DIGITRON SEMICONDUCTORS
MUR805-MUR860
8A SCHOTTKY RECTIFIER
MAXIMUM RATINGS
Rating
Peak repetitive reverse voltage
Working peak reverse voltage
DC blocking voltage
Average rectified forward current
(Rated V
R
)
Peak repetitive forward current
(Rated V
R
)
Square wave, 20 kHz
Non-repetitive peak surge current
(surge applied at rated load conditions, halfwave, single
phase, 60Hz)
Operating and storage junction temperature range
Maximum thermal resistance
Junction to case
Junction to ambient
(1)
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FM
MUR
805
50
810
100
815
150
820
200
840
400
860
600
Unit
V
A
A
8.0 @ T
C
= 150°C
16 @ T
C
= 150°C
I
FSM
T
J,
T
stg
R
ӨJC
R
ӨJA
3.0
100
-65 to +175
2.0
73
A
°C
°C/W
ELECTRICAL CHARACTERISTICS
(T
C
= 25°C unless otherwise noted)
Parameter
Maximum instantaneous forward voltage
(I
F
= 8.0A, T
C
= 150°C)
(I
F
= 8.0A, T
C
= 25°C)
Maximum instantaneous reverse current
(Rated dc voltage, T
C
= 150°C)
(Rated dc voltage, T
C
= 25°C)
Maximum reverse recovery time
(I
F
= 1.0A, di/dt = 50A/µs)
(I
F
= 0.5A, I
R
= 1.0A, I
REC
= 0.25A)
Note 1: Pulse test: Pulse width = 300µs, duty cycle = 2.0%.
(1)
Symbol
MUR
805
810
0.895
0.975
250
5.0
35
25
815
820
840
1.00
1.30
500
10
60
50
860
1.20
1.50
Unit
V
F
(1)
V
I
R
µA
t
rr
ns
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
Rev. 20121128
DIGITRON SEMICONDUCTORS
MUR805-MUR860
8A SCHOTTKY RECTIFIER
MECHANICAL CHARACTERISTICS
Case
Marking
Pin out
TO-220AC
Alpha-numeric
See below
TO-220AC
Inches
Min
A
B
C
D
F
G
H
J
K
L
Q
R
S
T
U
0.595
0.380
0.160
0.142
0.142
0.190
0.110
0.018
0.500
0.045
0.100
0.080
0.045
0.235
0.030
Max
0.620
0.405
0.190
0.147
0.147
0.210
0.130
0.025
0.562
0.050
0.120
0.110
0.055
0.255
0.050
Millimeters
Min
15.110
9.650
4.060
3.610
3.610
4.830
2.790
0.460
12.700
1.140
2.540
2.040
1.140
5.970
0.760
Max
15.750
10.290
4.820
3.730
3.730
5.330
3.300
0.640
14.270
1.270
3.040
2.790
1.390
6.480
1.270
Available Non-RoHS (standard) or RoHS compliant (add PBF suffix).
Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.
144 Market Street
Kenilworth NJ 07033 USA
phone +1.908.245-7200
fax +1.908.245-0555
sales@digitroncorp.com
www.digitroncorp.com
