Crystal Oscillator
FXO-37F
Miniature Clock Crystal Oscillator
■
Features
¡It
is a compact and thin ceramic package with a metalized lead for surface mounting
that is able to be automatically loaded.
¡Reflow
soldering is possible.
¡CMOS,
TTL IC direct drive is possible. Depending upon the frequency band, there
is also a crystal oscillator with a CMOS IC with a tri-state function built in.
¡Use
in the broad frequency band from 50MHz to 125MHz is possible. (PLL circuit is
built in).
Original Size
■
Specifications
Item
Application
Frequency Range
Standard Frequency
Frequency Stability
Operating Temperature Range
Storage Temperature Range
Supply Voltage
Current
Load
Output Level
Output Symmetry
Rise Time/Fall Time
Start-up Time
Vibration
Shock
Weight
※Taping
item packaging : one unit 3,000 pcs or 1,000 pcs
10ms MAX.
5±0.25V
50mA MAX.
25pF(10TTL)
15pF(5TTL)
Type
FXO-37F
C-MOS Output
50~100MHz
100~125MHz
Table 1
±100×10
−
6
0 ~+70:
−20~+80:
3.3±0.15V
25mA MAX.
15pF(5TTL)
V
OH
: 2.8V MIN.
V
OL
: 0.5V MAX.
FXO-37FL
Low Voltage Type
50~100MHz
■
Table１
Standard Frequencies
Frequency (MHz)
50.000
60.000
64.000
65.000
66.667
67.700
70.000
75.000
75.525
80.000
90.3168
V
OH
: 4.0V MIN./V
OL
: 0.5V MAX.
40~60% (VT=1/2V
DD
)
7ns MAX.
15ms MAX.
94.410
100.000
106.250
120.000
10~55Hz Ampulitude 1.5mm, Cycle 2 minute, 3 direction, 2 hour each
1000G
0.2g
■
Outline
FXO-37F
#4
#3
■
Land Pattern(reference)
100.000
KSS 4G
#1
#2
5.0±0.2
1.8
1.8±0.2
7.0±0.2
6.2±0.2
2.0
1.2 0.6
5.08±0.2
1.4
0.6
CONNECTION
1:INH
2:GND
3:OUTPUT
4:V
DD
INH:Hi:Fout
Low:Output-Stop
(High Z)
2.6
5.08
4.2
Dimensions(mm)
- 48 -
