
=0.7V
V
IN
=1.0V
P-ch, V
DS
=2.1V, V
IN
=6.0V
V
IN
=1.0V
V
IN
=2.0V
N-ch, V
DS
=0.5V V
IN
=3.0V
V
IN
=4.0V
V
IN
=5.0V
P-ch, V
DS
=2.1V, V
IN
=8.0V
-40°С≤T
OPR
≤85°С
0.7
0.7
0.1
0.85
1.0
3.0
5.0
6.0
7.0
2.3
2.7
3.0
3.2
3.6
6
10
μA
V
V
mA
0.8
2.7
-7.5
2.2
7.7
10.1
11.5
13.0
-10.0
±100
0.2
-2
-1.5
mA
Output Current
(V
DF
≧
1.6V)
I
OUT
3
mA
4
Temperature Characteristics
Transient Delay Time
△V
DF
△T
OPR
·V
DF
t
DLY
5
mA
ppm/
°С
ms
Note:1. Detect voltage of ±1% tolerance is also available per customer’s request.
2. V
DF(T)
: Established Detect Voltage Value
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 20
QW-R119-010,E
