CSOD1100SH Overview

1.0Amp. Surface Mount Schottky Barrier Diodes

CYStech Electronics Corp.
1.0Amp. Surface Mount Schottky Barrier Diodes
Spec. No. : C338SH
Issued Date : 2009.04.03
Revised Date :2010.12.10
Page No. : 1/4
CSOD120-1100SH Series
Features
For surface mounted applications.
For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications
Plastic material used carries Underwriters Laboratory Flammability Classification 94V-0
Low leakage current
High surge capability
High temperature soldering: 250°C/10 seconds at terminals
Exceeds environmental standards of MIL-S-19500/228
RoHS compliant package
Mechanical Data
Case: Molded plastic, JEDEC SOD-123.
Terminals: Pure tin plated, solderable per MIL-STD-202 method 208
Polarity: Indicated by cathode band.
Weight: 0.04 gram approximately
Maximum Ratings and Electrical Characteristics
(
Rating at 25°C ambient temperature unless otherwise specified.)
Parameter
Repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum instantaneous
forward voltage, I
F
=1A
(Note 1)
Average forward rectified current
Peak forward surge current @8.3ms single
half sine wave superimposed on rated load
(JEDEC method)
Maximum DC reverse current
V
R
=V
RRM
,T
J
=25
(Note 1)
V
R
=V
RRM
,T
J
=125
(Note 1)
Maximum thermal resistance, Junction to
ambient
Diode junction capacitance @ f=1MHz and
applied 5V reverse voltage
Storage temperature range
Operating temperature range
Symbol
V
RRM
V
RMS
V
R
V
F
I
O
I
FSM
Type
Units
CSOD120 CSOD140 CSOD160 CSOD1100
20
40
60
100
V
14
28
42
70
V
20
40
60
100
V
0.45
0.55
1
30
0.66
0.83
V
A
A
mA
mA
/W
pF
I
R
R
th,JA
C
D
Tstg
T
J
0.3
10
250(typ)
45 (typ)
-65 ~ +175
-50 ~ +150
Notes : 1.Pulse test, pulse width=300μsec, 2% duty cycle
CSOD120-1100SH
CYStek Product Specification
