F-213
TM
STRIP
35
PES–08–02–L–VT
PET–04–01–L–VT
(6,35 mm) .250"
PES, PET SERIES
35A HIGH POWER HEADER & SOCKET
PES Mates with:
PET
PET Mates with:
PES, PESS
PES
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
TAIL
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?PET
or www.samtec.com?PES
Insulator Material:
Black LCP
Terminal Material:
Copper Alloy
Plating:
Sn or Au over 50µ"
(1,27 µm) Ni
Operating Temp Range:
-55°C to +105°C with Tin
-55°C to +125°C with Gold
Voltage Rating:
725 VAC/1025 VDC
Wiping Distance (PES):
(0,38 mm) .015"
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
CURRENT RATING
(PER CONTACT)
PET/PES
AMBIENT
TEMP
2 PINS 4 PINS
20°C
47A
43A
40°C
40A
39A
60°C
33A
31A
75°C
27.6A
26.2A
TIN PLATED
–01
–02, –04,
–06, –08
= Use with
(1,60 mm) .062"
Thick PCB
–L
= 10µ" (0,25 µm)
Gold on contact,
Matte Tin on tail
–VT
= Vertical
–SD
= Screw
Down
(Right
Angle only)
– RA
= Right Angle
(Screw Down
option required)
(20,80) .819
(3,81) .150 DIA
–02
= Use with
(3,18 mm) .125"
Thick PCB
No. of positions x (6,35) .250 + (16,51) .650
(11,43)
.450
(2,04)
(6,35)
.080
.250
TYP
–T
= Matte Tin
(12,00) .472
(4,40)
.173
(8,30)
.327
(12,64)
.497
(20,80)
.819
A
(5,54)
.218
(4,44)
.175
(2,54) .100
–RA–SD
(0,64)
.025
(2,54) .100
(0,50) .020
(0,64)
.025
A
(2,54)
.100
LEAD
STYLE
A
(2,35) .093
(3,95) .156
ALSO AVAILABLE
Combination Signal/Power:
See PESC or PETC Series.
–VT
–01
–02
• Screw down
(right angle)
APPLICATION
SPECIFIC OPTION
• Locking Clip (Manual
placement required).
• No Latch ears.
Call Samtec.
PET
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
TAIL
OPTION
OTHER
OPTION
–01
–02, –04,
–06, –08
= Use with
(1,60 mm) .062"
Thick PCB
–L
= 10µ" (0,25 µm)
Gold on contact,
Matte Tin on tail
–VT
= Vertical
–SD
= Screw
Down
(Right
Angle only)
– RA
= Right Angle
(Screw Down
option
required)
–02
MATED HEIGHT
= Use with
(3,18 mm) .125"
Thick PCB
No. of positions x (6,35) .250 + (16,51) .650
(11,43) .450
(6,35)
(2,70) .106
.250 TYP
–T
= Matte Tin
LEAD STYLE
A
(2,35) .093
(3,95) .156
(3,81)
.150 DIA
(19 mm)
.748"
–01
–02
(14,62)
.575
(14,50)
.571
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some sizes, styles
and options are non-standard,
non-returnable.
A
(2,54)
.100
(0,50) .020
(0,64)
.025 (0,64)
.025
A
(2,54) .100
(5,69)
.224
(23,50) .925
(2,54) .100
(5,54) .218
–VT
–RA–SD
WWW.SAMTEC.COM
