MCC
TM
Micro Commercial Components
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
SF31G
THRU
SF38G
3 Amp High
Efficiency Glass
•
Features
•
•
•
•
•
•
•
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
Low power loss, high efficiency
Low Forward Voltage Drop and Low Leakage
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
Passivated Rectifier
50 to 600 Volts
DO-201AD
Maximum Ratings
Operating Temperature: -65°C to +150°C
Storage Temperature: -65°C to +150°C
MCC
Device
Maximum
Maximum
Catalog
Marking
Reccurrent
RMS
Number
Peak Reverse
Voltage
Voltage
SF31G
SF31G
50V
35V
SF32G
SF32G
100V
70V
SF34G
SF34G
200V
140V
SF35G
SF35G
300V
210V
SF36G
SF36G
400V
280V
SF38G
SF38G
600V
420V
Maximum
DC
Blocking
Voltage
50V
100V
200V
300V
400V
600V
D
A
Cathode
Mark
B
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward
Current
Surge
D
I
F(AV)
I
FSM
3A
T
A
= 55°C
8.3ms, half sine
C
125A
Maximum Instantaneous
Forward Voltage
SF31G-35G
SF36G
SF38G
V
F
0.95V
1.27V
1.75V
I
FM
= 3.0A;
T
A
= 25°C
DIMENSIONS
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Maximum Reverse
Recovery
Tim e
I
R
5
µA
50
µA
T
A
= 25°C
T
A
= 150°C
T
rr
I
F
=0.5A, I
R
=1.0A,
35.0nS I
rr
=0.25A
DIM
A
B
C
D
INCHES
MIN
.287
.189
.048
1.000
MAX
.374
.208
.052
---
MM
MIN
7.30
4.80
1.20
25.40
MAX
9.50
5.30
1.30
---
NOTE
Typical Junction
Capacitance
SF31G~35G
SF36G~38G
C
J
50pF
30pF
Measured at
1.0MHz, V
R
=4.0V
Notes:1.High Temperature Solder Exemption Applied, see EU Directive Annex 7.
Revision: B
www.mccsemi.com
1 of 3
2013/01/01
MCC
TM
Micro Commercial Components
Ordering Information :
Device
Part Number-TP
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
1.2Kpcs/Reel
Ammo Packing:
1.2Kpcs/Ammo
Box
Bulk:
12Kpcs/Carton
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision: B
3 of 3
2013/01/01
