RE-L
SERIES
Features
●
Rated voltage 275Vac (UL, CSA 250V).
●
IEC/EN 60384-14 class X2.
NOISE SUPPRESSION CAPACITOR
Applications
●
Designed mainly for suppressing noise occurring
in power line of electrical appliances.
●
Dimensions
Safety Standard
UL
:UL-60384-14
cUL
:CSA E60384-14
CSA
:CSA E60384-14, C22.2 No.8
VDE
:IEC/EN 60384-14
SEMKO
:IEC/EN 60384-14
NEMKO
:IEC/EN 60384-14
DEMKO
:IEC/EN 60384-14
FIMKO
:IEC/EN 60384-14
Electrosuisse :IEC/EN 60384-14
:IEC/EN 60384-14
ENEC
File No.
E47474
E47474
LR37404, LR104926
094750X
1303400, 916932
P08208949, P10211810
144191-01, 315279-01
FI 24150A2, FI 25644
13.0339, 13.0068
40028657
The "ENEC" mark is a common European product certification
mark based on testing to harmonised European safety standard.
The mark with #10 stands for VDE.
W±0.5
T±0.5
Before change to markings
H±0.5
●
Circuit
F±1.0
30min.
φ
d±0.05
Unit: mm
After change to markings
●
Model numbering system
R E
Series name
Capacitance
L
Supported mark
L
lead length 30mm min.
Electrical Specifications
Safety
Standard
Class
Model
Number
RE103-L
RE153-L
RE223-L
RE333-L
RE473-L
RE683-L
RE104-L
RE154-L
RE224-L
RE334-L
RE474-L
RE684-L
RE105-L
RE155-L
RE225-L
Capacitance
μF±10%
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
W
12.0
Dimensions
H
T
F
10.5
11.5
11.0
17.0
12.0
15.0
16.0
17.5
19.0
21.0
23.0
27.5
30.5
4.5
5.5
5.0
6.0
8.0
9.0
8.0
9.5
10.5
12.5
17.0
20.5
15.0
10.0
Rated Voltage
d
275Vac (UL, CSA: 250V)
Test Voltage
Insulation
Resistance
Dissipation
Factor
0.6
C≤1μF
0.003max.
(f=10kHz)
C>1μF
0.002max.
(f=1kHz)
Line to Line
1,250Vac
50/60Hz 60sec
Line to Case
2,000Vac
50/60Hz 60sec
X2
Line to Line
103~334
15,000MΩmin.
474~225
5,000Ω•Fmin.
Line to Case
100,000MΩmin.
(at 100Vdc)
25.5
22.5
0.8
27.5
30.5
Operating Temperature: -55~+100°C
15
SUPPRESSION CAPACITORS
