R1EX24064ASA00A
R1EX24064ATA00A
Two-wire serial interface
64k EEPROM (8-kword
×
8-bit)
REJ03C0331-0002
Preliminary
Rev.0.02
Jan. 15, 2009
Description
R1EX24xxx series are two-wire serial interface EEPROM (Electrically Erasable and Programmable
ROM). They realize high speed, low power consumption and a high level of reliability by employing
advanced MNOS memory technology and CMOS process and low voltage circuitry technology. They
also have a 32-byte page programming function to make their write operation faster.
Note: Renesas Technology’s serial EEPROM are authorized for using consumer applications such as
cellular phone, camcorders, audio equipment. Therefore, please contact Renesas Technology’s
sales office before using industrial applications such as automotive systems, embedded controllers,
and meters.
Features
•
•
•
•
Single supply: 1.8 V to 5.5 V
Two-wire serial interface (I
2
C serial bus)
Clock frequency: 400 kHz
Power dissipation:
Standby: 2
µA
(max)
Active (Read): 1 mA (max)
Active (Write): 3.0 mA (max)
Automatic page write: 32-byte/page
Write cycle time: 5 ms
Endurance: 1,000k Cycles @25°C
Data retention: 100 Years @25°C
•
•
•
•
Preliminary: The specifications of this device are subject to change without notice. Please contact your
nearest Renesas Technology’s Sales Dept. regarding specifications.
REJ03C0331-0002
Page 1 of 20
Rev.0.02
Jan.15, 2009
