SIDACtor Protection Thyristors
Description
(PXXA PXXB
Package DO-214AA
PXXC)
Fast Delivery Time
PXXA,PXXB,PXXC Series SIDACtor Protection Thyristor protect telecommunications equipment such as
ADSL Modems,Router, , Telephone, CCTV Camera,Digital Video Record,Video Capture Card,Twisted-pair
video transmitter,CATV Splitter.....Etc.
PXXA,PXXB,PXXC Series SIDACtor Protection Thyristor are used to enable equipment to meet various
regulatory requirements including GR 1089, ITU K.20/21,IEC 61000-4-5, YD/T 1082,YD/T 993,YD/T
950,TIA-968-A ,TIA-968-B
Features
Compared to surge suppression using other technologies, PXXA,PXXB,PXXC Series devices offer absolute surge protection
regardless of the surge current available and the rate of applied voltage (dv/dt). PXXA,PXXB,PXXC Series devices:
•
100% Lead-Free(RoHs
Compliant )
•
Cannot be damaged by voltage
•
Eliminate hysteresis and heat dissipation typically found with clamping devices
•
Eliminate voltage overshoot caused by fast-rising transients
•
Are non-degenerative
•
Have low capacitance, making them ideal for high-speed transmission equipment
Electrical
Characteristics
Parameter
Definition
Peak Off-state Voltage
— maximum voltage that can be applied while maintaining off state
Switching Voltage
— maximum voltage prior to switching to on state
Holding Current
— minimum current required to maintain on state
Switching Current
— maximum current required to switch to on state
On-state Current
— maximum rated continuous on-state current
On-state Voltage
— maximum voltage measured at rated on-state current
Off-state Capacitance
— typical capacitance measured in off state
Leakage Current
— maximum peak off-state current measured at V
DRM
Peak Pulse Current
— maximum rated peak impulse current
Peak One-cycle Surge Current
— maximum rated one-cycle AC current
Rate of Rise of Current
— maximum rated value of the acceptable rate of rise in current over time
V
DRM
V
S
I
H
I
S
I
T
V
T
C
apacitance
I
DRM
I
PP
I
TSM
di/dt
1
Revised:February 25,2014
www.huaandz.com
ShenZhen
HuaXinAn Electronics Co.,Ltd
Electrical
Characteristics
V
DRM
@I
DRM=
5μA
V
min
P23B
P26B
P31B
P35B
P008C
P03C
P06C
P07C
P09C
P11C
P13C
P15C
P18C
P21C
P23C
P26C
P31C
P35C
P45C
190
220
275
320
6
25
58
65
75
90
120
140
170
180
190
220
275
320
400
V
S
@100V/
μs
V
max
260
300
350
400
25
40
77
88
98
130
160
180
220
240
260
300
350
400
540
mA
min
150
150
150
150
50
50
150
150
150
150
150
150
150
150
150
150
150
150
150
mA
max
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
A
max
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
I
H
I
S
I
T
(SIDACtor Protection Thyristors )
continued
V
T
@I
T
=2.2Amps
Capacitance
@1MHz,2V bias
Part Number
V
max
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
pF
50
45
45
40
75
75
55
60
65
55
60
50
55
85
65
65
55
50
45
Notes:
-All measurements are made at an ambient temperature of 25°C .Ipp applies to -40°C through +85°C temperature
range .
-Off-state capacitance(Co) is typical value.
*For surge ratings,see next page.
3
Revised:February 25,2014
www.huaandz.com
ShenZhen
HuaXinAn Electronics Co.,Ltd
Surge Ratings
I
pp
2
x
10µs
Series
A
B
C
Amps
150
250
500
(SIDACtor Protection Thyristors )
I
pp
8x20µs
Amps
150
250
400
I
pp
10x160µs
Amps
90
150
200
I
pp
10x560µs
Amps
50
100
150
I
pp
10x1000µs
Amps
45
80
100
I
pp
5x320µs
Amps
75
100
200
I
pp
5x310µs
Amps
75
100
200
I
pp
10x360µs
Amps
75
125
175
I
TSM
50/60Hz
di/dt
Amps/µs
500
500
500
Amps
20
25
30
Thermal Considerations
Package
DO-214AA/SMB
Symbol
Parameter
Operating Junction Temperature Range
Storage Temperature Range
Junction to Ambient on prited circuit
Value
-40 to +150
-65 to +150
90
Unit
°C
°C
°C /W
T
J
T
S
R
θJA
Description of Part Number
P
008
B
I
pp
Rating(10x1000µs)A=45A
Median Voltage
B=80A C=100A
P
=SIDACtor
Protection Thyristor
4
Revised:February 25,2014
www.huaandz.com
