M21038/27-01T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power management> transformer> M21038/27-01T

M21038/27-01T: DescriptionPulse Transformer, GENERAL PURPOSE Application(s), 1CT:1CT; 1CT:0.707CT,; CategoryPower management transformer; File Size63KB，2 Pages; ManufacturerPulse Electronics

Download Datasheet Parametric Compare View All

M21038/27-01T Overview

Pulse Transformer, GENERAL PURPOSE Application(s), 1CT:1CT; 1CT:0.707CT,

M21038/27-01T Parametric

Parameter Name	Attribute value
Maker	Pulse Electronics
Reach Compliance Code	compliant
ECCN code	EAR99
application	GENERAL PURPOSE
high	6.35 mm
Insulation voltage	100 V
length	15.875 mm
Manufacturer's serial number	M21038/27
Installation features	THROUGH HOLE MOUNTED
Number of functions	1
Maximum operating temperature	130 °C
Minimum operating temperature	-55 °C
physical size	L0.625XB0.625XH0.25 (inch)
surface mount	NO
Transformer type	PULSE TRANSFORMER
Turns ratio (Np:Ns)	1CT:1CT; 1CT:0.707CT
width	15.875 mm

M21038/27-01T Preview

Through the board

MIL-PRF-21038/27

Level T Interface Transformers

qualified for use in QPL MIL-STD-1553 applications

dual ratio in a single package

designed, built, and tested

to MIL-PRF-21038 Level T*

two packages available: Package A without

standoffs, Package G with standoffs

built in ISO 9002 facility

APPLICABLE SPECIFICATIONS

MIL-STD-1553B

MIL-STD-202

MIL-I-45208

MIL-T-10727

MIL-PRF-21038/27*

ISO 9002

SUMMARY PERFORMANCE SPECIFICATIONS

Impedance................................................................................................... see table

Droop..............................................................................................................

20%

Overshoot..................................................................................................

1V max

Common mode rejection (CMR).................................................................

45 dB

Frequency range (no load)............................................................. 75 kHz to 1MHz

Operating temperature range........................................................... -55oC to 130oC

Weight.......................................................................................................

5 grams

Insulation resistance (min)........................................... 10K megohms @ 250 Vdc

Dielectric withstanding voltage................................................................ 100 Vrms

*MIL-PRF-21038E (8 July 1998) supersedes MIL-T-21038D (11 May 1979) and establishes

three product levels for low power pulse transformers:

Level C - for high reliability commercial/industrial applications;

Level M - for general purpose military applications;

Level T - for high reliability critical military applications.

TWO PEARL BUCK COURT

BRISTOL, PA 19007-6812

TEL 215-781-6400

FAX 215-781-6403

www.pulsespecialty.com

CHARACTERISTICS

MILITARY

DESIGNATION

NUMBER

TECHNITROL

PART NO.

PACK AGE

HEIGHT

(in.)

MAX

TERMINALS

RATIO

( +3%)

RDC

(ohm s)

MAX

IMPEDANCE

(ohms)

MIN

M21038/27-01T

QT1553-1

.250

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1-3:4-8

1-3:5-7

1CT :1CT

1CT :.707CT

1.4CT :1CT

2CT :1CT

1.25CT:1CT

1.66CT:1CT

1CT :2.3CT

1CT :3.2CT

1CT :2.12CT

1CT :1.5CT

1CT :1CT

1CT :.707CT

1.4CT :1CT

2CT :1CT

1.25CT:1CT

1.66CT:1CT

1CT :2.12CT

1CT :1.5CT

1CT :2.50CT

1CT :1.79CT

1CT :2.50CT

1CT :1.79CT

1-3 3.0

4-8 3.0

1-3 3.5

4-8 3.0

1-3 3.2

4-8 3.0

1-3 1.2

5-7 3.0

1.3 1.0

4-8 3.5

1-3 3.0

4-8 3.0

1-3 3.5

4-8 3.0

1-3 3.2

4-8 3.0

1-3 1.0

4-8 3.5

1-3 1.0

4-8 3.5

1-3 1.0

4-8 3.5

(1-3)

4000

(1-3)

7,200

(1-3)

4000

(5-7)

3000

(4-8)

3,000

(1-3)

4,000

(1-3)

7,200

(1-3)

4,000

(4-8)

4,000

(4-8)

4,000

(4-8)

4,000

M21038/27-02T

QT1553-2

.250

M21038/27-03T

QT1553-3

.250

M21038/27-04T

QT1553-4

.300

M21038/27-10T

QT1553-5*

.250

M21038/27-21T

QT1553-81

.275

M21038/27-22T

QT1553-82

.275

M21038/27-23T

QT1553-83

.275

M21038/27-24T

QT1553-84

.275

M21038/27-25T

QT1553-85

.275

M21038/27-26T

QT1553-45*

.250

*Designed for transceivers utilizing a single supply voltage (+5V).

SCHEMATICS AND DIMENSIONS

Package A

Package G

8l~tb~t

TWO PEARL BUCK COURT

BRISTOL, PA 19007-6812

TEL 215-781-6400

FAX 215-781-6403

www.pulsespecialty.com
