XO-54
Vishay Dale
Full Size Clock Oscillators TTL/HCMOS Compatible
FEATURES
•
•
•
•
•
•
•
•
14 pin full size
Industry standard
Wide frequency range
Low cost
Tri-State enable/disable
Resistance weld package
5V
Lead (Pb)-free terminations and RoHS compliant
RoHS
COMPLIANT
The XO-54 series oscillator is Full Size Tri-state
Enable/Disable control. The metal package with pin #7 case
ground acts as shielding to minimize EMI radiation.
STANDARD ELECTRICAL SPECIFICATIONS
XO-54
1 MHz ~ 100.00 MHz
All Condition*
± 25 ppm, ± 50 ppm, ± 100 ppm
T
OPR
0 °C ~ 70 °C (- 40 °C ~ + 85 °C option)
T
STG
- 55 °C ~ + 125 °C
V
DD
5.0 V ± 10 %
25 °C ± 3 °C
± 5 ppm
1 MHz to 23.999 MHz
20 mA Max
24.000 MHz to 49.999 MHz
30 mA Max
Supply Current
I
DD
50.000 MHz to 69.999 MHz
40 mA Max
70.000 MHz to 100.000 MHz
60 mA Max
Sym
1/2 V
DD
40/60 % (45/55 % Option)
Output Symmetry
T
r
10 % V
DD
~ 90 % V
DD
10 ns Max
Rise Time
T
f
90 % V
DD
~ 10 % V
DD
10 ns Max
Fall Time
90 % V
DD
Min
V
OH
Output Voltage
V
OL
10 % V
DD
Max
TTL Load
1 ~ 10 TTL
~ 50 M : 50 pF
Output Load
~ 70 M : 30 pF
HCMOS Load
~ 100 M : 15 pF
Ts
10 ms Max
Start-up Time
Pin 1 = H or open.... Output active at pin 8
Pin 1, Tri-State Function
Pin 1 = L.... High Impedance at pin 8
* Include: 25 °C tolerance, operating temperature range, input voltage change, aging, load change, shock and vibration.
SYMBOL
F
O
PARAMETER
Frequency Range
Frequency Stability*
Operating Temperature Range
Storage Temperature Range
Power Supply Voltage
Aging (First Year)
CONDITION
DIMENSIONS
in millimeters
OH
DD
IH
DC
OL
DD
DD
DD
ORDERING INFORMATION
XO-54
MODEL
B
FREQUENCY STABILITY
AA = 0.0025 % (25 ppm)
A = 0.005 % (50 ppm)
B = 0.01 % (100 ppm)
Standard
R
OTR
Blank = 0 °C to + 70 °C
R = - 40 °C to + 85 °C
E
ENABLE/DISABLE
Blank = Pin 1 open
E = Disable or Tristate
40 M
FREQUENCY/MHz
e2
JEDEC
LEAD (Pb)-FREE
STANDARD
GLOBAL PART NUMBER
X
O
MODEL
5
4
C
FREQUENY
STABILITY
T
OTR
E
ENABLE/
DISABLE
D
PACKAGE
CODE
N
A
4
0
FREQUENCY
M
OPTIONS
www.vishay.com
24
For technical questions contact: frequency@vishay.com
Document Number: 35024
Revision: 05-Mar-07
