LED-Anzeigesysteme

In die Entwicklung dieser Bausteine ist

das über Jahrzehnte erworbene Know-

how der Firma MENTOR als Entwickler

und Lieferant von Bauelementen für die

Industrieelektronik geflossen. Die Baue-

lementen-Vielfalt erstreckt sich von THT-

Einzelanzeigen in unterschiedlichsten

Ausführungen über THT-LED-Leisten,

Flächenausleuchtsystemen, Signallam-

pen bis hin zu Lampenfassungen. THT-

Ausführungen kennzeichnen Bauteile in

Durchstecktechnik.

Der Einsatz dieser Bausteine ist überall

dort zu suchen, wo Licht flimmert, strahlt

oder blinkt, wo Lichtsignale auf Funkti-

onen oder Betriebszustände aufmerksam

machen sollen und müssen.

Den sich ständig verändernden Anforde-

rungen unserer Kunden begegnen wir mit Kompetenz und Innovationskraft und

der sich daraus ergebenden Möglichkeit, neben Standardlösungen auch spezielle

Kundenwünsche zu erfüllen.

LED Display Systems

The development of these components

benefited from decades of experience

gained by MENTOR in developing and

supplying components for industrial

electronics. The range of components

stretches from individual THT displays in

various versions via THT LED bars, sur-

faces made from illumination systems,

and signaling lamps all the way to lamp

sockets. THT versions designate compon-

ents in hole-mounted technology.

The area of application of these compo-

nents covers any scenario where light

flickers, radiates or flashes where light

signals should and must draw attention

to functions or operating status.

We meet our customer‘s constantly

changing demands with competency

and innovative energy, thus being able to fulfil not only standard solutions but

also to meet customer specific requirements.

Allgemeine technische Daten

(Auswahl bzw. Abweichungen zu den folgenden allgem. Daten: siehe Beschreibung des jeweiligen Artikels)

Lötbarkeit

DIN IEC 68-2-20 (260°C

≤

5s)

Anschlüsse

verzinnt

Betriebstemperatur

-40°C ... +85°C

Klima

GPF DIN 40040

Beschriftung

auf Sonderwunsch bedruckt oder gelasert

Bestückung mit LED‘s

Technische Daten siehe Seite 65/66

Sonderwünsche

Sonderbestückung, Verwendung von zusätzlichen Fixierpins sowie umgekehrte Polarität auf Anfrage möglich.

Mindestbestellmengen für Sonderausführungen auf Anfrage.

General Technical Data

(Selection and deviations from the following general data: see description of the respective item)

Solderability

DIN IEC 68-2-20 (260°C

≤

5s)

Terminals

tinned

Operatin temperature

-40°C ... +85°C

Climate

GPF DIN 40040

Marking

On special request printed or laser printed

LED’s

Technical data see page 65/66

Special requirements

Special components, use of additional fixing pins and reverse polarity on request

Minimum quantity for special design on request.

Magerdruck keine Lagerware · Bestellmenge und Preise auf Anfrage · Articles in roman typefaces not in stock · Order quantities and prices on request
