52596EV40M6

Description
2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Blue
File Size40KB,2 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Download Datasheet Compare View All

52596EV40M6 Overview

2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Blue

This document was generated on 05/21/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
98982-1026
Active
MOX Products
2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Blue
Documents:
3D Model
Drawing (PDF)
Application Specification AS-98982-001 (PDF)
Packaging Specification PK-98982-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
General
Product Family
Series
Application
Application Tooling Part Link
Application Tooling Part Link
Overview
Product Name
UPC
Crimp Housings
98982
Power, Wire-to-Board
63813-8300
63813-8400
MOX Products
MOX
822348817252
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Physical
Circuits (maximum)
Circuits Detail
Color - Resin
Gender
Glow-Wire Compliant
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Ports
Stackable
Temperature Range - Operating
40
40
Blue
Receptacle
No
None
Yes
Polyester
8.350/g
4
Bag
No
2.54mm
2.54mm
Yes
1
No
-40°C to +125°C
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
98982Series
Mates With
Please Contact Molex for Details
Use With
98658 MOX Crimp Terminal
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Extractor Tool for
0638138300
MOX, 0.63mm
Receptacle Crimp
Terminals
Extractor Tool for
0638138400
MOX, 0.63mm
Electrical
Current - Maximum per Contact
6A
Material Info
Old Part Number
52596EV40M6
Reference - Drawing Numbers
Application Specification
Packaging Specification
Sales Drawing
AS-98982-001
PK-98982-001
SD-98982-002

52596EV40M6 Related Products

52596EV40M6 98982-1026
Description 2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Blue 2.54mm Pitch MOX Receptacle Kit, 4 Rows, 40 Circuits, Blue
