DG3000DB-E1

Description
IC 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PBGA6, 1.07 X 1.57 MM, BUMP, CSP-6, Multiplexer or Switch
CategoryAnalog mixed-signal IC    The signal circuit
File Size96KB，9 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric View All

DG3000DB-E1 Overview

IC 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PBGA6, 1.07 X 1.57 MM, BUMP, CSP-6, Multiplexer or Switch

DG3000DB-E1 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
Parts packaging codeBGA
package instructionVFBGA,
Contacts6
Reach Compliance Codeunknown
Analog Integrated Circuits - Other TypesSPDT
JESD-30 codeR-PBGA-B6
JESD-609 codee1
length1.57 mm
Humidity sensitivity level1
Number of channels1
Number of functions1
Number of terminals6
Nominal off-state isolation61 dB
Maximum on-state resistance (Ron)20 Ω
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeVFBGA
Package shapeRECTANGULAR
Package formGRID ARRAY, VERY THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum seat height0.715 mm
Maximum supply voltage (Vsup)2.2 V
Minimum supply voltage (Vsup)1.8 V
Nominal supply voltage (Vsup)2 V
surface mountYES
Maximum disconnect time33 ns
Maximum connection time76 ns
technologyCMOS
Temperature levelINDUSTRIAL
Terminal surfaceTin/Silver/Copper (Sn/Ag/Cu)
Terminal formBALL
Terminal pitch0.5 mm
Terminal locationBOTTOM
Maximum time at peak reflow temperature40
width1.07 mm

DG3000DB-E1 Preview

DG3000
Vishay Siliconix
Low-Voltage Single SPDT MICRO FOOTrAnalog Switch
FEATURES
D
MICRO FOOT Chip Scale Package
(1.07 x 1.57 mm)
D
Low Voltage Operation (1.8 V to 5.5 V)
D
Low On-Resistance - r
DS(on
): 1.4
W
D
Fast Switching - t
ON
: 24 ns, t
OFF
: 9 ns
D
Low Power Consumption
D
TTL/CMOS Compatible
BENEFITS
D
D
D
D
Reduced Power Consumption
Simple Logic Interface
High Accuracy
Reduce Board Space
APPLICATIONS
D
D
D
D
D
D
Cellular Phones
Communication Systems
Portable Test Equipment
Battery Operated Systems
PCM Cards
PDA
DESCRIPTION
The DG3000 is a single-pole/double-throw monolithic CMOS
analog switch designed for high performance switching of
analog signals. Combining low power, high speed (t
ON
: 24 ns,
t
OFF
: 9 ns), low on-resistance (r
DS(on)
: 1.4
W)
and small
physical size (MICRO FOOT, 6-bump), the DG3000 is ideal for
portable and battery powered applications requiring high
performance and efficient use of board space.
The DG3000 is built on Vishay Siliconix’s low voltage JI2
process. An epitaxial layer prevents latchup. Break-before
-make is guaranteed for DG3000.
Each switch conducts equally well in both directions when on,
and blocks up to the power supply level when off.
FUNCTIONAL BLOCK DIAGRAM AND PIN CONFIGURATION
MICRO FOOT
(6-Bump)
TRUTH TABLE
IN
V+
GND
B1
A1
NO (Source
1
)
COM
NC (Source
2
)
Logic
0
1
NC
ON
OFF
NO
OFF
ON
B2
A2
B3
A3
Top View
A1 Locator
3000
ORDERING INFORMATION
Temp Range
-40 to 85°C
Package
MICRO FOOT: 6-Bump
(3 x 2, 0.5-mm Pitch)
Part Number
DG3000DB
Device Marking: 3000
xxx = Date/Lot Traceability Code
XXX
Document Number: 71742
S-32154—Rev. D, 03-Nov-03
www.vishay.com
1
