BZX84C24-T3: DescriptionZener Diode, 24V V(Z), 5%, 0.35W, Silicon, Unidirectional, PLASTIC PACKAGE-3; CategoryDiscrete semiconductor diode; File Size150KB，5 Pages; ManufacturerSangdest Microelectronics (Nanjing) Co., Ltd.

Download Datasheet Parametric View All

BZX84C24-T3 Overview

Zener Diode, 24V V(Z), 5%, 0.35W, Silicon, Unidirectional, PLASTIC PACKAGE-3

BZX84C24-T3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Sangdest Microelectronics (Nanjing) Co., Ltd.
package instruction	R-PDSO-G3
Reach Compliance Code	unknown
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	R-PDSO-G3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.35 W
Certification status	Not Qualified
Nominal reference voltage	24 V
surface mount	YES
technology	ZENER
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	5 mA

Preview

Download Datasheet

View All

SENSITRON

SEMICONDUCTOR

Data Sheet

2597,

Rev. –

BZX84C2V4 – BZX84C39

350mW SURFACE MOUNT ZENER DIODE

Features

Planar Die Construction

350mW Power Dissipation

2.4 – 39V Nominal Zener Voltage

5% Standard Vz Tolerance

Designed for Surface Mount Application

Plastic Material – UL Recognition Flammability

Classification 94V-O

TOP VIEW

Dim

Min

0.37

1.19

2.10

0.89

0.45

1.78

2.65

0.013

0.89

0.45

0.076

Mechanical Data

Case: SOT-23, Molded Plastic

Terminals: Plated Leads Solderable per

MIL-STD-202, Method 208

Polarity: See Diagram

Weight: 0.008 grams (approx.)

Marking: Device Code (See Table Next Page)

TOP VIEW

SOT-23

Max

Min

0.51 0.014

1.40 0.047

2.50 0.083

1.05 0.035

0.61 0.018

2.05

0.07

3.05 0.104

0.15 0.0005

1.10 0.035

0.61 0.018

0.17 0.003

Max

0.020

0.055

0.098

0.041

0.024

0.081

0.120

0.006

0.043

0.024

0.007

In mm

In inch

Maximum Ratings

=25° unless otherwise specified

Characteristic

Symbol

Value

Unit

Peak Pulse Power Dissipation at T

= 25° (Note 1)

350

Forward Voltage @ I

= 10mA

0.9

Thermal Resistance Junction to Ambient (Note 1)

357

C/W

Operating and Storage Temperature Range

, T

STG

-65 to +150

Note: 1. Valid provided that device terminals are kept at ambient temperature.

•

!!"#$•

•

% & '(&)*+,,---. &

./0•12&%#

%3 &

./0•

SENSITRON

SEMICONDUCTOR

TECHNICAL DATA

DISCLAIMER:

1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product

characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version

of the datasheet(s).

2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment,

medical equipment, and safety equipment), safety should be ensured by using semiconductor devices that feature assured safety or by

means of users’ fail-safe precautions or other arrangement.

3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during

operation of the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual

property claims or any other problems that may result from applications of information, products or circuits described in the datasheets.

4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from

use at a value exceeding the absolute maximum rating.

5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.

6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of

Sensitron Semiconductor.

7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will

hinder maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third

party. When exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and

regulations.

•

221 West Industry Court

Deer Park, NY 11729-4681

(631) 586-7600 FAX (631) 242-9798

•

World Wide Web - http://www.sensitron.com

•

E-Mail Address - sales@sensitron.com

•
