www.amccaps.com
H
IGH
T
EMPERATURE
S
URFACE
M
OUNT
C
APACITORS
K
EY
F
EATURES
• For Use at Temperatures Up to 200°C
• Rated Working Voltages from 50V to 200V
• MLC Designs Utilizing Military Grade Ceramics
• Custom Sizes, Values, and Voltages Available
A
PPLICATIONS
• For Use in High Temperature Applications, Such as:
- Oil Well Logging (Downhole)
- Geophysical Probes
- Jet Engine Controls
C
APACITANCE
/ V
OLTAGE
S
ELECTION
Case
Size
T15
T18
T41
T43
T49
T48
50 V
1500 pF
3900 pF
4700 pF
0.022
µF
0.056
µF
0.075
µF
NPO Max Capacitance
100 V
1000 pF
2200 pF
3300 pF
0.010
µF
0.039
µF
0.056
µF
200 V
470.0 pF
1000 pF
2200 pF
4700 pF
0.033
µF
0.039
µF
50 V
0.018
µF
0.039
µF
0.120
µF
0.270
µF
0.750
µF
1.000
µF
X7R Max Capacitance
100 V
8200 pF
0.022
µF
0.056
µF
0.150
µF
0.390
µF
0.560
µF
200 V
3900 pF
0.010
µF
0.027
µF
0.075
µF
0.220
µF
0.270
µF
D
IELECTRIC
C
HARACTERISTICS
TEMPERATURE COEFFICIENT:
CAP DROP AT 200°C:
DISSIPATION FACTOR:
INSULATION RESISTANCE:
@25°C
INSULATION RESISTANCE:
@200°C
DIELECTRIC STRENGTH:
TEST PARAMETERS:
2
NPO DIELECTRIC
0 ± 30 ppm, -55 to 125°C
minus 0.5% max
.001 (0.1%) max, 1Khz, 25°C
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC
1
ΩF
or 100 MΩ, whichever is
less @ 200°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
X7R DIELECTRIC
0 ± 15% ,-55 to 125°C
minus 45% max
.025 (2.5%) max, 1KHz, 25°C
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC
1ΩF or 100 MΩ, whichever is
less @ 200°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
www.amccaps.com
M
ECHANICAL
C
HARACTERISTICS
Size
Code
T15 / 0805
T18 / 1206
T41 / 1210
T43 / 1812
T49 / 1825
T48 / 2225
mm.
1.27
1.27
1.65
2.16
2.79
2.79
T (max)
In.
0.050
0.050
0.065
0.085
0.110
0.110
W (± 10%*)
mm.
1.27
1.57
2.41
3.18
6.35
6.35
In.
0.050
0.062
0.095
0.125
0.250
0.250
L (± 10%*)
mm.
2.03
3.18
3.18
4.45
4.57
5.72
In.
0.080
0.125
0.125
0.175
0.180
0.225
0.64
0.025 ± 0.015
0.51
0.020 ± 0.010
mm.
E/B
In.
* Note: L and W tolerances are
± 10% or 0.010”, whichever is larger
W
L
T
E/B
H
OW TO
O
RDER
101
VOLTAGE***
500 = 50 V
101 = 100 V
201 = 200 V
T15
CASE SIZE
See Chart
N
DIELECTRIC
N = NPO
W = X7R
102
CAPACITANCE
1st two digits are
significant; third digit
denotes number of
zeros.
101 = 100 pF
102 = 1000 pF
103 = 0.01 µF
104 = 0.10 µF
105 = 1.00 µF
J
TOLERANCE
J = ± 5% **
K = ± 10%
M = ± 20%
** (NPO Only)
Y
TERMINATION
Y = Palladium-Silver
V = Tinned Ni-Barrier
4
S
PART MODIFIER
S = Special Part
MARKING
4 = Unmarked
3 = Specified
6 = EIA 2-digit code
***Working Voltage (WVDC) is derated 50% at 200°C (see example)
Example Part number written: 101T15N102JY4 = Rated 100 VDC@125°C, 50VDC@200°C 1000pF ± 5% NPO in T15 (0805) size.
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
3
