DIGITRON SEMICONDUCTORS
1N6373 – 1N6389
1500 WATT LOW CLAMPING FACTOR
TRANSIENT VOLTAGE SUPPRESSOR
•
•
•
Unidirectional and bidirectional TVS series for thru-hole mounting
Suppresses transients up to 1500 watts @ 10/1000
μs
t
clamping
(0 volts to V
(BR)
min):
Unidirectional – Less than 100 pico seconds
Bidirectional – Less than 5 nano seconds
•
•
•
•
•
•
Working voltage (V
WM
) range 5 V to 45 V
Low clamping factor (ratio of actual V
C
/V
BR
): 1.33 @ full rated power and 1.20 @ 50% rated power
Economical plastic encapsulated TVS for thru-hole mount
Surface mount equivalent packages also available
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix)
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
MAXIMUM RATINGS
1500 Watts for 10/1000
μs
with repetition rate of 0.01% or less* at lead temperature (T
L
) 25°C
(See figures 1, 2, & 4)
Operating and Storage Temperature:
Thermal Resistance:
-65°C to +150°C
22°C/W junction to lead at
⅜”
from body or 82°C/W junction to
ambient when mounted on FR4 PC board with 4mm
2
copper pads
and track width 1 mm, length 25mm
5 watts at T
L
≤
40°C, or 1.52 watts at T
A
= 25°C when mounted
on FR4 PC board described for thermal resistance
260°C for 10 s (maximum)
Steady State Power Dissipation:*:
Solder Temperatures:
*
TVS devices are not typically used for dc power dissipation and are instead operated at or less than their rated standoff voltage (V
WM
) except for
transients that briefly drive the device into avalanche breakdown (V
BR
to V
C
region).
ELECTRICAL CHARACTERISTICS @ 25°C
(Unidirectional)
Stand-Off
Voltage
(Note 1)
Maximum
Reverse
Leakage @
V
WM
l
D
μA
300
25
2
2
2
2
2
2
2
25
2
2
2
2
Minimum*
Breakdown
Voltage @
1.0 mA
V
(BR) (min)
VOLTS
6.0
9.4
11.7
14.1
17.6
21.2
25.9
42.4
52.9
9.4
11.7
14.1
17.6
21.2
Maximum
Clamping
Voltage
(Fig. 2)
l
PP1
= 1A
V
C
VOLTS
7.1
11.3
13.7
16.1
20.1
24.2
29.8
50.6
63.3
11.4
14.1
16.7
20.8
24.8
Maximum
Clamping
Voltage
(Fig. 2)
@
l
PP2
= 10A
V
C
VOLTS
7.5
11.5
14.1
16.5
20.6
25.2
32.0
54.3
70.0
11.6
14.5
17.1
21.4
25.5
Maximum
Peak Pulse
Current
Part
Number
Direction
V
WM
VOLTS
1N6373
1N6374
1N6375
1N6376
1N6377
1N6378
1N6379
1N6380
1N6381
1N6382
1N6383
1N6384
1N6385
1N6386
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Unidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
5.0
8.0
10.0
12.0
15.0
18.0
22.0
36.0
45.0
8.0
10.0
12.0
15.0
18.0
l
PP3
A
160
100
90
70
60
50
40
23
19
100
90
70
60
50
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
DIGITRON SEMICONDUCTORS
1N6373 – 1N6389
1500 WATT LOW CLAMPING FACTOR
TRANSIENT VOLTAGE SUPPRESSOR
ELECTRICAL CHARACTERISTICS @ 25°C
(Bidirectional)
Stand-Off
Voltage
Part
Number
Direction
(Note 1)
V
WM
VOLTS
1N6387
1N6388
1N6389
Bidirectional
Bidirectional
Bidirectional
22.0
36.0
45.0
Maximum
Reverse
Leakage
l
D
μA
2
2
2
Minimum*
Breakdown
Voltage @
1.0 mA
V
(BR) (min)
VOLTS
25.9
42.4
52.9
Maximum
Clamping
Voltage
l
PP1
= 1A
V
C
VOLTS
30.8
50.6
63.3
Maximum
Clamping
Voltage @
l
PP2
= 10A
V
C
VOLTS
32.0
54.3
70.0
Maximum
Peak Pulse
Current
l
PP3
A
40
23
19
Note 1: TVS devices are normally selected according to the reverse “Stand Off Voltage” (V
WM
) which should be equal to or greater than dc or
continuous peak operating voltage level.
•
For bidirectional parts, add suffix C at end of the part number.
*
The minimum breakdown voltage as shown takes into consideration the ±1 volt tolerance normally specified for power supply regulation on
most integrated circuit manufacturers data sheets. Similar devices are available with reduced clamping voltages where tighter regulated power
supply voltages are employed.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121016
