Hall Effect Current Sensors L03S***D15 Series
Features:
•
•
•
•
Open Loop type
Panel mounting
Molex connector
Insulated plastic case according to
UL94V0
Advantage:
•
•
•
•
•
•
Excellent accuracy and linearity
Low temperature drift
Wide frequency bandwidth
No insertion loss
High Immunity To External Interference
Current overload capability
Specifications
Parameters
Rated current
Maximum Current
Output Voltage
Offset Voltage
Accuracy
1
Output Linearity
1
Power Supply
Consumption Current
Response Time
2
T
A
=25ºC, V
CC
=±15V, R
L
=10k
Symbol L03S050D15 L03S100D15 L03S200D15 L03S300D15 L03S400D15 L03S500D15 L03S600D15
I
f
I
fmax
V
OUT
V
OE
X
≤±40mV @
I
f
= 0A
50AT
±150AT
100AT
±300AT
200AT
±600AT
4V±40mV @
I
f
≤±30mV @
I
f
= 0A
±1% @
I
f
≤±1% @
I
f
±15V±5%
< 12mA
< 5µs (@ di/dt=50A / µs)
≤±2mV/ºC
< ± 2mV/ºC
±30mV (@ 0A
⇔
I
f
)
< ± 1.0 mV/ºC
±20mV (@ 0A
⇔
I
f
)
±10mV (@ 0A
⇔
I
f
)
300AT
400AT
500AT
600AT
>±700AT
ε
L
V
CC
I
C
t
r
Output Temperature Charac-
TCV
OUT
teristic
1
Offset Temperature Charac-
TCV
OE
teristic
Hysteresis error
Withstand Voltage
Insulation Resistance
Frequency Bandwidth
3
Operating Temperature
Storage Temperature
1
V
OH
V
d
R
IS
f
T
A
T
S
AC2500V for 1minute (sensing current 0.5mA), inside of through hole
⇔
terminal
> 500M
(500V DC), inside of through hole
⇔
terminal
DC .. 50kHz
-20ºC~+80ºC
-20ºC~+85ºC
Without offset —
2
Time between 10% input current full scale and 90% of sensor output full scale —
3
Small signal only to avoid excessive heating of
magnetic core
Electrical Performances
Frequency Characteristic (L03S600D15)
2,0
0,0
Saturation Characteristic (L03S600D15)
6,0
O utput Voltage (V)
Attenuation (dB)
4,0
2,0
0,0
-2,0
-4,0
-6,0
- 2,0
- 4,0
- 6,0
- 8,0
- 10,0
0,1
1
10
100
-1200 -1000
-800
- 600
-400
-200
0
200
400
600
800
1000
1200
If frequency (kHz) @ If=6.0Arms
Input current (A)
L03SXXXD15revC, March 2009
Tamura reserve the right to modify its products in order to improve them without prior notice
Hall Effect Current Sensors L03S***D15 Series
Mechanical dimensions in mm
Ø4.5
L03S
Lot No.
20
Ø2.5
D15
Note 1: Unless otherwise specified, toler-
ances shall be ±0.5
Recommended
retainer holes
Terminal number:
1. +15V
2. -15V
3. V
OUT
4. 0V
40.5 MAX
20.5
Terminal number
29.5 MAX
19.5 MAX
Connector
5045-04A (MOLEX)
30.5 MAX
4321
39 MAX
10.5
15
20
4.5
Ø2
3
Ø4.5
18.5 MAX
Electrical connection diagram
+V
CC
-V
CC
1
2
3
4
GND
V
OUT
R
L
= 10k
+I
f
-I
f
Package & Weight Information
Weight
46g
Pcs/box
50
Pcs/carton
200
Pcs/pallet
2400
L03SXXXD15revC, March 2009
Tamura reserve the right to modify its products in order to improve them without prior notice
