2259 & 2257 Series
4.2mm Wire to Wire Dual Row Connectors
Specifications:
Current Rating
Voltage Rating
Contact Resistance
Insulation Resistance
Withstanding Voltage
Operating Temperature Range
Wire Size
Material and Finish
A. Housing Insulator
B. Crimp Terminal
: Nylon 66
: Phosphor Bronze or
Brass Tin Plated
: 9A AC/DC
: 600V AC/DC
: 10mΩ Max.
: 1,000MΩ Min.
: 1,500V AC for one minute
: -40°C to +105°C
: 26AWG to 16AWG
Receptacle
Plug
Dimensions of Receptacle :
Circuits
2
4
6
8
10
12
14
16
18
20
Dim. A
-
4.2
8.4
12.6
16.8
21
25.2
29.4
33.6
37.8
Dim. B
5.4
9.6
13.8
18
22.2
26.4
30.6
34.8
39
43.2
Dimensions : Millimetres
www.element14.com
www.farnell.com
www.newark.com
Page <1>
22/01/13
V1.0
2259 & 2257 Series
4.2mm Wire to Wire Dual Row Connectors
Dimensions of Plug :
Max. Panel thickness : 2mm
Circuits
2
4
6
8
10
12
14
16
18
20
Dimensions : Millimetres
Dim. A
-
4.2
8.4
12.6
16.8
21
25.2
29.4
33.6
37.8
Dim. B
5.4
9.6
13.8
18
22.2
26.4
30.6
34.8
39
43.2
Dim. C
10.8
15
19.2
23.4
27.6
31.8
36
40.2
44.4
48.6
Dim. D
5.8
10
14.2
18.4
22.6
26.8
31
35.2
39.4
43.6
Part Number Table
Description
Receptacle, Free, 2 Way
Receptacle, Free, 4 Way
Receptacle, Free, 6 Way
Receptacle, Free, 8 Way
Receptacle, Free, 10 Way
Receptacle, Free, 12 Way
Receptacle, Free, 14 Way
Receptacle, Free, 16 Way
Receptacle, Free, 18 Way
Receptacle, Free, 20 Way
Part Number
MC34505
MC34507
MC34509
MC34511
MC34513
MC34515
MC34889
MC34549
MC34891
MC34551
Description
Plug, Panel Mount, 2 Way
Plug, Panel Mount, 4 Way
Plug, Panel Mount, 6 Way
Plug, Panel Mount, 8 Way
Plug, Panel Mount, 10 Way
Plug, Panel Mount, 12 Way
Plug, Panel Mount, 14 Way
Plug, Panel Mount, 16 Way
Plug, Panel Mount, 18 Way
Plug, Panel Mount, 20 Way
Part Number
MC34517
MC34519
MC34521
MC34523
MC34525
MC34527
MC34893
MC34553
MC34895
MC34555
