RF Interconnect Products
Introduction ...................................................................................... 2
Trompeter Quality
ISO 9001 Registration ..................................................................... 3
Warranty Information ...................................................................... 3
Space Qualified Connectors
Outgassing Specifications ................................................................ 4
Twinax/Triax Connector Series
Mil-Std-1553B Data Bus General Specifications Guide ............. 5-6
70/370 Series
MIL-C-49142 QPL'd Connectors .................................................... 8
TRB/TRT Miniature Plugs & Jacks ................................................ 9
TRB/TRT Miniature Bulkhead Jacks ............................................ 10
Miniature Circuit Board Jacks ....................................................... 11
TRB Series Pad, Paralleling Jacks, & T Adapter .......................... 12
Hermetically Sealed Connectors ................................................... 13
Mating Twinax Size 8 Contacts .....................................................
14
150/3150 Series
TRS/TTM Subminiature Jacks and Plugs ..................................... 15
TRS/TTM Subminiature Bulkhead Jacks ...................................... 16
Subminiature Bulkhead Jacks, Adapters,
& Push-on .................................................................................. 16-17
450 Series
Concentric Twinax Connectors ................................................ 18-20
80/380 Series
TRC/TRN Standard Twinax/Triax Threaded ................................ 21
30/330 Series
TWBNC/TWTNC
Two-pin Polarized Connectors ...................................................... 22
Coax Connector Series
20/220 Series
Coax BNC Plugs & Jacks ......................................................... 23-24
Coax BNC Bulkhead Jacks ............................................................ 25
Coax Circuit Board Jacks ......................................................... 26-31
250 Series
Mini-BNC Coax Plugs & Jacks ..................................................... 33
Mini-BNC Circuit Board Jacks ..................................................... 33
40/240 Series
TNC Miniature Coax Threaded ..................................................... 34
TNC Bulkhead Jacks, Miniature Coax Threaded ......................... 35
120 Series
BNC/TNC Miniature Push-on Jacks & Plugs ............................... 36
1.6/5.6 DIN Connectors
Miniature Coax DIN Connectors ................................................... 37
Coaxial Ground Filter Bulkhead Jacks .........................................
38
"N" Connectors
90 Series Coax "N" Connectors ................................................ 39-40
Low VSWR Coax Connectors ....................................................... 43
"F" Connectors
130 Series Coax "F" Connectors .............................................. 40-42
50/350 Series
TPS/TCM Subminiature Coax Threaded Jacks & Plugs .............. 44
Teflon is a registered trademark of the Dupont Company.
Terminations & RFI Caps
Coax Terminations & RFI Caps .................................................. 45
Chain Options .............................................................................. 45
Stainless Steel Rope for "D" Ring Option .................................. 45
Twinax/Triax Terminations & RFI Caps .................................... 46
Adapters (Custom and Standard)
Adapter Circuitry Schematics ...................................................... 47
Coax to Coax Adapter Table ....................................................... 48
Coax/Twinax/Triax Adapter Table ......................................... 49-50
Patching Products
Panels
Panel Specifications ..................................................................... 51
Distribution Panels ....................................................................... 52
Standard/Miniature Panels ...................................................... 53-54
"D" Mounting Hole Specifications .............................................. 54
Patching
Standard Twinax/Triax Patching ........................................... 55, 57
Front Loading Modular Panels .................................................... 56
Subminiature Twinax/Triax Patching ......................................... 58
Standard & Subminiature Twinax/Triax Looping Plugs ............ 57
Standard Coax Patching .......................................................... 60-65
Mini-WECo Coax Patch Plugs .................................................... 66
75Ω Mini-WECo Coax Patch Jacks ...................................... 60, 62
Audio Patching ............................................................................. 68
Coax Looping Plugs ..................................................................... 68
50Ω Miniature Coax Patching ..................................................... 69
Custom Cable Assemblies .......................................................
70-72
Tools & Accessories
Cable Strippers ............................................................................. 73
Crimp Tools ................................................................................. 74
Cable Assembly Testers .............................................................. 75
Tool Kit/Bulk Packaging ............................................................. 76
Appendix
Bend Relief Boots ........................................................................ 90
Trompeter Cable Specifications ............................................. 77-78
Cable Group Table ................................................................ 91-133
Connector Compatibility Table ................................................... 79
General Material/ Finish Specifications ...................................... 80
BNC Coax Tool/Wrench Crimp Assembly Illustrations ............ 83
Custom Products Fax Request Form ......................................... 137
Part Number Index .............................................................. 138-140
Technical Papers
Signal Transmission in High Density/
High Frequency Applications .................................................
81-82
Electronic Systems Wiring & Cable ......................................
84-89
Digital Signal Integrity .......................................................
134-136
Trompeter Products Catalog - T21 Military/Aerospace
ISO 9001
Registered
R
(800) 982-2629
Fax: (818) 706-1040
www.trompeter.com
2
rf interconnect products
Introduction
Established in 1960, Trompeter is a manufacturer of high value wireline coax, triax, and twinax transmission line
connectors, cable, and the tools required for assembly. In addition, the company has a broad line of patch panel insertion-
controlled interconnect modules and a rapid response cable assembly business. The firm is ISO-9001 registered and
enjoys an international presence in the Telecommunications, Broadcast, and Military/Aerospace markets.
MIL-STD-1553B Digital Data Bus Applications
Twinax /Triax connectors are used in military applications to protect data signals from extraneous noise through non-
signal-carrying shielding. Interfacing connectors must provide contact surfaces isolated from each other and from their
outer shields. MIL-STD-1553B addresses twinax applications for computerized/multiplexed digital data distribution
systems servicing the many functions of
Command, Control, Communications, Computers
and
Intelligence
(C
4
I)
which
was originally designed for military aircraft. MIL-STD-1553B applications are found in military surface ships, battle
tanks, helicopters, missiles, space vehicles, combat aircraft and in many ground applications such as data networks and
perimeter security for airports, armories, and other government installations.
The great advantages of additional information, automation and weight savings, which are necessary for the complex
demands of aircraft operations are realized by using a single transmission cable instead of the complicated, heavy,
dedicated multiple cable used in the past. A 78Ω twinax cable was selected to provide the transmitted digital information
with the needed protection from magnetic, electrostatic and electromagnetic pulse (EMP) interference. Complete
shielding of the twisted pair along the transmission path and all electrical contacts within multi-pin connectors must be
maintained.
Trompeter
provides matching components of Twinax/Triax connectors and cable for improving the transmission
capabilities and interference rejection of data transmission systems. Trompeter components will meet or exceed MIL-
STD-1553B requirements (for airborne and ground checkout) and MIL-STD-1760 "External Stores".
Trompeter Products Catalog - T21 Military/Aerospace
ISO 9001
Registered
R
(800) 982-2629
Fax: (818) 706-1040
www.trompeter.com
3
Trompeter quality
Quality Standard and Custom Components
For over thirty years, Trompeter's product offering have grown as a result of new and modified designs for unusual
applications. With Trompeter's tradition of custom components comes our reputation for providing rugged products that
have been designed to perform to your expectations and to meet your specific mechanical requirements. The growth of
our product line, from 78 components in 1964 to more than 7,000 end items (over 20,000 configurations), is proof of our
engineering and manufacturing capabilities.
Why compromise your design?
A minor modification might be an affordable solution to your design needs.
Why settle for less than Trompeter?
Superior quality is paramount.
Trompeter components meet your most demanding requirements...
When performance is critical.
When compromise is not an acceptable solution.
When cost savings detract from the integrity of your design.
ISO 9001 Registration
The main value of being an ISO 9001 Registered company is in the assurance to our customers that we have a solid quality
system in place, and that it is well documented. DET Norske Veritas (DNV) has certified that Trompeter is in compliance
with established systems and policies. ISO 9001 Quality System Standard is a document outlining twenty elements of
quality that Trompeter has addressed in order to meet registration requirements. An accredited ISO 9001 auditor must
verify, through on-site audits, that a company has a well documented quality system in place that meets the requirements
of ISO 9001, and that the company is working in accordance with the documented system. Trompeter's quality system
is also certified by numerous other accredited agencies. ISO 9001 registration makes Trompeter an edge in the global
market by giving customers the assurance that they are dealing with a company dedicated to meeting their quality
expectations.
3-Year Warranty
All Trompeter products carry a
"Three Year Warranty"
(except
the battery powered cable stripper)
and meet or exceed
the highest industrial and government standards, such as MIL-C-39012 and MIL-C-49142. More importantly, Trompeter
connectors are designed to meet your design specifications which are often more demanding and less forgiving. We have
built our business on responding to your special needs for uncompromising performance in a world of increasing pressure
from global competition. If, within three (3) years of shipment, any of our products fail to meet your expectations due
to defects in material or workmanship, we will gladly repair or replace it free of charge.
Custom Product Requests
The products in this catalog are your first resource for solving your special interconnect problems. If you cannot find
an adequate solution, then we invite you to consult with us for your special requirements. If you have an application which
requires a new product, or a modification to one of our existing products, please fill out a copy of the Custom Products
Request Form on page 137 and fax it to us. Please submit one complete form for each product requested. Requests for
new/modified products are evaluated weekly, and you will receive a response within 3-5 working days.
Trompeter Products Catalog - T21 Military/Aerospace
ISO 9001
Registered
R
(800) 982-2629
Fax: (818) 706-1040
www.trompeter.com
4
Space-qualified connectors
Outgassing Requirements
for Space Rated Connectors
Trompeter has a long and proud history of servicing space applications.
NASA
uses the specification
(SP-R-0022),
Vacuum Stability Requirements of Polymeric Material for Space Application, to qualify materials for use in spacecraft.
This has also become the standard in the commercial space industry. This specification governs the "outgassing" of non-
metallic materials. Outgassing occurs when a non-metallic material is placed into a vacuum, subjected to heat, and some
of its constituents are volatilized.
One of the bi-products of outgassing is that the material loses a portion of its mass. This is referred to as Total Mass Loss,
or TML. Under the NASA specification, the material's TML should not exceed 1.0% of the total specimen mass. This
issue is very important because shrinkage may contribute to the failure of a connector as the connector components will
no longer fit properly.
Another bi-product of outgassing is Collectable Volatile Condensable Material (CVCM). This represents the quantity
of outgassed matter that condenses and collects on a surface. Under the NASA specification, the maximum condensable
material allowed is 0.1% of the total specimen mass. This is very critical in a thermal/vacuum environment because it
is the condensed material that will contaminate optical and sensory surfaces causing them to possibly fail.
Some polymeric materials meet the requirements of a TML less than 1.0% and CVCM of less than 0.1% through the
normal manufacturing process. Other polymeric materials, while not within limits after their manufacture, can be
brought within vacuum stability limits by vacuum baking for a specific period of time (usually 48 hours at maximum
use temperature at a pressure less than 10
-5
torr). If a material cannot be vacuum baked, its exposure area is 13cm
2
or less,
and is out of sight of a payload or other critical surfaces, then a TML not greater than 3.0% and a CVCM not greater than
1.0% is acceptable.
Test conditions are ASTM E-595 or ASTM F-1227. The test consists of heating a sample to 125°C for 24 hours under
a 10
-5
torr vacuum and measuring the weight loss and any material that condenses on an adjacent cold surface area (25°C).
The most common candidates for outgassing in Trompeter product lines include:
1. Silicon rubber per ZZ-R-765E/GEN (Federal Spec), Class 2B, Grade 40, 50, 60, and 70. Almost all of
Trompeter's gaskets are manufactured from this material. These materials require a post process
(by Trompeter) at 200°centigrade for 6 hours minimum.
2. Ink. Trompeter uses Markem
TM
series 7224 inks (in a variety of colors) for part marking. Only blue 7224
Markem ink has acceptable TML (0.43%) and CVCM (0.07%) readings after a post cure process. While this
is acceptable, Trompeter recommends impression stamping the connector rather than ink marking.
3. Shrinkable strain relief/sealing sleeve. Sleeves made from Kynar
TM
material meets the requirement for
outgassing at 0.14% TML and 0.02% CVCM.
4. Insulators. At Trompeter, the majority of dielectric insulators are made from PTFE. (Teflon
TM
is Dupont's
trademark for PTFE, FEP, and PFA fluoropolymer resins). PTFE has excellent TML (0.07%) and CVCM
(0.01%) readings. The loss rate is about one-tenth of the acceptable maximum rates for spacecraft uses.
For a list of connectors which meet outgassing requirements, contact our technical support staff.
Trompeter Products Catalog - T21 Military/Aerospace
ISO 9001
Registered
R
(800) 982-2629
Fax: (818) 706-1040
www.trompeter.com
5
Twinax/triax connector specifications
Trompeter offers a broad line of connectors manufactured to
meet or exceed the Mil-Specs governing twinax connectors.
In fact, Mil-C-49142 was created from the Trompeter con-
centric twinax/triax connector design.
The following information reflects the specification require-
ments for each family of connectors in both twinax and
triax applications. Use this chart to determine the proper
connector type to be used in your application, based on the
environment and electrical requirements of your design.
Trompeter's technical support staff is available to answer any
specification questions you may have.
MIL-STD-1553B Data Bus
General Specifications Guide
Characteristic Requirements
Nominal Impedance
Frequency Range
Voltage Rating
(max.)
@ sea level
Voltage Rating
(max.)
@ 70,000 ft.
Insulation Resistance
Dielectric Withstanding Voltage
(between center cond. & inter. cond.)
Dielectric Withstanding Voltage
(between inter. cond. & outer cond.)
RF High Potential Withstanding Voltage
(between center cond. & inter. cond.)
RF High Potential Withstanding Voltage
(between inter. & outer cond.)
70 Series
TRB/TRT
Non-constant
0-500 MHz
400 VRMS
100 VRMS
5000 MΩ
1200 VRMS
80 Series
TRC/TRN
Non-constant
0-500 MHz
500 VRMS
125 VRMS
5000 MΩ
1500 VRMS
150 Series
TRS/TTM
Non-constant
0-500 MHz
400 VRMS
100 VRMS
5000 MΩ
1200 VRMS
450 Series
TCS
Non-constant
0-2 MHz
900 VRMS
N/A
5000 MΩ
900 VAC
500 VRMS
500 VRMS
500 VRMS
N/A
800 VRMS
1000 VRMS
500 VRMS
900 VAC @ 60 Hz
200 VRMS
@ 5-7.5 MHz
350 VRMS
@ 5-7.5 MHz
125 VRMS
N/A
Specifications continued on page 6...
* Specifications are minimum unless otherwise stated. Trompeter connectors are designed to exceed all minimum specifications.
Trompeter Products Catalog - T21 Military/Aerospace
ISO 9001
Registered
R
(800) 982-2629
Fax: (818) 706-1040
www.trompeter.com
Creative Market
京公网安备 11010802033920号
EEWORLD
