10/6/2018

Eclipse Swing Panel (ESP Series) - Hammond Mfg.

Quality Products. Service Excellence.

Eclipse Swing Panel

ESP Series

Hinged panel allows access to internally mounted equipment.

12 gauge steel construction.

Slotted quarter turn latches provide closure.

Adding optional locking quarter turn latches (Part Number

EQTRL)

convert this to a dead

front panel.

Complete with 4-6" depth adjustment channels.

Hardware kit maintains UL, CSA and NEMA ratings when field installed.

Finished in white.

Fits Enclosure Size

(A x B)

12 x 12

16 x 12

16 x 16

16 x 20

20 x 16

20 x 20

20 x 24

24 x 16

24 x 20

24 x 24

Part No.

ESP1212

ESP1612

ESP1616

ESP1620

ESP2016

ESP2020

ESP2024

ESP2416

ESP2420

ESP2424

Part No.

ESP3020

ESP3024

ESP3030

ESP3624

ESP3630

ESP3636

ESP4236

ESP4824

ESP4836

ESP6036

Fits Enclosure Size

(A x B)

30 x 20

30 x 24

30 x 30

36 x 24

36 x 30

36 x 36

42 X 36

48 X 24

48 X 36

60 X 36

Data subject to change without notice

https://www.hammfg.com/electrical/products/accessories/esp

1/1
