DCM
™
DC-DC Converter
DCM2322x50T1360y6z
S
®
C
US
C
NRTL
US
Isolated, Regulated DC Converter
Features & Benefits
•
Isolated, regulated DC-DC converter
•
Up to 60 W, 5.00 A continuous
•
89.7% peak efficiency
•
266 W/in
3
Power density
•
Wide input range 9 – 50 Vdc
•
Safety Extra Low Voltage (SELV) 12.0 V Nominal Output
•
3000 Vdc isolation
•
ZVS high frequency switching
•
Dual modes of operation:
Product Ratings
V
IN
= 9 V to 50 V
V
OUT
= 12.0 V
(7.2 V to 13.2 V Trim)
P
OUT
= 60 W
I
OUT
= 5.00 A
Product Description
The DCM2322 is a lower power, isolated and regulated DC-DC
converter that operates from an unregulated, wide-range input
to generate an isolated 12.0 Vdc output. With its high-frequency
zero-voltage switching (ZVS) topology, the DCM2322 converter
consistently delivers high efficiency across the input line range.
Modular DCM converters and downstream DC-DC products
support efficient power distribution, providing superior power
system performance and connectivity from a variety of
unregulated power sources to the point-of-load.
Leveraging the thermal and density benefits of Vicor’s ChiP
packaging technology, the DCM2322 offers flexible thermal
management options with very low top and bottom side
thermal impedances. Thermally adept ChiP based power
components enable customers to quickly and predictably
achieve cost effective power system solutions.
n
Enables low-profile, high-density filtering
n
Array mode
– Up to 8 units – 480 W
– No power derating needed
– Sharing strategy permits dissimilar line voltages
across an array
n
Enhanced V
OUT
regulation mode
– Standalone: 60 W
•
Fully operational current limit
•
OV, OC, UV, short circuit and thermal protection
•
2322 through-hole ChiP™ package
n
0.978” x 0.898” x 0.284”
(24.84 mm x 22.8 mm x 7.21 mm)
Typical Applications
•
•
•
•
Rail Transportation
Defense / Aerospace
Industrial
Process Control
Part Ordering Information
Product
Function
DCM
23
Package
Size
22
Package
Type
x
Max
Input
Voltage
50
Range
Ratio
T
Max
Output
Voltage
13
Max
Output
Power
60
Temperature
Grade
y
Option
6z
60 = Array and
Enhanced V
OUT
Regultion
Modes / Analog Control
Interface Version
DCM =
DC-DC
Converter
mm
T=
Through hole
ChiPs
Internal Reference
T = -40°C to 125°C
M = -55°C to 125°C
DCM™ DC-DC Converter
Page 1 of 31
Rev 1.1
01/2020
DCM2322x50T1360y6z
Typical Applications
R
b
C
b1
C
b2
DCM1
TR
EMI_GND
C
Y
EN
FT
R
dm_1
C
Y
L
2_1
R
COUT-EXT_1
L
b_1
F
1_1
V
IN
L
1_1
C
1_1
R
d_1
C
d_1
+IN
+OUT
C
IN
–IN
–OUT
C
OUT-EXT_1
C
Y
C
2_1
C
3
C
4
Load
C
Y
R
b
R
b
C
b1
C
b1
C
b2
C
b2
DCM2
TR
EN
FT
R
dm_2
C
Y
L
2_2
R
COUT-EXT_2
L
b_2
F
1_2
L
1_2
C
1_2
R
d_2
C
d_2
C
Y
+IN
+OUT
C
IN
–IN
–OUT
C
OUT-EXT_2
C
Y
C
2_2
≈≈
C
Y
R
b
C
b1
C
b2
≈≈
R
b
C
b1
C
b2
DCM4
TR
EN
FT
R
dm_4
C
Y
L
b_4
L
2_4
F
1_4
L
1_4
C
1_4
R
d_4
C
d_4
C
Y
+IN
+OUT
C
IN
–IN
–OUT
R
COUT-EXT_4
C
OUT-EXT_4
C
Y
R
b
C
b1
C
b2
C
2_4
C
Y
Note:
C
IN
, R
b
, C
b1
and C
b2
are required components for proper operation of the DCM. See required components table below.
DCM2322x50T1360y6z in an array of four units; applicable when DCM is operating in Array Mode
Required Components
C
IN
R
b
C
b1
, C
b2
TDK
C5750X7T2E225M250KA, 2.2 µF, 250 V
Generic
1
Ω,
1/4 W
KEMET
C1812C103KGRACTU, 10,000 pF, 2000 V
DCM™ DC-DC Converter
Page 2 of 31
Rev 1.1
01/2020
DCM2322x50T1360y6z
Typical Applications (Cont.)
R
b
C
b1
C
b2
DCM1
TR
EMI_GND
C
Y
T
1_1
C
1_1
R
d_1
C
d_1
C
Y
C
IN
EN
FT
C
Y
+IN
+OUT
R
dm_1
L
b_1
L
2_1
F
1_1
V
IN
R
COUT-EXT_1
C
OUT-EXT_1
C
Y
C
2_1
C
3
C
4
Load
–IN
–OUT
R
b
R
b
C
b2
C
b1
C
b2
C
b2
DCM2
TR
EN
FT
F
1_2
C
Y
T
1_2
C
1_2
R
d_2
C
d_2
C
Y
C
IN
–IN
–OUT
+IN
+OUT
C
Y
R
dm_2
L
b_2
L
2_2
R
COUT-EXT_2
C
OUT-EXT_2
C
Y
C
2_2
≈≈
R
b
C
b1
C
b2
≈≈
R
b
C
b1
C
b2
DCM8
TR
EN
FT
F
1_8
C
Y
T
1_8
C
1_8
R
d_8
C
d_8
C
Y
R
b
C
b1
C
b2
C
IN
–IN
–OUT
+IN
+OUT
C
Y
R
dm_8
L
b_8
L
2_8
R
COUT-EXT_8
C
OUT-EXT_8
C
Y
C
2_8
Note:
C
IN
, R
b
, C
b1
and C
b2
are required components for proper operation of the DCM. See required components table on page 2.
Parallel operation of DCMs with common mode chokes installed on the input side to suppress common mode noise; applicable when DCM
is operating in Array Mode
R
b
C
b1
C
b2
DCM
TR
EMI_GND
C
Y
EN
FT
F
1
V
IN
L
1
C
1
R
d
C
d
C
Y
+IN
+OUT
R
dm
L
2
R
COUT-EXT
L
b
Load 1
C
IN
–IN
–OUT
C
2
C
OUT-EXT
C
Y
C
Y
R
b
C
b1
C
b2
Non-isolated
Point-of-Load
Regulator
Load 2
Note:
C
IN
, R
b
, C
b1
and C
b2
are required components for proper operation of the DCM. See required components table on page 2.
Single DCM2322x50T1360y6z, to a non-isolated regulator, and direct to load
DCM™ DC-DC Converter
Page 3 of 31
Rev 1.1
01/2020
DCM2322x50T1360y6z
Pin Configuration
1
+IN
A
TOP VIEW
2
A’
+OUT
B’
–OUT
C’
+OUT
D’
–OUT
TR
B
EN
C
FT
D
–IN
E
DCM ChiP™
Pin Descriptions
Pin
Number
A1
B1
C1
D1
E1
A’2, C’2
B’2, D’2
Signal Name
+IN
TR
EN
FT
-IN
+OUT
-OUT
Type
INPUT POWER
INPUT
INPUT
OUTPUT
INPUT POWER
RETURN
OUTPUT POWER
OUTPUT POWER
RETURN
Positive input power terminal
Function
Enables and disables trim functionality. Adjusts output voltage when trim active.
Dual function:
1. Enables either Array or Enhanced V
OUT
Regulation mode
2. Enables and disables power supply
Fault monitoring
Negative input power terminal
Positive output power terminal
Negative output power terminal
DCM™ DC-DC Converter
Page 4 of 31
Rev 1.1
01/2020
DCM2322x50T1360y6z
Absolute Maximum Ratings
The absolute maximum ratings below are stress ratings only. Operation at or beyond these maximum ratings can cause permanent damage to the device.
Electrical specifications do not apply when operating beyond rated operating conditions.
Parameter
Input Voltage (+IN to –IN)
Input Voltage Slew Rate
TR to –IN
EN to –IN
FT to –IN
5
Output Voltage (+OUT to –OUT)
Dielectric withstand (input to output)
Internal Operating Temperature
M-Grade
T-Grade
Storage Temperature
M-Grade
Average Output Current
-65
125
9.0
°C
A
-55
-40
125
125
°C
°C
Basic insulation
T-Grade
-0.5
3000
-40
125
15.8
mA
V
Vdc
°C
Comments
Min
-0.5
-1
-0.3
-0.3
-0.3
Max
65.0
1
3.5
3.5
3.5
Unit
V
V/µs
V
V
V
Figure 1
—
Thermal Specified Operating Area: Max Output Power vs. Case Temp, Single unit at minimum full load efficiency
Figure 2
—
Electrical Specified Operating Area: Array Mode
Figure 3
—
Electrical Specified Operating Area: Enhanced V
OUT
Regulation Mode
DCM™ DC-DC Converter
Page 5 of 31
Rev 1.1
01/2020
