High Efficacy
VIOLET LED Emitter
LZ1-00UA00
Key Features
High Efficacy 5W VIOLET LED
Ultra-small foot print – 4.4mm x 4.4mm
Surface mount ceramic package with integrated glass lens
Very low Thermal Resistance (4.2°C/W)
Electrically neutral thermal path
Very high Radiant Flux density
Autoclave (121°C, 2 ATM, 100% RH, 168 Hours)
JEDEC Level 1 for Moisture Sensitivity Level
Lead (Pb) free and RoHS compliant
Reflow solderable (up to 6 cycles)
Emitter available on Standard or Miniature MCPCB (optional)
Typical Applications
Dental Curing and Teeth Whitening
Ink and adhesive curing
Sterilization and Medical
DNA Gel
Description
The LZ1-00UA00 VIOLET LED emitter provides superior radiometric power in the wavelength range specifically
required for sterilization, dental curing lights, and numerous medical applications. With a 4.4mm x 4.4mm ultra-
small footprint, this package provides exceptional optical power density. The radiometric power performance and
optimal peak wavelength of this LED are matched to the response curves of dental resins, inks and adhesives,
resulting in a significantly reduced curing time. The patented design has unparalleled thermal and optical
performance. The high quality materials used in the package are chosen to optimize light output, have excellent
VIOLET resistance, and minimize stresses which results in monumental reliability and radiant flux maintenance.
UV RADIATION
Avoid exposure to the beam
Wear protective eyewear
COPYRIGHT © 2013 LED ENGIN. ALL RIGHTS RESERVED.
LZ1-00UA00 (5.4 – 11/18/13)
LED Engin
|
651 River Oaks Parkway
|
San Jose, CA 95134 USA
|
ph
+1 408 922 7200
|
fax
+1 408 922 0158
|
em
sales@ledengin.com
|
www.ledengin.com
Part number options
Base part number
Part number
LZ1-00UA00-xxxx
LZ1-10UA00-xxxx
LZ1-30UA00-xxxx
Description
LZ1 emitter
LZ1 emitter on Standard Star MCPCB
LZ1 emitter on Miniature round MCPCB
COPYRIGHT © 2013 LED ENGIN. ALL RIGHTS RESERVED.
2
LZ1-00UA00 (5.4 – 11/18/13)
LED Engin
|
651 River Oaks Parkway
|
San Jose, CA 95134 USA
|
ph
+1 408 922 7200
|
fax
+1 408 922 0158
|
em
sales@ledengin.com
|
www.ledengin.com
Bin kit option codes
Full distribution wavelength (385-410nm)
Kit number suffix
0000
J000
K000
L000
Min flux Bin
H
J
K
L
Color Bin Range
U4 - U8
U4 - U8
U4 - U8
U4 - U8
Description
full distribution flux; full distribution wavelength
J minimum flux bin; full distribution wavelength
K minimum flux bin; full distribution wavelength
L minimum flux bin; full distribution wavelength
Two wavelength bins (10nm range)
Kit number suffix
Min flux Bin
Color Bin Range
Description
Wavelength U4 and U5 bin (385 – 395nm)
0U45
JU45
KU45
LU45
H
J
K
L
U4 - U5
U4 – U5
U4 – U5
U4 – U5
full distribution flux; wavelength U4 and U5 bin
J minimum flux bin; wavelength U4 and U5 bins
K minimum flux bin; wavelength U4 and U5 bins
L minimum flux bin; wavelength U4 and U5 bins
Wavelength U5 and U6 bin (390 – 400nm)
0U56
JU56
KU56
LU56
H
J
K
L
U5 - U6
U5 - U6
U5 - U6
U5 - U6
full distribution flux; wavelength U5 and U6 bin
J minimum flux bin; wavelength U5 and U6 bins
K minimum flux bin; wavelength U5 and U6 bins
L minimum flux bin; wavelength U5 and U6 bins
Wavelength U6 and U7 bin (395 – 405nm)
0U67
JU67
KU67
LU67
H
J
K
L
U6 - U7
U6 - U7
U6 - U7
U6 - U7
full distribution flux; wavelength U6 and U7 bin
J minimum flux bin; wavelength U6 and U7 bins
K minimum flux bin; wavelength U6 and U7 bins
L minimum flux bin; wavelength U6 and U7 bins
Wavelength U7 and U8 bin (400 – 410nm)
0U78
JU78
KU78
LU78
H
J
K
L
U7 - U8
U7 - U8
U7 - U8
U7 - U8
full distribution flux; wavelength U7 and U8 bin
J minimum flux bin; wavelength U7 and U8 bins
K minimum flux bin; wavelength U7 and U8 bins
L minimum flux bin; wavelength U7 and U8 bins
COPYRIGHT © 2013 LED ENGIN. ALL RIGHTS RESERVED.
3
LZ1-00UA00 (5.4 – 11/18/13)
LED Engin
|
651 River Oaks Parkway
|
San Jose, CA 95134 USA
|
ph
+1 408 922 7200
|
fax
+1 408 922 0158
|
em
sales@ledengin.com
|
www.ledengin.com
Single wavelength bin (5nm range)
Kit number suffix
Min flux Bin
Color Bin Range
Description
Wavelength U4 bin only (385 – 390nm)
00U4
H
U4
full distribution flux; wavelength U4 bin only
Wavelength U5 bin only (390 – 395nm)
00U5
J0U5
K0U5
L0U5
H
J
K
L
U5
U5
U5
U5
full distribution flux; wavelength U5 bin only
J minimum flux bin; wavelength U5 bin only
K minimum flux bin; wavelength U5 bin only
L minimum flux bin; wavelength U5 bin only
Wavelength U6 bin only (395 – 400nm)
00U6
J0U6
K0U6
L0U6
H
J
K
L
U6
U6
U6
U6
full distribution flux; wavelength U6 bin only
J minimum flux bin; wavelength U6 bin only
K minimum flux bin; wavelength U6 bin only
L minimum flux bin; wavelength U6 bin only
Wavelength U7 bin only (400 – 405nm)
00U7
J0U7
K0U7
L0U7
H
J
K
L
U7
U7
U7
U7
full distribution flux; wavelength U7 bin only
J minimum flux bin; wavelength U7 bin only
K minimum flux bin; wavelength U7 bin only
L minimum flux bin; wavelength U7 bin only
Wavelength U8 bin only (405 – 410nm)
00U8
J0U8
K0U8
L0U8
H
J
K
L
U8
U8
U8
U8
full distribution flux; wavelength U8 bin only
J minimum flux bin; wavelength U8 bin only
K minimum flux bin; wavelength U8 bin only
L minimum flux bin; wavelength U8 bin only
Notes:
1.
Default bin kit option is -0000
COPYRIGHT © 2013 LED ENGIN. ALL RIGHTS RESERVED.
4
LZ1-00UA00 (5.4 – 11/18/13)
LED Engin
|
651 River Oaks Parkway
|
San Jose, CA 95134 USA
|
ph
+1 408 922 7200
|
fax
+1 408 922 0158
|
em
sales@ledengin.com
|
www.ledengin.com
Radiant Flux Bins
Table 1:
Bin Code
Minimum
Radiant Flux
(Φ)
@ I
F
= 700mA
[1,2]
(mW)
410
512
640
800
1000
Maximum
Radiant Flux
(Φ)
@ I
F
= 700mA
[1,2]
(mW)
512
640
800
1000
1250
H
J
K
L
M
Notes for Table 1:
1.
Radiant flux performance guaranteed within published operating conditions. LED Engin maintains a tolerance of ± 10%
on flux measurements.
2.
Future products will have even higher levels of radiant flux performance. Contact LED Engin Sales for updated information.
Peak Wavelength Bins
Table 2:
Bin Code
Minimum
Peak Wavelength (λ
P
)
@ I
F
= 700mA
[1]
(nm)
385
390
395
400
405
Maximum
Peak Wavelength (λ
P
)
@ I
F
= 700mA
[1]
(nm)
390
395
400
405
410
U4
U5
U6
U7
U8
Notes for Table 2:
1.
LED Engin maintains a tolerance of ± 2.0nm on peak wavelength measurements.
Forward Voltage Bins
Table 3:
Bin Code
Minimum
Forward Voltage (V
F
)
@ I
F
= 700mA
[1]
(V)
3.20
Maximum
Forward Voltage (V
F
)
@ I
F
= 700mA
[1]
(V)
4.40
0
Notes for Table 3:
1.
LED Engin maintains a tolerance of ± 0.04V for forward voltage measurements.
