TM
Brilliance by design
LED Replacement for
Incandescent Lamps
MODEL 513
T-1 3/4 Wedge base LED is
available in all colors. Direct
replacement for T-1 3/4 wedge base
incandescent lamps.
FEATURES
• Available in all colors and voltages
• Long life LEDs
• Low power consumption
• Direct replacement for:
11*, 17, 18,
37, 56, 73, 74, 79, 84, 85 & 86
HOW TO ORDER
Voltage
2.5vdc
5vdc
6.3vdc
14vdc
28vdc
Model No.
513-205X*
513-5X
513-603X
513-14X
513-28X
Where the 'X' appears insert: 1-Red, 2-
Green, 3-Yellow, 4-Amber, 5-Ultra Green, 6-
Ultra Blue, 7-Pure White
NOTE:
* External resistor required
* *For voltage/current specs, see page 7-9
MODEL 516
T-3 1/4 Bi-pin LED is available in all
colors. Direct replacement for the T-3
MODEL 512
1/4 wedge base bi-pin incandescent
lamps. Unit available in both standard
160 degree viewing angle for
switches and vide viewing applica-
tions and 30 degree for narrow
viewing surfaces that require extra
brightness. Please specify when
ordering. For example: 516-127D for
12vdc white LED for narrow ultra
bright illumination or 516-127 for
12vdc white LED for wide bright
illumination.
FEATURES
• Available in all colors and voltages
• Long life LEDs
• Low power consumption
• Direct replacement for:
124, 147,
152, 158, 159, 161, 168, 184, 190,
192-194, 259, 280, 285, 400, 444,
447, 464, 555, 585, 655, 656, 657,
658, 740, 758, 947, 3-501, 3-504,
3-505, 3-507
HOW TO ORDER
Voltage
5vdc
6vdc
7vdc
12vdc
14vdc
24vdc
28vdc
Model No.
516-5X
516-6X
516-7X
516-12X
516-14X
516-24X
516-28X
Where the 'X' appears insert: 1-Red, 2-
Green, 3-Yellow, 4-Amber, 5-Ultra Green, 6-
Ultra Blue, 7-Pure White
NOTE:
*For voltage/current specs, see page 7-9
7-7
SloanLED
copyright 2006 SloanLED
513 516
TM
Brilliance by design
LED Replacements for
Incandescent Lamps
LED Specifications and Technical Data
LED data for models 160, 162, 164, 460, 510, 516, 522, 532, 513, 541
Color
Choice
1
2
3
4
5
6
7
LED
Size
T 1-3/4
T 1-3/4
T 1-3/4
T 1-3/4
T 1-3/4
T 1-3/4
T 1-3/4
Raw
Chip
Material
GaAIAs
Gap
AllnGap
AllnGap
InGaN
InGaN
InGaN/
YAG
Emitted
Color
Red
Green
Yellow
Amber
Ultra
Green
Wave
Length
660
565
595
611
575
470
Viewing
Angle
(Deg.)
22
20
22
22
30
30
45
lv (mcd)
Typical
3000-4000
750
2000-3000
2000-3000
2200
500
1200
If (mA) Vf (V)
Typical Typical
20
20
25
25
25
25
25
2.1
1.8
2.1
2.1
3.5
3.5
3.5
Blue
Pure
White
LED data for models 159, 197, 311
Color
Choice
1
2
3
4
5
6
7
LED
Size
T-1
T-1
T-1
T-1
T-1
T-1
T-1
Raw
Chip
Material
GaAIAs
Gap
AllnGap
AllnGap
InGaN
InGaN
InGaN/
YAG
Emitted
Color
Red
Green
Yellow
Amber
Ultra
Green
Wave
Length
660
568
595
611
575
470
Viewing
Angle
(Deg.)
30
20
30
30
30
30
45
lv (mcd)
Typical
1250
500
500
500
1700
650
630
If (mA) Vf (V)
Typical Typical
20
20
25
25
25
25
25
1.8
1.8
2.1
2.1
3.5
3.5
3.5
Blue
Pure
White
Note: The specifications listed above are subject to change. For special LED requirements amd color please
contact SloanLED.
7-9
SloanLED
copyright 2006 SloanLED
