DIGITRON SEMICONDUCTORS
1N5629-1N5665
MAXIMUM RATINGS
Operating and Storage Temperature
DC Power Dissipation
Thermal Resistance
1500 watts for 10/1000
μs
with repetition rate of 0.01 @
T
L
= 25°C
Forward surge current:
Solder Temperatures:
-65 to +175°C
1 watt @ T
L
≤
125°C, 3/8” from body
50°C/W junction to lead at 0.375” from body or 110°C/W
junction to ambient when mounted on FR4 PC board with 4
mm
2
copper pads and track width 1 mm, length 25 mm
200 amps for 8.3 ms half-sine wave @ T
A
= 25°C
260°C for 10 s (maximum)
TRANSIENT ABSORPTION ZENER
ELECTRICAL CHARACTERISTICS
Breakdown
Voltage
(V
BR
) @ I
T
Min
Vdc
Type #
Test
Current
(l
T
)
mAdc
Max
Vdc
Rated
Standoff
Voltage
(V
WM
)
V
Maximum
Reverse
Leakage
Current
(l
D
@
V
WM
)
μAdc
Maximum
Peak Pulse
Reverse
Voltage
(V
C
max @
l
pp
)
V
Maximum
Peak Pulse
Current
(l
pp
)
A
Maximum
Temperature
Coefficient
of V
(BR)
α
VZ
%/°C
1N5629
1N5629A
1N5630
1N5630A
1N5631
1N5631A
1N5632
1N5632A
1N5633
1N5633A
1N5634
1N5634A
1N5635
1N5635A
1N5636
1N5636A
1N5637
1N5637A
1N5638
1N5638A
1N5639
1N5639A
1N5640
1N5640A
1N5641
1N5641A
1N5642
1N5642A
1N5643
1N5643A
1N5644
1N5644A
1N5645
6.12
6.45
6.75
7.13
7.38
7.79
8.19
8.65
9.00
9.5
9.9
10.5
10.8
11.4
11.7
12.4
13.5
14.3
14.4
15.2
16.2
17.1
18.0
19.0
19.8
20.9
21.6
22.8
24.3
25.7
27.0
28.5
29.7
7.48
7.14
8.25
7.88
9.02
8.61
10.0
9.55
11.0
10.5
12.1
11.6
13.2
12.6
14.3
13.7
16.5
15.8
17.6
16.8
19.8
18.9
22.0
21.0
24.2
23.1
26.4
25.2
29.7
28.4
33.0
31.5
36.3
10
10
10
10
10
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
5.50
5.80
6.05
6.40
6.63
7.02
7.37
7.78
8.10
8.55
8.92
9.40
9.72
10.2
10.5
11.1
12.1
12.8
12.9
13.6
14.5
15.3
16.2
17.1
17.8
18.8
19.4
20.5
21.8
23.1
24.3
25.6
26.8
1000
1000
500
500
200
200
50
50
10
10
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
10.8
10.5
11.7
11.3
12.5
12.1
13.8
13.4
15.0
14.5
16.2
15.6
17.3
16.7
19.0
18.2
22.0
21.2
23.5
22.5
26.5
25.2
29.1
27.7
31.9
30.6
34.7
33.2
39.1
37.5
43.5
41.4
47.7
139
143
128
132
120
124
109
112
100
103
93
96
87
90
79
82
68
71
64
67
56.5
59.5
51.5
54
47
49
43
45
38.5
40
34.5
36
31.5
.057
.057
.061
.061
.065
.065
.068
.068
.073
.073
.075
.075
.078
.078
.081
.081
.084
.084
.086
.086
.088
.088
.090
.090
.092
.092
.094
.094
.096
.096
.097
.097
.098
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
DIGITRON SEMICONDUCTORS
1N5629-1N5665
ELECTRICAL CHARACTERISTICS (Cont’d)
Type #
Breakdown
Voltage
(V
BR
) @ I
T
Min
Vdc
TRANSIENT ABSORPTION ZENER
Rated
Standoff
Voltage
(V
WM
)
V
Test
Current
(l
T
)
mAdc
Max
Vdc
Maximum
Reverse
Leakage
Current
(l
D
@ V
WM
)
μAdc
Maximum Peak
Pulse Reverse
Voltage
(V
C
max @ l
pp
)
V
Maximum
Peak Pulse
Current
(l
pp
)
A
Maximum
Temperature
Coefficient
of V
(BR)
α
VZ
%/°C
1N5645A
1N5646
1N5646A
1N5647
1N5647A
1N5648
1N5648A
1N5649
1N5649A
1N5650
1N5650A
1N5651
1N5651A
1N5652
1N5652A
1N5653
1N5653A
1N5654
1N5654A
1N5655
1N5655A
1N5656
1N5656A
1N5657
1N5657A
1N5658
1N5658A
1N5659
1N5659A
1N5660
1N5660A
1N5661
1N5661A
1N5662
1N5662A
1N5663
1N5663A
1N5664
1N5664A
1N5665
1N5665A
31.4
32.4
34.2
35.1
37.1
38.7
40.9
42.3
44.7
45.9
48.5
50.4
53.2
55.8
58.9
61.2
64.6
67.5
71.3
73.8
77.9
81.9
86.5
90
95
99
105
108
114
117
124
135
143
144
152
153
162
162
171
180
190
34.7
39.6
37.8
42.9
41.0
47.3
45.2
51.7
49.4
56.1
53.6
61.6
58.8
68.2
65.1
74.8
71.4
82.5
78.8
90.2
86.1
100.0
95.5
110
105
121
116
132
126
143
137
165
158
176
168
187
179
198
189
220
210
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
28.2
29.1
30.8
31.6
33.3
34.8
36.8
38.1
40.2
41.3
43.6
45.4
47.8
50.2
53.0
55.1
58.1
60.7
64.1
66.4
70.1
73.7
77.8
81.0
85.5
89.2
94.0
97.2
102
105
111
121
128
130
136
138
145
146
154
162
171
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
45.7
52.0
49.9
56.4
53.9
61.9
59.3
67.8
64.8
73.5
70.1
80.5
77.0
89.0
85.0
98.0
92.0
108
103
118
113
131
125
144
137
158
152
173
165
187
179
215
207
230
219
244
234
258
246
287
274
33
29
30
26.5
28
24
25.3
22.2
23.2
20.4
21.4
18.6
19.5
16.9
17.7
15.3
16.3
13.9
14.6
12.7
13.3
11.4
12.0
10.4
11.0
9.5
9.9
8.7
9.1
8.0
8.4
7.0
7.2
6.5
6.8
6.2
6.4
5.8
6.1
5.2
5.5
.098
.099
.099
.100
.100
.101
.101
.101
.101
.102
.102
.103
.103
.104
.104
.104
.104
.105
.105
.105
.105
.106
.106
.106
.106
.107
.107
.107
.107
.107
.107
.108
.108
.108
.108
.108
.108
.108
.108
.108
.108
V
(BR)
is measured after l
T
has been applied for
≤
300ms. Forward voltage V
F
at 100 amps peak 8.3 msec is 3.5 volts max.
Forward current l
F
shall be applied for 30 secs, before V
F
is measured.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
DIGITRON SEMICONDUCTORS
1N5629-1N5665
TRANSIENT ABSORPTION ZENER
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
DIGITRON SEMICONDUCTORS
1N5629-1N5665
MECHANICAL CHARACTERISTICS
Case:
Polarity:
Marking:
DO-13
Cathode Connected to Case & Polarity indicated by diode symbol
Part number & polarity diode symbol
TRANSIENT ABSORPTION ZENER
Dimensions
1N5629-1N5665
Inches
Min
A
B
C
D
E
F
G
-
0.315
1.250
1.250
-
-
0.026
Max
0.235
0.350
-
-
0.210
0.090
0.035
Millimeters
Min
-
8.001
31.750
31.750
-
-
0.660
Max
5.970
8.890
-
-
5.334
2.286
0.889
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
