DIGITRON SEMICONDUCTORS
MUR3020-MUR3040
MAXIMUM RATINGS
Rating
Peak repetitive reverse voltage
Working peak reverse voltage
DC blocking voltage
Average rectified forward current
(Rated V
R
)
Peak repetitive surge current
(Rated V
R,
square wave, 20 kHz)
Non-repetitive peak surge current
(surge applied at rated load conditions, halfwave, single phase, 60Hz)
Operating and storage junction temperature range
Maximum thermal resistance
Junction to case
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FRM
I
FSM
T
J,
T
stg
R
ӨJC
MUR
3020
200
3030
300
30 @ T
C
= 70°C
30 @ T
C
= 150°C
300
-65 to +175
1.0
3040
400
Unit
30A ULTRA FAST RECTIFIER
V
A
A
A
°C
°C/W
ELECTRICAL CHARACTERISTICS
(T
C
= 25°C unless otherwise noted)
Parameter
Maximum instantaneous forward voltage
(I
F
= 30A, T
C
= 100°C)
(I
F
= 30A, T
C
= 25°C)
Maximum instantaneous reverse current
(Rated dc voltage, T
C
= 100°C)
(Rated dc voltage, T
C
= 25°C)
Maximum reverse recovery time
(I
F
= 1.0A, di/dt = 15A/µs)
Symbol
MUR
3020
3030
1.4
1.5
6.0
35
100
3040
Unit
V
F
V
I
R
mA
µA
ns
t
rr
MECHANICAL CHARACTERISTICS
Case
Marking
Pin out
TO-218
Alpha-numeric
See below
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121205
DIGITRON SEMICONDUCTORS
MUR3020-MUR3040
30A ULTRA FAST RECTIFIER
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121205
