WEDF1M32B-90H1I5A

Description
Flash Module,
Categorystorage    storage
File Size725KB，9 Pages
ManufacturerMercury Systems Inc
Download Datasheet Parametric View All

WEDF1M32B-90H1I5A Overview

Flash Module,

WEDF1M32B-90H1I5A Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMercury Systems Inc
package instructionPGA, PGA66,11X11
Reach Compliance Codecompliant
Maximum access time90 ns
Other featuresUSER CONFIGURABLE AS 4MX8
Spare memory width16
startup blockBOTTOM
Data retention time - minimum20
JESD-30 codeS-CPGA-P66
length27.3 mm
memory density33554432 bit
Memory IC TypeFLASH MODULE
memory width32
Number of functions1
Number of departments/size1,2,1,15
Number of terminals66
word count1048576 words
character code1000000
Operating modeASYNCHRONOUS
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
organize1MX32
Output characteristics3-STATE
Package body materialCERAMIC
encapsulated codePGA
Encapsulate equivalent codePGA66,11X11
Package shapeSQUARE
Package formGRID ARRAY
Parallel/SerialPARALLEL
Programming voltage5 V
Maximum seat height4.6 mm
Department size16K,8K,32K,64K
Maximum standby current0.00002 A
Maximum slew rate0.2 mA
Maximum supply voltage (Vsup)5.5 V
Minimum supply voltage (Vsup)4.5 V
Nominal supply voltage (Vsup)5 V
surface mountNO
technologyCMOS
Temperature levelINDUSTRIAL
Terminal formPIN/PEG
Terminal pitch2.54 mm
Terminal locationPERPENDICULAR
typeNOR TYPE
width27.3 mm

WEDF1M32B-90H1I5A Preview

1Mx32 5V NOR FLASH MODULE
WEDF1M32B-XXX5
FEATURES

Access Times of 70, 90, 120ns

Packaging:
• 66 pin, PGA Type, 1.075” square, Hermetic Ceramic HIP
(Package 400)
• 68 lead, 22mm Low Profile CQFP, 3.5mm (0.140”),
(Package 510)

Sector Architecture
• One 16KByte Sectors
• Two 8KByte Sectors
• One 32KByte Sectors
• Fifteen 64KByte Sectors

1,000,000 Erase/Program Cycles

Organized as 1Mx32, user configurable as 2Mx16 or 4Mx8.

Commercial, Industrial and Military Temperature Ranges

5V ± 10% for Read and Write Operations.

Low Power CMOS

Embedded Erase and Program Algorithm

Built-in Decoupling Caps and Multiple Ground Pins for Low
Noise Operation

Weight
WEDF1M32B-XG2UX5 - 8 grams typical
WEDF1M32B-XH1X5 - 13 grams typical
* This product is under development, is not qualified or characterized and is subject to change or
cancellation without notice.
PIN CONFIGURATION FOR WF1M32B-XH1X5
TOP VIEW
1
I/O
8
I/O
9
I/O
10
A
14
A
16
A
11
A
0
A
18
I/O
0
I/O
1
I/O
2
11
22
12
RESET#
CS
2
#
GND
I/O
11
A
10
A
9
A
15
V
CC
CS
1
#
A
19
I/O
3
33
23
I/O
15
I/O
14
I/O
13
I/O
12
OE#
A
17
WE#
I/O
7
I/O
6
I/O
5
I/O
4
I/O
24
I/O
25
I/O
26
A
7
A
12
NC
A
13
A
8
I/O
16
I/O
17
I/O
18
44
34
V
CC
CS
4
#
NC
I/O
27
A
4
A
5
A
6
NC
CS
3
#
GND
I/O
19
55
45
I/O
31
I/O
30
I/O
29
I/O
28
A
1
A
2
A
3
I/O
23
I/O
22
I/O
21
I/O
20
66
56
PIN DESCRIPTION
I/O0-31
A0-19
WE#
CS1-4#
OE#
RESET#
V
CC
GND
NC
Data Inputs/Outputs
Address Inputs
Write Enable
Chip Selects
Output Enable
Reset
Power Supply
Ground
Not Connected
Block Diagram
CS1#
RESET#
WE#
OE#
A0-19
1M x 8
1M x 8
1M x 8
1M x 8
CS2#
CS3#
CS4#
8
8
8
8
I/O0-7
I/O8-15
I/O16-23
I/O24-31
Mercury Corp. - Memory and Storage Solutions • (602) 437-1520 • www.mrcy.com
1
4338.06E-0816-ss-WEDF1M32B-XXX5
WEDF1M32B-XXX5
PIN CONFIGURATION FOR WF1M32B-XG2UX5
TOP VIEW
I/O0-31
RESET#
A0
A1
A2
A3
A4
A5
CS3#
GND
CS4#
WE1#
A6
A7
A8
A9
A10
V
CC
PIN DESCRIPTION
Data Inputs/Outputs
Address Inputs
Write Enables
Chip Selects
Output Enable
Reset/Powerdown
Power Supply
Ground
A0-19
WE1-4#
CS1-4#
I/O16
I/O17
I/O18
I/O19
I/O20
I/O21
I/O22
I/O23
GND
I/O24
I/O25
I/O26
I/O27
I/O28
I/O29
I/O30
I/O31
9 8 7 6 5 4 3 2 1 68 67 66 65 64 63 62 61
I/O0
I/O1
I/O2
I/O3
I/O4
I/O5
I/O6
I/O7
GND
I/O8
I/O9
I/O10
I/O11
I/O12
I/O13
I/O14
I/O15
10
60
11
59
12
58
13
57
14
56
15
55
16
54
17
53
18
52
19
51
20
50
21
49
22
48
23
47
24
46
25
45
26
44
27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43
V
CC
A11
A12
A13
A14
A15
A16
CS1#
OE#
CS2#
A17
WE2#
WE3#
WE4#
A18
A19
NC
OE#
RESET#
V
CC
GND
BLOCK DIAGRAM
WE1# CS1#
RESET#
OE#
A0-19
1M x 8
1M x 8
1M x 8
1M x 8
WE2# CS2#
WE3# CS3#
WE4# CS4#
8
8
8
8
I/O0-7
I/O8-15
I/O16-23
I/O24-31
The Microsemi 68 lead G2U CQFP
fi
lls the same
fi
t and function as the
JEDEC 68 lead CQFJ or 68 PLCC. But the G2U has the TCE and lead
inspection advantage of the CQFP form.
Mercury Corp. - Memory and Storage Solutions • (602) 437-1520 • www.mrcy.com
2
4338.06E-0816-ss-WEDF1M32B-XXX5
