SMT CURRENT SENSE
TRANSFORMERS
PA1005.XXX Series
Height:
5.1mm Max*
Footprint:
8.4mm x 7.2mm Max
Current Rating:
up to 20A
Frequency Range:
50kHz to 1MHz
Low Primary DCR version of P820X
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
Number
PA1005.020
PA1005.030
PA1005.040
PA1005.050
PA1005.060
PA1005.070
PA1005.100
6
PA1005.125
5,6
Turns
Ratio
1:20
1:30
1:40
1:50
1:60
1:70
1:100
1:125
Current
2
Rating
(A)
20
20
20
20
20
20
20
20
Secondary
Inductance
(mH MIN)
0.08
0.18
0.32
0.50
0.72
0.98
2.00
3.00
DCR
(mΩ MAX)
Primary
Secondary
(8-7)
(1-3)
0.75
0.75
0.75
0.75
0.75
0.75
0.75
0.75
550
870
1140
1500
2250
4750
5500
6500
Hipot
(V
RMS
)
500
500
500
500
500
500
500
500
NOTES:
1. The temperature of component (ambient temperature plus temper-ature
rise) must be within the specified operating temperature range.
2.The maximum current rating is based upon temperature rise of the
component and represents the DC current which will cause a typical
temperature rise of 40°C with no airflow when both one turn windings
connected in parallel.
3. To calculate value of terminating resistor (Rt) use the following formula:
Rt (Ω) =V
REF
* N / (Ipeak_primary)
4. The peak flux density of the device must remain below 2000 Gauss. To
calculate the peak flux density for uni-polar current use following formula:
Bpk = 37.59 * V
REF
* (Duty_Cycle_Max) * 10
5
/ (N * Freq_kHz)
* for bi-polar current applications divide Bpk (as calculated above) by 2.
5. Optional Tape & Reel packaging can be ordered by adding a "T" suffix
to the part number (i.e. PA1005.020 becomes PA1005.020T). Pulse
complies to industry standard tape and reel specification EIA481.
6. To order RoHS compliant part, add the suffix "NL" to the part number
(i.e. PA1005.020 becomes PA1005.020NL and PA1005.020T becomes
PA1005.020NLT). Please note that the PA1005.125 part is not available
in an RoHS compliant version.
Mechanical
RECOMMENDED
PAD LAYOUT
.073
1,85
.050
1,27
.050
1,27
Schematic
8
7
Iprimary
Isecondary
1
N
Vref
1
3
4
3
xxx
.120
3,05
.060
1,52
.106
2,69
.100
2,54
5
6
2
1
Pin 1
.190
*
4,83 NOM
.006/0,15
8 SURFACES
RT
.330
8,38 MAX
Pin 8
6
1
2
3
Pin 7
.010
0,25
APPLICATION CIRCUIT
.284
7,21 MAX
.073
1,85 NOM
BOTTOM
VIEW
5
4
*NOTE:
for RoHS compliant part,
the height is increased to:
.024
0,61
.200
5,10 NOM &
.215
5,50 MAX
Weight
. . . . . . . . . . . . . .0.34 grams
Tray
. . . . . . . . . . . . . . . . . .120/tray
Tape & Reel
. . . . . . . . . . . .900/reel
Coplanarity
. . . . . . . . .0.004 inches
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
110
SPM2007 (7/07)
