Miniature Aluminum Electrolytic Capacitors
LOW IMPEDANCE, SUBMINIATURE, RADIAL LEADS,
POLARIZED ALUMINUM ELECTROLYTIC CAPACITORS
FEATURES
• VERY LOW IMPEDANCE AT HIGH FREQUENCY
• LOW PROFILE 7mm HEIGHT
• WIDE TEMPERATURE, -55
O
C~ +105
O
C
CHARACTERISTICS
Rated Voltage Range
Capacitance Range
Operating Temperature Range
Capacitance Tolerance
Max. Leakage Current
After 1 minutes At +20°C
Max. Tan
δ
@ 120Hz/+20°C
Low Temperature Stability
Impedance Ratio @ 120Hz
Load Life Test at Rated W.V.
+105°C 1,000 Hours
6.3 ~ 35Vdc
0.47 ~ 330μF
-55 ~ +105°C
±20%(M)
0.01CV or 3μA, whichever is greater
W.V. (Vdc)
S.V. (Vdc)
Tan
δ
Z-40°C/Z+20°C
Z-55°C/Z+20°C
Capacitance Change
Tan
δ
Leakage Current
6.3
10
16
25
35
8
13
20
32
44
0.24
0.20
0.18
0.14
0.12
3
2
2
2
2
5
4
4
3
3
Within ±25% of initial measured value
Less than 200% of specified maximum value
Less than specified maximum value
NRE-SX Series
includes all homogeneous materials
RoHS
Compliant
*See Part Number System for Details
P N b S
f D il
STANDARD PRODUCT AND CASE SIZE TABLE Dφ x L (mm)
Cap. (μF)
4.7
10
15
22
33
47
68
100
150
220
330
Code
4R7
100
150
220
330
470
680
101
151
221
331
6.3
-
-
-
-
-
5x7
-
-
-
6.3x7
6.3x7
Working Voltage (Vdc)
10
16
25
-
-
-
-
-
4x7
-
4x7
5x7
4x7
5x7
5x7
5x7
-
6.3x7
5x7
6.3x7
6.3x7
-
-
6.3x7
6.3x7
6.3x7
6.3x7
6.3x7
6.3x7
-
6.3x7
6.3x7
-
-
-
-
35
4x7
5x7
6.3x7
6.3x7
6.3x7
6.3x7
-
-
-
-
-
LEAD SPACING AND DIAMETER (mm)
Case Dia. (Dφ)
Lead Dia. (dφ)
Lead Spacing (F)
Dim.
α
Dim.
β
4
0.45
1.5
0.5
1.0
5
0.45
2.0
0.5
1.0
6.3
0.45
2.5
0.5
1.0
DIMENSIONS (mm)
Polarity Marking
Sleeve
+
dφ ± 0.05
F ± 0.5
-
L +
β
max.
15mm Min.
4mm
Min.
Dφ ±
α
Drawing is representative of parts as supplied in bulk or
straight lead format, please see taping specification for
details on taped format packaging.
Please review the notes on correct use, safety and precautions found on
pages T10
&
T11
of NIC’s
Electrolytic Capacitor catalog.
Also found at
www.niccomp.com/precautions
If in doubt or uncertainty, please review your specific application - process
details with NIC’s technical support personnel:
tpmg@niccomp.com
PRECAUTIONS
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
1
Miniature Aluminum Electrolytic Capacitors
STANDARD PRODUCTS, CASE SIZES AND SPECIFICATIONS Dφ x L (mm)
Part Number
NRE-SX470M6.3V5 x 7F
NRE-SX221M6.3V6.3 x 7F
NRE-SX331M6.3V6.3 x 7F
NRE-SX220M10V4 x 7F
NRE-SX330M10V5 x 7F
NRE-SX470M10V5 x 7F
NRE-SX101M10V6.3 x 7F
NRE-SX151M10V6.3 x 7F
NRE-SX221M10V6.3 x 7F
NRE-SX150M16V4 x 7F
NRE-SX220M16V5 x 7F
NRE-SX470M16V6.3 x 7F
NRE-SX101M16V6.3 x 7F
NRE-SX151M16V6.3 x 7F
NRE-SX221M16V6.3 x 7F
NRE-SX100M25V4 x 7F
NRE-SX150M25V5 x 7F
NRE-SX220M25V5 x 7F
NRE-SX330M25V6.3 x 7F
NRE-SX470M25V6.3 x 7F
NRE-SX680M25V6.3 x 7F
NRE-SX101M25V6.3 x 7F
NRE-SX4R7M35V4 x 7F
NRE-SX100M35V5 x 7F
NRE-SX150M35V6.3 x 7F
NRE-SX220M35V6.3 x 7F
NRE-SX330M35V6.3 x 7F
NRE-SX470M35V6.3 x 7F
Cap.
(μF)
47
220
330
22
33
47
100
150
220
15
22
47
100
150
220
10
15
22
33
47
68
100
4.7
10
15
22
33
47
W.V.
(Vdc)
6.3
Max.
Tanδ
0.24
0.24
0.24
0.20
0.20
0.20
0.20
0.20
0.20
0.18
0.18
0.18
0.18
0.18
0.18
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.12
0.12
0.12
0.12
0.12
0.12
Max. Impedance
100KHz/20°C
0.49
0.24
0.29
1.15
0.49
0.49
0.24
0.24
0.29
1.15
0.49
0.24
0.24
0.29
0.29
1.15
0.49
0.49
0.24
0.24
0.24
0.24
1.15
0.49
0.29
0.29
0.29
0.29
Max. Ripple Current at
100KHz/105°C
(mA rms)
0.49
0.24
0.29
90
160
160
280
280
280
90
160
280
280
280
280
90
160
160
280
280
280
280
90
160
280
280
280
280
Load Life Hours
@ +105°C
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
NRE-SX Series
10
16
25
35
PART NUMBER SYSTEM
NRE-SX 220 M 35V 6.3x7 TB F
RoHS Compliant
TB = Tape & Box*
Size (D∅ x L)
Rated Voltage
Tolerance Code
Capacitance Code
Series
*see tape specification for details
