DIGITRON SEMICONDUCTORS
MAC10 SERIES
MAC11 SERIES
SILICON BIDIRECTIONAL THYRISTORS
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
MAXIMUM RATINGS
Rating
Peak repetitive off-state voltage
(1)
(T
J
= 100°C)
MAC10-1,MAC11-1
MAC10-2,MAC11-2
MAC10-3,MAC11-3
MAC10-4,MAC11-4
MAC10-5,MAC11-5
MAC10-6,MAC11-6
MAC10-7,MAC11-7
MAC10-8,MAC11-8
RMS on-state current
(T
C
= 75°C)
Peak non-repetitive surge current
(1 cycle, 60Hz, T
J
= -40 to + 100°C)
Circuit fusing considerations
(T
J
= -40 to + 100°C, t = 8.3ms)
Peak gate power
Average gate power
Peak gate current
Operating junction temperature range
Storage temperature range
Mounting torque
(6-32 screw)
(2)
Symbol
Value
Unit
V
DRM
25
50
100
200
300
400
500
600
10
100
40
10
0.5
2
-40 to +100
-40 to +150
8
Volts
I
T(RMS)
I
TSM
I
2
t
P
GM
P
G(AV)
I
GM
T
J
T
stg
Amps
Amps
A
2
s
Watts
Watts
Amps
°C
°C
In. lb.
Note 1: Ratings apply for open gate conditions. Thyristor devices shall not be tested with a constant current source for blocking capability such that the voltage applied exceeds the rated blocking
voltage.
Note 2: Torque rating applies with use of torque washer. Mounting torque in excess of 8 in. lb. does not appreciably lower case to sink thermal resistance. Anode lead and heatsink contact pad are
common.
* Soldering temperatures shall not exceed 200°C
THERMAL CHARACTERISTICS
Characteristic
Thermal resistance, junction to case
Thermal resistance, junction to ambient
Symbol
R
ӨJC
R
ӨJA
Maximum
2.0
50
Unit
°C/W
°C/W
ELECTRICAL CHARACTERISTICS
(T
C
= 25°C unless otherwise noted)
Characteristic
Peak blocking current
(either direction)
(V
D
= Rated V
DRM
, gate open, T
J
= 100°C)
Peak on-state voltage
(either direction)
(I
TM
= 14A peak)
Gate trigger current
(continuous dc)
(V
D
= 12V, R
L
= 100Ω)
MT2(+),G(+); MT2(-),G(-) , MAC10, MAC11
MT2(+),G(-); MT2(-), G(+), MAC10
Gate trigger voltage
(continuous dc)
(V
D
= 12V, R
L
= 100Ω)
MT2(+),G(+); MT2(-),G(-) , MAC10, MAC11
MT2(+),G(-); MT2(-), G(+), MAC10
Gate trigger voltage
(continuous dc)
(V
D
= Rated V
DRM
, R
L
= 100Ω, T
J
= 100°C) All modes
Symbol
I
DRM
V
TM
Min
-
-
Typ.
-
1.3
Max
2.0
1.8
Unit
mA
Volts
I
GT
-
-
-
-
50
75
mA
V
GT
-
-
0.2
0.9
1.0
-
2.0
2.5
-
Volts
V
GD
Volts
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20130207
