DIGITRON SEMICONDUCTORS
1N746 – 1N759A
1N4370-1N4372A
MAXIMUM RATINGS
Operating and Storage Temperature
Thermal Resistance
Steady State Power
Forward Voltage @ 200mA
Solder Temperatures:
-65 to +175°C
250°C/W junction to lead at 3/8” lead length from body
0.5 Watts at T
L
≤
50°C
1.1 Volts
260°C for 10 s (max)
SILICON PLANAR POWER ZENER DIODES
ELECTRICAL CHARACTERISTICS
@ 25°C unless otherwise specified
Part
Number
(Note 1)
Normal Zener
Voltage
V
Z
@ l
ZT
(Note 2)
Zener
Test
Current
l
ZT
mA
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Maximum
Zener
Impedance
Z
ZT
@ l
ZT
(Note 3)
Maximum Reverse
Leakage Current
V
R
= 1 Volt
Maximum
Zener
Current
l
ZM
(Note 4)
Typical
Temperature
Coefficient
Of Zener
Voltage
%/°C
-.085
-.080
-.075
-.066
-.058
-.046
-.033
-.015
±.010
+.030
+.049
+.053
+.057
+.060
+.061
+.062
+.062
VOLTS
1N4370
1N4371
1N4372
1N746
1N747
1N748
1N749
1N750
1N751
1N752
1N753
1N754
1N755
1N756
1N757
1N758
1N759
Notes:
OHMS
30
30
29
28
24
23
22
19
17
11
7
5
6
8
10
17
30
μA
@ 25°C
100
75
50
10
10
10
2
2
1
1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
μA
@ 125°C
200
150
100
30
30
30
30
30
20
20
20
20
20
20
20
20
20
mA
150
135
120
110
100
95
85
75
70
65
60
55
50
45
40
35
30
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
12
1. Suffix letter A denotes ±5% tolerance, suffix C denotes ±2% tolerance, & suffix D denotes ±1% tolerance.
2. Voltage measurements to be performed 20 seconds after application of dc current.
3. Zener impedance derived by superimposing on l
ZT
, a 60cps, rms ac current equal to 10% l
ZT
(2mA ac)
4. Allowance has been made for the increase in V
Z
due to Z
Z
and for the increase in junction temperature as the unit approaches thermal equilibrium at the power
dissipation of 400mW.
MECHANICAL CHARACTERISTICS
Case:
Marking:
Polarity:
DO-35 Glass
Alpha Numeric
Cathode Band
Dimensions
Inches
Min
BD
BL
LD
LL
0.055
0.120
0.018
1.000
Max
0.090
0.200
0.022
1.500
Millimeters
Min
1.400
3.050
0.460
25.400
Max
2.290
5.080
0.559
38.100
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20120705
DIGITRON SEMICONDUCTORS
1N746 – 1N759A
1N4370-1N4372A
SILICON PLANAR POWER ZENER DIODES
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix)
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20120705
