100 SM PC Series
Powertron
•
•
•
•
•
•
•
Resistances to 25MOhms
Resistance Tolerances to ±0.005%
Temperature Coefficients of ±1 ppm/K
Power Ratings to 2W
100% Acceptance Tested / Traceable to NIST
Long Term Stability / 100ppm/year
Matched Resistance Sets to ±0.001% and ±0.5 ppm/K
SPECIFICATIONS
Type
Commercial
Wattage
( Watts )
0.06
0.08
0.10
0.10
0.12
0.15
0.15
0.175
0.20
0.20
0.25
0.25
0.33
0.40
0.50
0.75
1.00
1.50
2.00
Maximum Ohms
Minimum
Tolerance
(%)
Dimensions
Diameter
±0.005”
[±0.13mm]
Length
±0.025”
[±0.64mm]
Lead Diameter
1
±0.002”
[±0.05mm]
Maximum
Working
Voltage
75
100
100
100
150
150
100
200
200
200
250
300
400
300
400
600
800
900
1000
SM-2
SM-3
SM-4
SM-13
SM-5
SM-6
139A
SM-15
SM-12
100
SM-7
101
102
120
121
129
106
107
108
75k
150k
250k
250k
400k
500k
500k
750k
750k
800k
1M
1.2M
2.5M
3.8M
3.8M
10M
12M
15M
25M
0.005
0.100 [2.5]
0.125 [3.2]
0.125 [3.2]
0.156 [4.0]
0.187 [4.7]
0.187 [4.7]
0.250 [6.4]
0.187 [4.7]
0.187 [4.7]
0.250 [6.4]
0.210 [5.3]
0.250 [6.4]
0.250 [6.4]
0.375 [9.5]
0.375 [9.5]
0.375 [9.5]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
0.210 [5.3]
0.260 [6.6]
0.375 [9.5]
0.312 [7.9]
0.250 [6.4]
0.295 [7.5]
0.250 [6.4]
0.375 [9.5]
0.450 [11.4]
0.375 [9.5]
0.465 [11.8]
0.500 [12.7]
0.750 [19.1]
0.500 [12.7]
0.750 [19.1]
1.000 [25.4]
1.000 [25.4]
1.500 [38.1]
2.000 [50.8]
1
0.020 [0.5]
0.020 [0.5]
0.025 [0.6]
0.020 [0.5]
0.020 [0.5]
0.025 [0.6]
0.025 [0.6]
0.025 [0.6]
0.025 [0.6]
0.020 [0.5]
0.025 [0.6]
0.032 [0.8]
0.025 [0.6]
0.025 [0.6]
0.032 [0.8]
0.025 [0.6]
0.032 [0.8]
0.025 [0.6]
0.032 [0.8]
0.032 [0.8]
0.032 [0.8]
0.032 [0.8]
0.032 [0.8]
0.032 [0.8]
Where more than one lead is listed / the top value is Standard
Lead Length = 1.50 [38] Min.
Ordering Information
Part Number - Resistance - Tolerance - TCR ( If not standard )
Example: SM-6 25kOhms 0.1%
Document Number: 64300
Revision: 20-09-10
For technical questions, contact:
powertron@vishaypg.com
www.powertron.de
1
100 SM PC Series
Powertron
SPECIFICATIONS
(continued)
PC Series
Type
Commercial
Wattage
( Watts )
0.125
0.125
0.125
0.25
0.40
0.50
Maximum
Ohms
500k
500k
500k
600k
800k
1M
0.005
Minimum
Tolerance
(%)
Dimensions
Diameter
±0.005”
[±0.13mm]
Length
±0.025”
[±0.64mm]
Lead Diameter1
±0.002”
[±0.05mm]
Lead Spacing
±0.015”
[±0.4mm]
Maximum
Working
Voltage
150
150
150
150
300
400
100PC
130PC
131PC
101PC
120PC
104PC
0.250 [6.4]
0.250 [6.4]
0.250 [6.4]
0.250 [6.4]
0.375 [9.5]
0.500 [12.7]
0.375 [9.5]
0.312 [7.9]
0.312 [7.9]
0.500 [12.7]
0.500 [12.7]
0.500 [12.7]
1
0.025 [0.6]
0.025 [0.6]
0.025 [0.6]
0.025 [0.6]
0.032 [0.8]
0.032 [0.8]
0.025 [0.6]
0.150 [3.8]
0.150 [3.8]
0.200 [5.1]
0.150 [3.8]
0.200 [5.1]
0.300 [7.6]
Where more than one lead is listed / the top value is Standard
Lead Length = 1.00 [25] Min.
Rectangular Series
Type
Commercial
Wattage
( Watts )
0.125
0.250
0.300
0.500
Maximum
Ohms
500k
750k
500k
1M
Dimensions
Width
±0.010”
[±0.25mm]
Height
±0.025”
[±0.64mm]
Length
±0.010”
[±0.25mm]
Lead Diameter
1
±0.002”
[±0.05mm]
Lead Spacing
±0.015”
[±0.4mm]
Maximum
Working
Voltage
150
150
150
150
SM-8
SM-9
SP5086
SP5232
0.140 [3.6]
0.150 [3.8]
0.102 [2.6]
0.160 [4.1]
0.250 [6.4]
0.270 [6.9]
0.320 [8.1]
0.525 [13.3]
0.270 [6.9]
0.540 [13.7]
0.300 [7.6]
0.585 [14.9]
0.032 [0.8]
0.032 [0.8]
0.025 [0.6]
0.032 [0.8]
0.125 [3.2]
0.250 [6.4]
0.150 [3.8]
0.400 [10.2]
1
Lead Length = 1.00 [25] Min.
Specification
Tolerances
Temperature Coefficient
( Standard )
( down to 1ppm on request )
Value
±0.005% to ±1% ( See Derating Curve )
>100W : ±10ppm/K
10W to100W : ±20ppm/K
<10W : ±30ppm/K
-55°C to +145°C ( See Derating Curve )
Temperature Range
180
Power Derating Curve
1% /
0.05%
Notes:
( Contact Factory for these options )
Fast Rise Time -
These resistors are available in
a low reactance design for fast rise time and ex-
tended frequency response.
High Stability -
These resistors are available in
a High Stability version with maximun resistance
change of ±20ppm/year under normal conditions.
High TC -
These resistors are available in High TC
configurations. Standard TC’s are +2600 / +3850 /
+4500 / +5000 / and +6000 ppm/K.
Percentage of Rated Power
160
140
120
100
80
60
40
20
0
0
20
40
0.5%
/ 0.1%
/ 0.02%
Toler
a
Tolera
n
nce
0.01% T
oleranc
e
0.005% Tolera
nce
ce
Ambient Temperature °C
60
80
100
120
140
160
www.powertron.de
2
For technical questions, contact:
powertron@vishaypg.com
Document Number: 64300
Revision: 20-09-10
