TS9004
Low-Power Single/Dual-Supply Quad Comparator with Reference
FEATURES
♦ Ultra-Low Quiescent Current:
5.1μA (max), All comparators plus Reference
♦ Single or Dual Power Supplies:
Single: +2.5V to +11V
Dual: ±1.25V to ±5.5V
♦ Input Voltage Range Includes Negative Supply
♦ 7μs Propagation Delay
♦ Push-pull TTL/CMOS-Compatible Outputs
♦ Separate Output GND Pin
♦ Crowbar-Current-Free Switching
♦ Continuous Source Current Capability: 40mA
♦ Internal 1.182V ±0.75% Reference
♦ 16-pin Narrow SOIC Package
DESCRIPTION
The TS9004 low-voltage, micropower quad analog
comparator is form-factor identical to the MAX934
analog comparator
with improved
electrical
specifications. Ideal for 3V or 5V single-supply
applications, the TS9004 draws 22% lower supply
current with a 50%-better initial accuracy reference
voltage. The TS9004 joins Touchstone’s TS9001-1/2
and TS9002 analog comparators in the “NanoWatt
Analog™” high performance analog integrated
circuits portfolio. This quad comparator can operate
from single +2.5V to +11V supplies or from ±1.25V to
±5.5V dual supplies.
The TS9004 exhibits an input voltage range from the
negative supply rail to within 1.3V of the positive
supply. In addition, its push-pull output stage is
TTL/CMOS compatible and capable of sinking and
sourcing current. It also incorporates an internal
1.182V ±0.75% voltage reference. A GND connection
available at the TS9004’s output stage enables TTL
compatibility and bipolar-to-single ended conversion.
The TS9004 is fully specified over the -40ºC to +85ºC
temperature range and is available in a 16-pin narrow
SOIC package.
APPLICATIONS
Threshold Detectors
Window Comparator
Level Translators
Oscillator Circuits
Battery-Powered Systems
TYPICAL APPLICATION CIRCUIT
Using a TS9004 in a 5V Bar-Graph Level Gauge Application
The Touchstone Semiconductor logo is a registered
trademark of Touchstone Semiconductor, Incorporated.
Page 1
© 2012 Touchstone Semiconductor, Inc. All rights reserved.
TS9004
ABSOLUTE MAXIMUM RATINGS
Supply Voltage (V+ to V-, V+ to GND, GND to V-)......-0.3V, +12V
Voltage Inputs
(IN+, IN-)..............................................(V+ + 0.3V) to (V- - 0.3V)
Output Voltage
REF..................................................... (V+ + 0.3V) to (V- - 0.3V)
OUT ................................................(V+ + 0.3V) to (GND - 0.3V)
Input Current (IN+, IN-)...........................................................20mA
Output Current
REF…………………………………………………………….20mA
OUT………………………………………………………...….40mA
Output Short-Circuit Duration (V+ ≤ 5.5V) ....................Continuous
Continuous Power Dissipation (T
A
= +70°C)
16-Pin SOIC (derate 8.7mW/°C above +70°C) ................696mW
Operating Temperature Ranges..............................-40°C to +85°C
Storage Temperature Range ................................-65°C to +150°C
Lead Temperature (soldering, 10s) .....................................+300°C
Electrical and thermal stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These
are stress ratings only and functional operation of the device at these or any other condition beyond those indicated in the operational sections
of the specifications is not implied. Exposure to any absolute maximum rating conditions for extended periods may affect device reliability and
lifetime.
PACKAGE/ORDERING INFORMATION
ORDER NUMBER
TS9004ISN16TP
PART
CARRIER QUANTITY
MARKING
Tube
TS9004I
Tape
& Reel
48
2500
TS9004ISN16T
Lead-free Program:
Touchstone Semiconductor supplies only lead-free packaging.
Consult Touchstone Semiconductor for products specified with wider operating temperature ranges.
Page 2
TS9004DS r1p0
RTFDS
TS9004
ELECTRICAL CHARACTERISTICS – 5V OPERATION
V+ = 5V, V- = GND = 0V; T
A
= -40ºC to +85ºC, unless otherwise noted. Typical values are at T
A
= +25ºC. See Note 1.
PARAMETER
POWER REQUIREMENTS
Supply Voltage Range
Supply Current
COMPARATOR
Input Offset Voltage
Input Leakage Current (IN-, IN+)
Input Common-Mode Voltage Range
Common-Mode Rejection Ratio
Power-Supply Rejection Ratio
Output Voltage Noise
Response Time
(High-to-Low Transition)
Response Time
(Low-to-High Transition)
Output High Voltage
Output Low Voltage
REFERENCE
Reference Voltage
Reference Line Regulation
Source Current
Sink Current
Output Voltage Noise
2.5V ≤ (V+ - V-) ≤ 5V
ΔVREF = 1%
ΔVREF = 1%
100Hz to 100kHz
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
-40°C to +85°C
1.173
1.164
20
6
10
4
1.182
0.25
25
15
100
1.191
1.199
V
mV/V
μA
μA
μV
RMS
V
CM
= 2.5V
IN+ = IN- = 2.5V
V- to (V+ – 1.3V)
V+ = 2.5V to 11V
100Hz to 100kHz
Overdrive = 10 mV
Overdrive = 100 mV
Overdrive = 10 mV
T
A
= +25°C, 100pF Load
Overdrive = 100 mV
-40°C to +85°C; I
OUT
= 17mA
-40°C to +85°C; I
OUT
= 1.8mA
Dual Supply
-40°C to +85°C; I
OUT
= 1.8mA
T
A
= +25°C, 100pF Load
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
-40°C to +85°C
V-
0.1
0.1
20
17
7
17
7
V+ – 0.4
GND + 0.4
V- + 0.4
±4.5
±10
±2
±5
V+ – 1.3V
1
1
mV
nA
V
mV/V
mV/V
μV
RMS
μs
μs
V
V
V
CONDITIONS
See Note 2
IN+ = IN- + 100mV
T
A
= +25°C
-40°C to +85°C
MIN
2.5
4.1
TYP
MAX
11
5.1
8
UNITS
V
µA
±0.01
±0.01
TS9004DS r1p0
Page 3
RTFDS
TS9004
ELECTRICAL CHARACTERISTICS – 3V OPERATION
V+ = 3V, V- = GND = 0V; T
A
= -40ºC to +85ºC, unless otherwise noted. Typical values are at T
A
= +25ºC. See Note 1.
PARAMETER
POWER REQUIREMENTS
Supply Current
COMPARATOR
Input Offset Voltage
Input Leakage Current (IN-, IN+)
Input Common-Mode Voltage Range
Common-Mode Rejection Ratio
Power-Supply Rejection Ratio
Output Voltage Noise
Response Time
(High-to-Low Transition)
Response Time
(Low-to-High Transition)
Output High Voltage
Output Low Voltage
REFERENCE
Reference Voltage
Reference Line Regulation
Source Current
Sink Current
2.5V ≤ (V+ - V-) ≤ 3V
ΔVREF = 1%
ΔVREF = 1%
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
-40°C to +85°C
1.173
1.164
20
6
10
4
1.182
0.25
25
15
1.191
1.199
V
mV/V
μA
μA
V
CM
= 1.5V
IN+ = IN- = 1.5V
V- to (V+ – 1.3V)
V+ = 2.5V to 11V
100Hz to 100kHz
Overdrive = 10 mV
Overdrive = 100 mV
Overdrive = 10 mV
T
A
= +25°C, 100pF Load
Overdrive = 100 mV
-40°C to +85°C; I
OUT
= 10mA
-40°C to +85°C; I
OUT
= 0.8mA
Dual Supply
-40°C to +85°C; I
OUT
= 0.8mA
T
A
= +25°C, 100pF Load
T
A
= +25°C
-40°C to +85°C
T
A
= +25°C
-40°C to +85°C
V-
0.2
0.1
20
17
7
17
7
V+ – 0.4
GND + 0.4
V- + 0.4
±4.5
±10
±1
±2.5
V+ – 1.3V
1
1
mV
nA
V
mV/V
mV/V
μV
RMS
µs
μs
V
V
V
CONDITIONS
IN+ = IN- + 100mV
T
A
= +25°C
-40°C to +85°C
MIN
TYP
3.8
MAX
4.8
6.5
UNITS
µA
±0.01
±0.01
Output Voltage Noise
100Hz to 100kHz
100
μV
RMS
Note 1:
All specifications are 100% tested at T
A
= +25°C. Specification limits over temperature (T
A
= T
MIN
to T
MAX
) are guaranteed by device
characterization, not production tested.
Note 2:
The TS9004 comparator operates below 2.5V. Refer to the “Low-Voltage Operation: V+ = 1.5V” section.
Page 4
TS9004DS r1p0
RTFDS
TS9004
TYPICAL PERFORMANCE CHARACTERISTICS
V
+
= 5V; V
-
= GND; T
A
= +25°C, unless otherwise noted.
Output Voltage Low
vs Load Current
2.5
V+ = 5V
2
4.5
4
1.5
V
OL
- V
V
OH
- V
V+ = 3V
1
3.5
3
2.5
0.5
2
0
0
4
8
12
16
20
24
28
LOAD CURRENT - mA
Reference Output Voltage vs
Output Load Current
1.190
V+ = 3V or 5V
1.185
REFERENCE VOLTAGE - V
REFERENCE VOLTAGE - V
1.180
1.175
1.170
1.165
1.160
1.155
0
5
10
15
20
25
30
SOURCE
SINK
1.21
1.20
1.19
1.18
1.17
1.16
1.15
1.14
-40
-15
10
35
60
85
1.22
1.5
0
10
20
30
40
50
LOAD CURRENT - mA
Reference Voltage vs Temperature
V+ = 3V
V+ = 5V
5
Output Voltage High vs
Load Current
LOAD CURRENT - µA
Supply Current vs Temperature
10
IN+ = IN- + 100mV
9
SUPPLY CURRENT - µA
SUPPLY CURRENT - µA
8
7
6
V+ = 5V, V- = 0V
5
4
V+ = 3V, V- = 0V
3
2
-40
-15
10
35
60
85
TEMPERATURE - ºC
V+ = 5V, V- = -5V
10
TEMPERATURE - ºC
Supply Current vs
Low Supply Voltages
1
0.1
1.5
2
SINGLE-SUPPLY VOLTAGE - V
2.5
TS9004DS r1p0
Page 5
RTFDS
