DIGITRON SEMICONDUCTORS
MUR605CT-MUR620CT
MAXIMUM RATINGS
Rating
Peak repetitive reverse voltage
Working peak reverse voltage
DC blocking voltage
Average rectified forward current
(Rated V
R
)
Non-repetitive peak surge current
(surge applied at rated load conditions, halfwave, single
phase, 60Hz)
Operating and storage junction temperature range
Maximum thermal resistance
Junction to case
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FSM
T
J,
T
stg
R
ӨJC
MUR
605CT
50
610CT
100
615CT
150
620CT
200
Unit
6A SCHOTTKY RECTIFIER
V
A
A
°C
°C/W
6.0 @ T
C
= 130°C
75
-65 to +175
7.0
ELECTRICAL CHARACTERISTICS
(T
C
= 25°C unless otherwise noted)
Parameter
Maximum instantaneous forward voltage
(I
F
= 3.0A, T
C
= 150°C)
(I
F
= 3.0A, T
C
= 25°C)
Maximum instantaneous reverse current
(Rated dc voltage, T
C
= 150°C)
(Rated dc voltage, T
C
= 25°C)
Maximum reverse recovery time
(I
F
= 1.0A, di/dt = 50A/µs)
Note 1: Pulse test: Pulse width = 300µs, duty cycle = 2.0%.
(1)
Symbol
MUR
605CT
610CT
0.895
0.975
250
5.0
35
615CT
620CT
Unit
V
F
(1)
V
I
R
µA
t
rr
ns
MECHANICAL CHARACTERISTICS
Case
Marking
Pin out
TO-220AB
Alpha-numeric
See below
TO-220AB
Inches
Min
Max
0.570 0.620
0.380 0.405
0.160 0.190
0.025 0.035
0.142 0.147
0.095 0.105
0.110 0.155
0.018 0.025
0.500 0.562
0.045 0.060
0.190 0.210
0.100 0.120
0.080 0.110
0.045 0.055
0.235 0.255
-
0.050
Millimeters
Min
Max
14.480 15.750
9.660 10.280
4.070
4.820
0.640
0.880
3.610
3.730
2.420
2.660
2.800
3.930
0.460
0.640
12.700 14.270
1.150
1.520
4.830
5.330
2.540
3.040
2.040
2.790
1.150
1.390
5.970
6.470
-
1.270
A
B
C
D
F
G
H
J
K
L
N
Q
R
S
T
U
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121128
DIGITRON SEMICONDUCTORS
MUR605CT-MUR620CT
10A SCHOTTKY RECTIFIER
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121128
